A8205B
01/18
Copyright 2018, Sargent Manufacturing Company, an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Sargent Manufacturing Company is prohibited.
IN220
PoE
Exit Device
Installation Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SARGENT IN220 and is the answer not in the manual?

Questions and answers

Related Manuals for Assa Abloy SARGENT IN220

Summary of Contents for Assa Abloy SARGENT IN220

  • Page 1 IN220 Exit Device Installation Instructions A8205B 01/18 Copyright 2018, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.

  • Page 3: Table Of Contents

    Table of Contents Warning ...................3 General Description ..............4 Hardware Specifications ............4 Electronic Specifications ............4 Installation Wiring ..............5 Parts Breakdown ..............8 Rim Type 8877/8878 Exit Device Installation .......12 Mortise Type 8977/8978 Exit Device Insallation ....24 Operational Check..............35 Warning Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

  • Page 4: General Description

    IN220 Exit Device General Description The SARGENT IN220 Exit device combines superior aesthetics with the energy efficiency and streamlined architecture of Power-over-Ethernet (PoE) access control. PoE-enabled access control allows facilities to leverage existing network infrastructure for enhanced security and easier, more cost-effective installations.
  • Page 5 IN220 Exit Device Parts Breakdown PART NO./ORDER ITEM QTY. DESCRIPTION STRING IN-220-EM01-[B*]IP-B Reader assembly - black plastic IN-220-EM01-[B*]IP-W Reader assembly - white plastic IN-220-EM01-[B*]IP-MB-xxx** Reader assembly - black plastic with metal trim IN-220-EM01-[B*]IP-MW-xxx** Reader assembly - white plastic with metal trim IN-220-EM01-[B*]IPS-B Reader assembly - black plastic IN-220-EM01-[B*]IPS-W...
  • Page 6 IN220 Exit Device Parts Breakdown (continued) 8877/8878 x ET x Lever Design IN220 Rim Exit Device ITEM PART No. DESCRIPTION REQ’D Cylinder Assembly (Reference Catalog for Available Cylinders) Lever (Reference Catalog for Available Styles) 97-4152 Exit Trim (ET) With Cylinder 97-4153 Exit Trim (ET) Without Cylinder 68-7546...
  • Page 7 IN220 Exit Device Parts Breakdown (continued) 8977/8978 x RT x Lever Design IN220 Mortise Exit Device ITEM PART No. DESCRIPTION REQ’D Cylinder Assembly (Reference Catalog for Available Cylinders) Lever (Reference Catalog for Available Styles) 97-4136 Exit Trim (ET) With Cylinder 97-4137 Exit Trim (ET) Without Cylinder 68-7546...

  • Page 8: Installation Wiring

    IN220 Exit Device Installation Wiring Overview SARGENT IN220 PoE Typical Application Network Cable Surface Mount RJ45 Network Switch (802.3af) LMT: Lock Management Tool A. PoE frame harness assembly B. PoE data hinge from McKinney (patent pending) C. PoE door harness* from McKinney D.
  • Page 9 IN220 Exit Device Installation Wiring (Continued) Supplied by CI Supplied by End User Certified Integrator (CI) supplies and terminates the B-Splice connector and the PoE Switch male RJ45 connector from harness to end user provided facility cable B-Splice Patch Cable Crimp Connector Patch Panel to PoE Switch...
  • Page 10 IN220 Exit Device Installation Wiring (Continued) Frame Harness Installation Components and wire harness supplied by McKinney. Suggested installation: Supplied by CI Cut end / ceiling-side PoE harness: TIA/EIA 568-B Standard Wiring B-Splice Crimp Connector Wire Pair Number White/Orange Orange White/Green RJ45-M Blue Ceiling...
  • Page 11 IN220 Exit Device Hinge Installation Order of installation may vary. Refer to appropriate sections for instructions. Hinge-side harness connectors: • 4-pin male Molex connector • 6-pin male Molex connector with ground wire Lock-side harness connectors: • Ring terminal • Male RJ45 connector (crimped after cable is fed through door) Notes: •...

  • Page 12: Rim Type 8877/8878 Exit Device Installation

    IN220 Exit Device Installation Instructions for 8877/8878 Rim Exit 1 Door Preparation Inside A. Verify Hand and Bevel of Door • Check hand of door. The exit device is non-handed and the trim is field reversible. Left Hand Right Hand Reverse Reverse •...
  • Page 13 IN220 Exit Device 2 Install Door Position Switch (DPS) Wood doors have 3/8” raceway to controller cutout and metal doors have 3/4” raceway to the controller cutout. Refer to template A8214. 1. Insert connector end of DPS through the raceway on the latch edge of the door (Fig.
  • Page 14 IN220 Exit Device 3 Mount Exit Device Chassis NOTE: Exit chassis harness consists of a 6-pin female connector and two different-sized ground lugs (Fig. 3A) 1. Feed 6-pin connector and larger ground lug straight through to outside of door (Fig. 3A, B) while feeding smaller ground lug into wire hole, up through wire channel and out through inside of door (Fig.
  • Page 15 IN220 Exit Device 4 Mount Exit Trim (ET) NOTE: For exterior applications, use ET gasket (52-0263) to seal between ET escutcheon and outside door surface. A. Connect motor harness adapter to chassis harness connector (Fig. 4A). B. For wood doors: Route ET wire harness connector through the cylinder hole, up and through the wire run channel to the controller cutout.
  • Page 16 IN220 Exit Device 5 Install Cylinder For devices without cylinder, go to Step 6. 1. While installing the rim cylinder, support the tail piece of the cylinder, verifying its engagement with the top hub of the exit chassis. Note: Be sure ET harness is clear of cylinder and tailpiece. 2.
  • Page 17 IN220 Exit Device 7 Install Chassis Cover Secure chassis cover to chassis using (4) #8-32 x 5/16” oval head machine screws (Fig. 7). NOTE: Cable lengths exaggerated for illustrative purposes. Fig. 7 1-800-810-WIRE • www.sargentlock.com • A8205B...
  • Page 18 IN220 Exit Device 8 Outside Reader and Mounting Plate Installation 1. Orient the reader so the LED lens is at the top. 2. Feed the cable/connector through the door (from outside to inside). 3. Install the reader to the outside of door by aligning the mounting posts with the door preparation holes.
  • Page 19 IN220 Exit Device Outside Reader Installation (Continued) 4. Next feed the cables/connectors through the inside mounting assembly (and gasket if required*). 5. Insert and partially tighten (2) through-bolts prior to installation of connectors. NOTE: Cable lengths exaggerated for illustrative purposes. Gasket* Inside of Door Inside...
  • Page 20 IN220 Exit Device Installation of Connectors DPS (4-pin) CAUTION - Do not touch or allow debris to enter connector contacts. Secure the following connectors to their respective terminals (Fig. 10A, B): A. Secure the 4-pin DPS connector. B. Secure the 10-pin lock body assembly connector. Ground IMPORTANT: Do not run wires through bottom hole in plate (Fig.
  • Page 21 IN220 Exit Device 11 Installation of Inside Component Assembly 1. Insert top tabs of controller into slots on mounting plate (Fig. 11A). 2. Ensure proper alignment of board-to-board connectors while pivoting bottom of controller toward door until tab on bottom snaps securely into place on mounting plate. CAUTION: To avoid possible damage to board-to-board connectors, care should be taken when securing controller to mounting plate.
  • Page 22 IN220 Exit Device 12 Inside Cover Installation 1. Assemble cover by hooking top edge on inside mounting plate. 2. Carefully press bottom of cover toward door without pinching wires. 3. Secure the cover with the security allen wrench. Inside of Door Inside Cover Fig.
  • Page 23 IN220 Exit Device 13 Installation of Rail Assembly 1. Retrieve harness from end of rail. Note: Harness has limited travel and can be damaged. 2. Attach harness to female connector on chassis. 3. Install rail and screws per exit device instructions. Note: This view shows rim exit device version.

  • Page 24: Mortise Type 8977/8978 Exit Device Insallation

    IN220 Exit Device Installation Instructions for Mortise Type 8977/8978 Exit Device 1 Door Preparation Inside A. Verify Hand and Bevel of Door • Check hand of door. This exit device is handed and is not reversible. Left Hand Right Hand •...
  • Page 25 IN220 Exit Device 2 Install Door Position Switch (DPS) Wood doors have 3/8” raceway to controller cutout and metal doors have 3/4” raceway to the controller cutout. Refer to template A8215. 1. Insert connector end of DPS through the raceway on the latch edge of the door (Fig.
  • Page 26 IN220 Exit Device 3 Mount Mortise & Exit Device Chassis 1. Slide mortise lock into door and loosely secure with (2) flat head screws. NOTE: Exit chassis harness consists of a 6-pin female connector and two different-sized ground lugs (Fig. 3A) 2.
  • Page 27 IN220 Exit Device 4 Position Exit Trim (ET) NOTE: For exterior applications, use ET gasket (52-0263) as a seal between ET escutcheon and outside door surface. A. Connect motor harness adapter to chassis harness connector (Fig. 4). B. For wood doors: Route ET wire harness connector through the cylinder hole, up and through the wire run channel to the controller cutout.
  • Page 28 IN220 Exit Device 5 Install Cylinder For devices without cylinder, go to Step 6. 1. While installing the rim cylinder, support the tail piece of the cylinder, verifying its engagement with the top hub of the exit chassis. Note: Be sure ET harness is clear of cylinder and tailpiece. 2.
  • Page 29 IN220 Exit Device 7 Install Chassis Cover Secure chassis cover to chassis using (4) #8-32 x 5/16” oval head machine screws (Fig. 7). NOTE: Cable lengths exaggerated for illustrative purposes. Fig. 7 1-800-810-WIRE • www.sargentlock.com • A8205B...
  • Page 30 IN220 Exit Device 8 Outside Reader and Mounting Plate Installation 1. Orient the reader so the LED lens is at the top. 2. Feed the cable/connector through the door (from outside to inside). 3. Install the reader to the outside of door by aligning the mounting posts with the door preparation holes.
  • Page 31 IN220 Exit Device Outside Reader Installation (Continued) 4. Next feed the cables/connectors through the inside mounting assembly (and gasket if required*). 5. Insert and partially tighten (2) through-bolts prior to installation of connectors. NOTE: Cable lengths exaggerated for illustrative purposes. Gasket* Inside Mounting Plate...
  • Page 32 IN220 Exit Device 9 Installation of Connectors CAUTION - Do not touch or allow debris to enter connector contacts. DPS (4-pin) Secure the following connectors to their respective terminals (Fig. 9A, B): A. Secure the 4-pin DPS connector. B. Secure the 10-pin lock body assembly connector. IMPORTANT: Do not run wires through bottom hole in plate (Fig.
  • Page 33 IN220 Exit Device Installation of Inside Component Assembly 1. Insert top tabs of controller into slots on mounting plate (Fig. 10A, B). 2. Ensure proper alignment of board-to-board connectors while pivoting bottom of controller toward door until tab on bottom snaps securely into place on mounting plate. CAUTION: To avoid possible damage to board-to-board connectors, care should be taken when securing controller to mounting plate.
  • Page 34 IN220 Exit Device 12 Inside Cover Installation 1. Assemble cover by hooking top edge on inside mounting plate. 2. Carefully press bottom of cover toward door without pinching wires. 3. Secure the cover with the security allen wrench. Inside of Door Inside Cover Security...

  • Page 35: Operational Check

    IN220 Exit Device Operational Check IMPORTANT: Be sure to test functions prior to closing door. In all cases, perform the following checks: 1. Ensure that inside lever retracts latch. • For units with cylinders, the following checks apply: Insert key into cylinder and rotate: a.
  • Page 36 The company’s customer base includes commercial construction, institutional, and industrial markets. Copyright © 2018, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
