Summary of Contents for PCE Health and Fitness GM 55
- Page 1 User Manual PCE-GM 55 Gloss Meter User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 21 October 2019 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
Contents Safety notes ................... 1 Delivery contents .................. 2 Technical specifications ..............2 Device description ................3 Display description ................4 On/off ...................... 5 Automatic Power Off................5 Measurement ..................5 Calibration ..................... 5 10 New calibration standard ..............5 11 Saving/viewing/deleting measured data .......... -
Page 3: Safety Notes
Safety notes Please read this manual carefully and completely before you use the device for the first time. The device may only be used by qualified personnel and repaired by PCE Instruments personnel. Damage or injuries caused by non-observance of the manual are excluded from our liability and not covered by our warranty. -
Page 4: Delivery Contents
Delivery contents 1 x gloss meter PCE-GM 55 1 x reference standard 1 x cleaning cloth 1 x carrying case 1 x user manual Technical specifications Measuring angle 20°, 45°, 75° Measuring range 0 ... 200 gloss units Resolution 0.1 gloss units Accuracy ±... -
Page 5: Device Description
Device description Description Display On/off key (POWER) ANGLE key to set measuring angle (ANGLE) CAL key for calibration and to decrease parameters MEAS key to make a measurement DEL key to delete reading RD key to view memory and increase parameter USB interface via 2.5 mm jack Case Charging connection... -
Page 6: Display Description
Display description Description Indicates that you are in calibration mode Reading Measuring mode Measuring angle Continuous mode Memory readout mode Memory item no. Indicates that battery must be recharged Indicates that a measurement is made © PCE Instruments... -
Page 7: On/Off
On/off To turn on the meter, press the on/off key. To turn off the meter, press and hold the on/off key until “OFF“ is displayed. Automatic Power Off The gloss meter has an automatic power off function to save battery power. If no key is pressed for 10 minutes when a single measurement is made, the meter will turn off automatically. -
Page 8: Saving/Viewing/Deleting Measured Data
Saving/viewing/deleting measured data This gloss meter has two functions which can be seen on the display. The meter is in measuring mode The meter is in memory readout mode In measuring mode, each reding will be saved. A measurement is made as soon as the measuring icon is displayed. -
Page 9: Warranty
Warranty You can read our warranty terms in our General Business Terms which you can find here: https://www.pce-instruments.com/english/terms. Disposal For the disposal of batteries in the EU, the 2006/66/EC directive of the European Parliament applies. Due to the contained pollutants, batteries must not be disposed of as household waste. They must be given to collection points designed for that purpose. - Page 10 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17 Tel.
