11
10
6
2
1
02/08/2011
1. Drain Valve
2. Bottom Plate
3. Heat Exchanger
4. Bottom Plate O-Ring
5. Lower Housing
6. Grommet
7. Cover O-Ring
8. Inlet Port/Check Valve
Fig. 21.2, DAVCO Fuel/Water Separator (Fuel Pro 382
shown)
15
14
13
12
9
8
7
5
4
3
f470567
9. Fuel Outlet Port
10. Filter Element
11. Spring
12. Clear Cover
13. Vent Cap O-Ring
14. Vent Cap
15. Collar
In an Emergency
02/16/2009
Fig. 21.3, DAVCO Collar Wrench
5. Remove the filter and dispose of it in an environ-
mentally acceptable manner.
6.
Clean all threads and sealing surfaces very thor-
oughly. Even a small amount of dirt will prevent
the fuel/water separator from sealing, and an air
leak will result.
7. Ensure that the drain valve is closed.
8. Remove the filter grommet from the filter stud, if
equipped.
9. Fill the housing to the top with clean diesel fuel.
10.
Install a standard fuel filter element on the filter
stud. If a standard filter element is not available,
install a spin-on fuel filter element (part number
FF105 or equivalent).
11. Install the cover O-ring, clear cover, and the col-
lar. Hand-tighten the collar.
12. Install and hand-tighten the vent cap O-ring and
vent cap.
13.
Start the engine. When the lubricating oil
reaches its normal operating pressure, increase
engine speed to high idle for one to two minutes
to purge air from the system.
Emergency Starting With
Jumper Cables
When using jumper cables, follow the instructions
below.
WARNING
Batteries release explosive gas. Do not smoke
when working around batteries. Put out all flames
FOR REMOVAL OF TOP COLLAR ONLY
f470277
21.2
