É9065843002#ËÍ
9065843002
Order no. 6462 7664 13 Part no. 906 584 30 02 Edition ÄJ 2013-1a
Sprinter
Fuse Allocation Supplement

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sprinter and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for freightliner Sprinter

Summary of Contents for freightliner Sprinter

  • Page 1 Sprinter Fuse Allocation Supplement É9065843002#ËÍ 9065843002 Order no. 6462 7664 13 Part no. 906 584 30 02 Edition ÄJ 2013-1a...
  • Page 2 © Daimler AG: not to be reprinted, translated could be helpful to you. or otherwise reproduced, in whole or in part, "Authorized Sprinter Dealer" is defined as an This symbol designates an without written permission. authorized Mercedes-Benz Sprinter Dealer. instruction you must follow.
  • Page 3 Contents Index ............2 Fuses supplement ......... 3 9065843002 É9065843002#ËÍ...
  • Page 4 Index Fuses ............3 Fuse box under the left front seat ..7 Main fuse box ........3 Relays ............. 3 Main fuse box ........7 Voltage supply Fuses ..........3...
  • Page 5 Fuses supplement Fuses Main fuse box General safety notes WARNING If you manipulate or bridge a faulty fuse or if you replace it with a fuse with a higher amperage, the electric cables could be overloaded. This could result in a fire. There is a risk of an accident and injury.
  • Page 6 Fuses supplement Configuration Fuses Consumer Fuse rating The F87 fuse (30 A) for the DC/DC converter is under the SRB fuse and relay module in the Terminal 87 (2) 20 A main fuse box. Have this fuse changed at a qualified specialist workshop only.
  • Page 7 Fuses supplement Consumer Fuse Consumer Fuse rating rating Headlamp range Headlamp cleaning 30 A control/front- system compartment heating Anti-theft alarm system 15 A Terminal 87 (3) 10 A (ATA)/beacon/beacon with siren Air bag control unit 10 A Additional turn signal 10 A Terminal 15 vehicle/ 7.5 A...
  • Page 8 Fuses supplement Consumer Fuse Consumer Fuse rating rating Passenger- 7.5 A Terminal 30 pre-fuse 150 A compartment boxes, SAM (signal illumination (reading acquisition and lamps or LED light strip) actuation module)/SRB (fuse and relay module) Convenience lighting 10 A Connection point on the Bridge Reading and load- 10 A...
  • Page 9 Fuses supplement Relays in the main fuse box Relays Description K40/9 Horn relay K40/9 Windshield wiper setting 1/2 relay K40/9 Starter relay, terminal 15 K40/9 Windshield wipers on/off relay K40/9 Starter relay, terminal 50 K40/9 Relay, terminal 15 R (normally open contact) K40/9 Engine control unit relay, terminal 87 K40/9...
  • Page 10 Fuses supplement Configuration Fuses Consumer Fuse rating Fuse block F55/3 ECO Start/control unit Consumer Fuse EGS (electronic gearbox 10 A rating control) Mirror setting/rear All-wheel drive control window defroster unit Rear window wiper 30 A ESM (electronic selector 10 A Auxiliary heating, digital module) timer/rear view...
  • Page 11 Fuses supplement Fuse block F55/4 Consumer Fuse rating Consumer Fuse rating Terminal 30, body 15 A electrics (courier Terminal 30, body/ 25 A vehicles) equipment manufacturer Rear window defroster 30 A without ATA Terminal 15, body/ 15 A equipment Rear window defroster 15 A manufacturer with ATA...
  • Page 12 Fuses supplement Fuse block F55/6 Consumer Fuse rating Consumer Fuse rating 15 A heater 3 DEF supply reservoir, Starter auxiliary battery/ 25 A vehicles with exhaust starter relay power gas aftertreatment supply 15 A heater 2 hose, Terminal 87 (7), gas 7.5 A vehicles with exhaust system, vehicles with a...
  • Page 13 Fuses supplement Fuses in the seat base of the left front seat There are additional fuses in the seat base, for example: for the passenger compartment or rear compartment air conditioning for the windshield heating for other vehicle assemblies, such as the power-steering pump, auxiliary battery and PTC heater from the body manufacturers for retarders,...
  • Page 14 Fuses supplement Relays in the seat base of the left front seat Relays Description Unassigned — Load relief relay, terminal 15 K41/5 Starter relay, terminal 15 Secondary air injection/secondary air pump relay K110 SCR relay , vehicles with exhaust gas aftertreatment Fuel pump relay K23/1 Blower relay, front, blower setting 1...
  • Page 15 Fuses supplement Relays Description K13/7 Windshield heating relay 1 Body manufacturer relay, terminal 15 K88/1 Body manufacturer relay, terminal 61 (D+) Loading tailgate relay Comfort illumination relay K122 LED light strip relay, passenger compartment lighting Headlamp cleaning system relay K51/10 Beacon with siren relay K118 Entrance lighting relay (bus)
  • Page 16 Fuses supplement Relays Description — K9/2 Air-conditioning system relay, auxiliary fan (mono) — K9/5 Passenger-compartment air conditioning relay, auxiliary fan...
