Fleck 6700 Downflow Quick Start Manual

MODEL 6700 Downflow - V2.0
Option Setting Level #1
Programming Chart
NOTE:
1. Push Program Button Once Per Display.
2. Option settings may be changed by pushing
either the Up or Down Arrow Button.
3. Depending on current valve programming
certain displays will not be able to be viewed or
set.
Level #1
To Enter Push And Hold Program Button For 5 Seconds.
Program
Water Hardness Set In Grains per Gallon
Example: 25 Grains [
Program
Water Hardness After Mixing Valve
Example: 10 French Degrees Of Hardness [P - - - - 10]
Note: This display only viewed with metric display
formats U2 & U4
Program
System Capacity
Example: 20,000 Grain Capacity [
Program
Regeneration Time
Example: 2:00 A.M. [ 2:00 ]
Program
Regeneration Cycle Step #1 - Backwash
Example: (Backwash 10 Minutes) [1 - - - 10.0]
Program
Regeneration Cycle Step #2 - Brine Draw / Slow Rinse
Example: (Brine Draw and Slow Rinse
for 60 Minutes) [2 - - - 60.0]
Program
Regeneration Cycle Step #3 - Rapid Rinse
Example: (Rapid Rinse for 10 Minutes) [3 - - - 10.0]
Program
Regeneration Cycle Step #4 - Brine Tank Refill
Example: (Brine Refill for 12 Minutes) [4 - - - 12.0]
Program
Regeneration Cycle Step #5 - Typically Not Used
Example: Cancelled [5 - - - OFF]
Program
Option Level #1 Is Exited
Normal Operation is resumed
Printed in U.S.A.
25]
20]
Page 1A
