INSTALLATION &
OPERATION MANUAL
BCA150
AC SOURCE

BATTERY CHARGER

An ISO9001 Registered Company
Battery Chargers
Inverters
Power Supplies
Voltage Converters
8128 River Way, Delta B.C. V4G 1K5 Canada T. 604.946.9981 F. 604.946.9983 TF. 800.668.3884 (US/CANADA)
www.analyticsystems.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BCA150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Analytic Systems BCA150

  • Page 1: Battery Charger

    INSTALLATION & OPERATION MANUAL BCA150 AC SOURCE BATTERY CHARGER An ISO9001 Registered Company Battery Chargers • Inverters • Power Supplies • Voltage Converters 8128 River Way, Delta B.C. V4G 1K5 Canada T. 604.946.9981 F. 604.946.9983 TF. 800.668.3884 (US/CANADA) www.analyticsystems.com...
  • Page 2: Important Safety Instructions

    AC SOURCE BATTERY CHARGER IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS — This manual contains important safety and operating instructions for the battery charger. BATTERY CHARGER PRECAUTIONS 1. Do not expose the battery charger to rain or snow unless it is a sealed model. 2.
  • Page 3 Improper connection can result in the risk of electric shock. Medical Equipment Notice Analytic Systems does not recommend the use of their products in life support applications where failure or malfunction of this product can be reasonably expected to cause failure of the life support device or to significantly affect its safety or effectiveness.
  • Page 4 • Product Warnings and Advisories • Table of Contents • Introduction • Box Contents • Main Parts • Operation • Two-Stage Charging • Installation • Troubleshooting • Specifications • Warranty Copyright (2005-2017) Analytic Systems Ware (1993) Ltd. Revised - April 11, 2018...
  • Page 5 Page intentionally left blank...
  • Page 6: Box Contents

    AC voltage worldwide (85-265 VAC ). The recently updated single board design incorporates modern switch-mode technology for unmatched efficiency and ultra-quiet operation. In the absence of a battery, the BCA150 can also function as a power supply up to its continuous current rating.
  • Page 7: Main Parts

    Main Parts Front Panel DC Output Connections: 2 sets Output Voltage Adjust Phoenix VDFK4 Terminal Blocks AC Input Connection: (Red and Black) Bulgin IEC320 Flange Mount Inlet Chassis Grounding Screw 6.3mm Top Panel Lighted Power Switch Drip Shield Power Indicator LED Integrated Digital Voltmeter Load Indicator LEDs (Output 1&2)
  • Page 8: Operation

    Rotate it counterclockwise to decrease the output voltage. You can check the charging voltage using the integrated digital voltmeter. LED Indicators The BCA150 features several indicator LEDs on its top panel to display the unit’s operating condition. Their meanings are detailed below. POWER: This LED glows green when the unit is connected to an AC power source and energized.
  • Page 9: Two-Stage Charging

    Amps Time Two Stage Charge The BCA150 charges batteries using either a two-stage charging profile. A two-stage charging profile occurs in two stages. During the bulk stage, the battery draws a constant current (Output Current) from the charger. This causes the battery’s voltage to rise until finally reaching a voltage slightly higher than the battery’s rated capacity, the float voltage.
  • Page 10: Installation

    Installation Mounting Mount the unit in a WELL VENTILATED and DRY area with at least one inch (2.54 cm) of clear- ance around the extruded vents. The unit should be mounted on a vertical surface with the drip shield facing upward as shown below. AC Input Connection This unit is equipped with a 3-pin Bulgin AC Inlet (6.3mm) Tab Flange Mount to serve as an AC input connection.
  • Page 11: Fuse Replacement

    Fuse Replacement This unit features reverse battery connection protection. In the event that a battery is connected in reverse polarity, the output fuses will blow to prevent damage to unit from erroneous current. Loosen and remove the 8 screws located on the vented side panels. (There are 4 screws on each side.) Loose and remove the 2 screws securing the drip shield to the top panel.
  • Page 12: Troubleshooting

    Troubleshooting In the event that your unit is not operating normally, the table below can be used to troubleshoot the cause of the problem and recommend the next course of action. Issue: The output fuse(s) immediately blow when the unit is turned ON. Check: The battery is likely connected in reverse polarity and the output fuses have blown to protect the unit from erroneous current.
  • Page 13: Specifications

    Specifications Input Unit Model BCA150 Voltage 85-265 VAC Current 3A (Max @ 90 VAC in) Power Factor >0.98 at full load (>0.86 @ 400Hz) Input Frequency 45 - 405 Hz Noise on Input < 50 mV Output Nominal Voltage 12 VDC...
  • Page 14 Page intentionally left blank...
  • Page 15: Limited Warranty

    2 Years from date of manufacture for non-standard or OEM products 1 Year from date of manufacture for encapsulated products. 3. Analytic Systems will determine eligibility for warranty from the date of purchase shown on the warranty card when returned within 30 days, or...
  • Page 16 DESIGNED AND MANUFACTURED BY 800-668-3884 604-946-9983 sales@analyticsystems.com www.AnalyticSystems.com Battery Chargers • Inverters • Power Supplies • Voltage Converters 8128 River Way Delta, BC V4G 1K5 | Canada Register Products Online | www.analyticsystems.com/support/warranty-registration...
