Summary of Contents for Bellman & Symfon Visit
- Page 1 Visit installer’s guide...
-
Page 2: Table Of Contents
All you need to know about Visit. Transmitters Door transmitter Push button transmitter Telephone transmitter Baby monitor Smoke alarm Receivers Flash receiver Portable receiver Pager receiver Wrist receiver Alarm clock receiver Accessories Pager charger Mobile phone sensor Bed shaker Flash receiver bracket... -
Page 3: Door Transmitter
VISIT SYSTEM System overview Reliable and flexible The Visit system is highly flexible and can easily be configured to cater your client’s specific home environment and lifestyle. It offers doorbell and phone detection, baby monitoring Door transmitter Smoke alarm Baby monitor Telephone transmitter and fire protection that meets the highest standards. - Page 4 Remove the battery pull tab to start the unit. In the box Dimensions and weight Environment Clean the wall with the wet wipe and remove the protective film from the Velcro. BE1411 Visit door transmitter Height: 100 mm, 4.0" For indoor use only ...
- Page 5 To clear all recorded sounds, press and hold button 1 and 2 simultaneously for 5 seconds. The green Visit LED on the receiver lights up to show The green Visit LED on the receiver lights up to show Note: This will clear the recorded sounds and the transmitter will return to factory settings, but the radio key settings and that the signal was received.
- Page 6 Here is how you change the radio key: The Visit LED on the receiver lights up in green and it starts to sound, flash or vibrate with a certain pace, called signal pattern. The transmitter and the connected accessories determine the signal pattern. The default is as follows: Open the transmitter front cover and move any radio key switch to the up = on position to change the radio key.
-
Page 7: Push Button Transmitter
2 x hole markings Technical specifications In the box Dimensions and weight Frequency and coverage Mounting with adhesive tape BE1420 Visit push button transmitter Height: 66 mm, 2.6" Frequency Attach the adhesive tape to the back of the transmitter. - Page 8 Press the front button on the transmitter within 30 seconds to send the new radio key. All Visit LEDs on the receiver blink 5 times to show that the radio key has been changed. It then returns to normal mode.
- Page 9 In the box Dimensions and weight Accessories The yellow Visit LED on the receiver lights up to show The yellow Visit LED on the receiver lights up to show BE1431 Visit telephone transmitter Height: 100 mm, 4.0"...
- Page 10 Green, top Yellow blinks 2 x ring signal, high Medium All Visit LEDs on the receiver blink 5 times to show that the radio key has been changed. It then returns to normal mode. Other accessory Green, bottom Green light...
- Page 11 Technical specifications The orange Visit LED on the receiver lights up to show The orange Visit LED on the receiver lights up to show that the signal was received. In addition, it starts to that the radio signal was received.
- Page 12 Press both test buttons simultaneously on the baby monitor within 30 s to send the new radio key. 75 dB Orange 10 s Orange All Visit LEDs on the receiver blink 5 times to show that the radio key has been changed. It then returns to normal mode. 85 dB Green Green Note: All Visit units must be set to the same radio key in order to operate as a group.
- Page 13 Technical specifications The red Visit LED on the receiver lights up to show that The red Visit LED on the receiver lights up to show that the signal was received. In addition it starts to sound, the signal was received.
- Page 14 Using broadcast mode Note: All Visit units must be set to the same radio key in order to operate as a group. If broadcast mode is activated, all Visit If you want the smoke alarm signal to be transmitted to all Visit receivers within radio range, you can activate broadcast receivers will respond regardless of the radio key settings.
- Page 15 To test the radio link you need a Visit transmitter. Press the test button/s on the transmitter. The receiver lights up a Visit LED and starts to flash. If a bed shaker is connected, it will vibrate. A short press on the mute/test button repeats the last indication. If nothing happens, see Troubleshooting.
- Page 16 While still holding down the button, activate the desired transmitter as intended. Release the button. All Visit LEDs on the receiver blink 5 times to show that the radio key has been changed. It then returns to normal mode. Scroll through the different Visit LED options by pressing the mute/test button on the receiver. Select the desired Visit LED colour by holding down the mute/test button until the power LED goes out and lights up again.
- Page 17 To test the radio link you need a Visit transmitter. Press the test button/s on the transmitter. The receiver lights up a Visit LED and starts to flash and sound. If a bed shaker is connected, it will vibrate. A short press on the test button repeats the last indication. If nothing happens, see Troubleshooting.
- Page 18 Release the button. All Visit LEDs on the receiver blink 5 times to show that the radio key has been changed. It then returns to normal mode.
- Page 19 Orange LED, pacifier symbol Battery power If you want to use Visit for other purposes, the pager front label can be replaced with a customized one. Here is how it’s done: The baby monitor is activated Coverage ...
- Page 20 Release the button. All Visit LEDs on the pager blink 5 times to show that the radio key has been changed. It then returns to normal mode. Scroll through the different Visit LED options by pressing the function button on the pager. Select the desired Visit LED Please note: All Visit units must be set to the same radio key in order to operate as a group.
-
Page 21: Wrist Receiver
To test the radio link you need a Visit transmitter. Press the test button/s on the transmitter. The receiver starts to vibrate and lights up a Visit LED. If a bed shaker is connected during charging, it will vibrate. If nothing happens, see Troubleshooting. - Page 22 Release the button. All Visit LEDs on the receiver blink 5 times to show that the radio key has been changed. It then returns to normal mode. Scroll through the different Visit LED options by pressing the function button on the receiver. Select the desired Visit Please note: All Visit units must be set to the same radio key in order to operate as a group.
-
Page 23: Alarm Clock Receiver
To test the radio link you need a Visit transmitter. Press the test button/s on the transmitter. The alarm clock lights up a Visit LED and starts to sound and flash. The bed shaker emits a sound and vibrates. If nothing happens, see Troubleshooting. -
Page 24: Receivers
Press the test button/s on the transmitter within 30 seconds to send the new radio key. All Visit LEDs on the alarm clock blink 5 times to show that the radio key has been changed. It then returns to normal mode. -
Page 25: Pager Charger
Note: Charge the backup batteries for 24 hours before using it with a bed shaker. Technical specifications To test the radio link you need the pager and a Visit transmitter. Press the test button/s on the transmitter (see Testing the connection for the relevant transmitter). -
Page 26: Mobile Phone Sensor
Place the sensor on the mobile phone or tablet display and use e.g. a landline telephone to call the mobile phone. When the display lights up, the yellow Visit LED on the alarm clock blinks and it starts to sound, flash and vibrate. -
Page 27: Bed Shaker
Operating voltage BE1444 Visit flash receiver with Relative humidity: 5% -95% 2.0 – 4.0 V DC from a Visit receiver battery backup and advanced Non-condensing Power consumption smoke detector supervision 250 – 750 mA Maintenance and care BE1570 Visit wrist receiver charger ... -
Page 28: Magnetic Switch
The external trigger cable is used to connect an external connect it to the telephone transmitter or baby monitor to trigger source to a Visit product. Use it for instance to be alerted when someone enters a room or leaves the bed. - Page 29 Phone +46 31 68 28 20 Fax +46 31 68 28 90 Email info@bellman.com © and TM 2016, Bellman & Symfon AB, all rights reserved. Bellman Visit and bellman.com Bellman & Symfon are registered trademarks owned by Bellman & Symfon AB.
