Instruction Manual
S2/1PCN-W1
Dear Customer, congratulations on the purchase of the EMP-Centauri
product. Before its installation and putting into operation, read carefully the
entire operation manual. Keep the purchase and rework (if any) records for
future need.
1) Field of Application, Warranty
The product is designed for the distribution of satellite TV and radio signals.
We recommend the device to be installed by the qualified technician.
EMP-Centauri's PROFI CLASS products are covered under 6 (six) years
warranty from the date of purchase. The warranty shall not apply to the
product used for other than the specified purpose. The user will be
responsible for injury or material damage which may arise in consequence of
any product use in contradiction with the manual. Repairs or any interventions
4x LNB
in the product may be performed only by EMP-Centauri company, or other
(SINGLE)
companies authorized by EMP-Centauri.
2) Technical Specifications
S4/1PCN-W1
The product is a universal LNB switch suitable for outdoor use. It switches
signals from 2 LNBs, allows to add next LNB to existing Monoblock LNB or to
switch between two DiSEqC 1.0 switches. The product is controlled from
satellite receiver using commands DiSEqC 1.0, 1.1 or 1.2, the choice of
command depends on manner of usage. The switch passes through DC
voltage, 22 kHz and DiSEqC commands, its inputs are short-circuit protected.
Number of inputs / Outputs
Frequency Range
Insertion Loss (avg)
Isolation (min)
Control
Current Consumption
LNB Current (max)
Dimensions (w,d,h)
Temperature Range
Instruction Manual
S2/1PCN-W1
Dear Customer, congratulations on the purchase of the EMP-Centauri
product. Before its installation and putting into operation, read carefully the
entire operation manual. Keep the purchase and rework (if any) records for
future need.
1) Field of Application, Warranty
The product is designed for the distribution of satellite TV and radio signals.
We recommend the device to be installed by the qualified technician.
EMP-Centauri's PROFI CLASS products are covered under 6 (six) years
warranty from the date of purchase. The warranty shall not apply to the
product used for other than the specified purpose. The user will be
responsible for injury or material damage which may arise in consequence of
any product use in contradiction with the manual. Repairs or any interventions
in the product may be performed only by EMP-Centauri company, or other
companies authorized by EMP-Centauri.
2) Technical Specifications
The product is a universal LNB switch suitable for outdoor use. It switches
signals from 2 LNBs, allows to add next LNB to existing Monoblock LNB or to
switch between two DiSEqC 1.0 switches. The product is controlled from
satellite receiver using commands DiSEqC 1.0, 1.1 or 1.2, the choice of
command depends on manner of usage. The switch passes through DC
4x LNB
voltage, 22 kHz and DiSEqC commands, its inputs are short-circuit protected.
(SINGLE)
S4/1PCN-W1
1/003565 A
2/1
SAT 950–2300 MHz
SAT 5 dB
SAT 25 dB (between inputs)
DiSEqC 1.0, 1.1 a 1.2
30 mA (18 V DC) from satellite receiver
400 mA (18 V DC)
8.2 x 7.7 x 2.3 cm
−30°C – +70°C
