Migration from RTCU AX9 turbo:

There are the following differences between the RTCU AX9 turbo and the RTCU NX-900:
Topic
DC Out
Digital input – S0
Cable glands
Cellular antenna
GNSS
WLAN / Bluetooth
ISM RF antenna
RS485 port 2
Accelerometer
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
AX9 turbo
3.3 VDC
Enabled by default
Three PG11 + two optional PG9
Internal + external
Not present
Not present
Internal
Shared with RS232 port 1, port=0
Not Present
Page 9 of 50
NX-900
5 VDC
Disabled by default
Three M20
External
Built-in, external antenna
Built-in, external antenna
External
Dedicated port, port=3
Present
