- Page 1 EXPRESS MANUAL Page 1 of 14...
- Page 2 This manual can help you understand how to operate, maintain and use your GoPowerBike. In order to avoid danger, please use caution and learn how to ride this bike. GoPowerBike are not to be held liable for injury or damage caused from riding the GoPowerBike 24” Bike to Go .
-
Page 3: Table Of Contents
Table of Contents: Bike Specs pg. 4 Assembling the Bike: pg. 5 Assembling the Wheels Assembling the Stem pg. 6 Assembling the Handlebar pg.6 Attaching the Seat pg.7 Attaching the Pedals pg.8 Adjusting the brakes pg.9 Battery pg.10 Charger/Charging the Bike pg.11 Battery Maintenance pg.12... -
Page 4: Bike Specs
Bike Specs: Display: LCD 36V 5 Level PAS Hub Motor: 36v 500w Lights:Front Headlight Pedal Assist: 5 Level Throttle: Half Twist with On/Off Button Max Speed: 20 MPH Charge Time: 3-4 Hours Range: 20 Miles Brake Levers: Comfort Grip Levers with Throttle Cutoff Brakes: F/R disc brake Cassette: 7 Speed Shimano Mega-range Freewheel Chain: Wheel 48Y 175MM... - Page 5 Assembly Instructions The steps below are a general manual to assemble your GoPowerBike and is anything but an extensive guide to assembling your bike. For professional assembly, maintenance, or help, please visit a bike shop. Assembly Steps Step 1: Remove bike from carton and carefully set out all contents of the box.
- Page 6 ASSEMBLY: To Attach The Wheel: Align the wheel into the center of the fork, and make sure that the center of the wheel is aligned with the frame of the bike. Tighten into place by securing the buckle, as seen in the picture below.
-
Page 7: Assembling The Handlebar
(as seen in the picture to the left) Adjust the saddle to find the right height for riding your GoPowerBike. If the safety line on the seat tube is visible (as seen in the picture to the left), then lower the seat until the safety line is NOT visible. -
Page 8: Attaching The Pedals
ATTACHING THE PEDALS To attach the pedals, you will need a wrench. The two pedals will be labeled with R (for Right) and L (for Left). Once you have determined the Right and Left peddles, now twist the pedals toward the front of the bike until they are securely fastened. -
Page 9: Adjusting The Brakes
ADJUSTING THE BRAKES If you feel that your brakes are too tight, turn the silver knob clockwise (clockwise is to the right) and now try to see how the braking of the bike wheel feels. Turning the silver disc clockwise will loosen the brakes, as where turning the silver knob counter-clockwise will tighten the brakes. -
Page 10: Battery
BATTERY To take out the battery, turn the key clockwise to unlock the battery pack. Lift the battery pack up to remove it. When you put the battery back on the bike frame, put the bottom right of the battery in place first, then align the top of the battery so that the battery is fully secure and connected. -
Page 11: Battery Maintenance
Battery Maintenance - Do NOT leave the battery in charger over night or for an extended period of time. - Operating temperature when charging: 32° - 113° F - Operating temperature when discharging: -4° - 113° F - If the battery gets wet, we advise that you dry the battery as soon as possible. - Page 12 Charger/Charging Your electric bike comes with a certified charger, only use the charger that comes with your bike or provided by GoPowerBike. The working voltage for the charger is 100/240V. After charging is complete, we advise you always cover the charging port on the battery.
-
Page 13: Folding Instructions
FOLDING INSTRUCTIONS Front Folding Stem: On the bar that connects the handlebar to the front fork, locate the locking lever. Once located, lift the lever and pull down towards floor. Then pull down the safety locking lever and then at the same time push down the stem until it is fully folded. -
Page 14: Warranty
GOPOWERBIKE has no liability (and to the knowledge of GOPOWERBIKE there is no basis for any present or future action, suit, proceeding, hearing, investigation, charge, complaint, claim or demand against it giving rise to any such liability) for replacement or repair thereof or other damages in connection therewith.
