GOPOWERBIKE
GoSpyder Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GoSpyder and is the answer not in the manual?

Questions and answers

Related Manuals for GoPowerBike GoSpyder

Summary of Contents for GoPowerBike GoSpyder

  • Page 1 GOPOWERBIKE GoSpyder Owner’s Manual...
  • Page 2 WWW.GOPOWERBIKE.COM DO NOT RETURN TO STORE! If you need any help with your new GoSpyder bike, whether it is missing parts or you need help with assembly, please email us at Help@gopowerbike.com. We will be sure to respond!
  • Page 3 Welcome Thank you for purchasing the GoSpyder from GoPowerBike. We take pride in bringing you a quality product that will offer years of enjoyment. Please read and understand this manual fully before assembling and riding your bike. If you have any questions after reading this manual, please reference the GoPowerBike Help Center or contact us by email.

  • Page 4: Table Of Contents

    Table of Contents Using This Manual General Info Safety Check Getting Started How to Fold Your Ebike Attaching the Seat Attaching the Pedals Adjusting the Handlebars Charging Your Ebike Get To Know Your Ebike Using the Kickstand Battery and Charging Riding Your Ebike Maintenance Disclaimer &...

  • Page 5: Using This Manual

    Keep this manual, along with any other documents that were included with your bike, for future reference, however all content in this manual is subject to change or withdrawal without notice. Gopowerbike makes every effort to ensure the accuracy of its documentation and assumes no responsibility or liability if any errors or inaccuracies appear within.

  • Page 6: General Info

    NOTICE: A critical aspect of assembling your bike by Gopowerbike is securing the front wheel and checking the tightness of the rear wheel axle nuts. All bikes by Gopowerbike use a quick release front wheel mounting mechanism and the rear wheel is bolted on. These mechanisms may become loose or unsecured during shipment or over time.

  • Page 7: Safety Check

    If the throttle, brake lever cutoff switches, pedal assistance, or lighting are functioning abnormally, intermittently, or not working, please discontinue using your ebike immediately and contact the Gopowerbike Product Support team for assistance. Quick Release Levers Quick release levers are located on your ebike to secure the seatpost. These provide convenience to the user since they allow the seatpost to be adjusted without tools.
  • Page 8 Loose, worn, or damaged handlebar grips should be replaced before you ride and can be purchased from Gopowerbike. The seat and seatpost should be properly aligned, fitted to the user, and the seatpost quick release should be properly tightened, fully closed, and secured before riding.
  • Page 9 Fully Assembled GoSpyder...

  • Page 10: Getting Started

    Getting Started Starting notes: · Remove all packaging before beginning assembly. · The directions given in this manual—right, left, front/forward, and rear/back—are oriented as the rider would see them when seated on the bike. The “right side” of the bike, for example, is the side where the rider’s right hand and foot will be.
  • Page 11 Unfolding the Handlebar When to unfold: for riding When to fold: for storage and transport How to unfold: Step 1: Gently raise the handlebar until the stem is resting vertically on the frame. STEM...
  • Page 12 LATCH Step 2: Push the latch in until it clicks into the closed (latched) position.
  • Page 13 Check that the latch is secured by ensuring that it cannot be pulled open. Important: never ride the GoSpyder without the folding latch closed and secured by the locking ring.

  • Page 14: How To Fold Your Ebike

    How to fold: Step 1: Rotate the locking ring counterclockwise around the stem until the tab clears from the tab slot on the folding latch. Step 2: While holding the handlebar stem steady with one hand, use the other hand to pull the latch open (unlatched). Step 3: Gently lower the handlebar down towards the side of the bike opposite the latch.

  • Page 15: Attaching The Seat

    Attaching the Seat Step 1: Pull open the latch on the seat clamp. Step 2: Locate the "minimum insertion" SEAT POST mark engraved near the bottom of MINIMUM INSERTION MARK the seat post. CLAMP LATCH CLAMP KNOB OPPOSITE SIDE NOT SHOWN Step 3: Lower the seat post through the SEAT CLAMP clamp and into the seat tube, until the...
  • Page 16 Step 4: To lock the seat in place, close the latch on the seat clamp. Step 5: Check that the seat is secure: use your hand to put downward pressure on the seat. If the seat post slips further down into the tube, bring It back to position and tighten the clamp by turning the knob clockwise.

  • Page 17: Attaching The Pedals

    Step 6: Install the headlight and tighten using the hex key provided. There is no back nut needed. Attaching the pedals Note the “R" (right) and “L" (left) markings on the end of spindle of each pedal. Step 1: Align the spindle on “R" pedal with the hole at the end of the crank arm on the right side of the bike.
  • Page 18 15MM WRENCH Step 3: Finish inserting and then tightening the spindle into the crank arm by turning it clockwise with the 15 mm wrench or 15mm wrench tip of the multi-tool. Step 4: Check that the right pedal is secure. Step 5: Repeat steps 2 –...

  • Page 19: Adjusting The Handlebars

    Adjusting the handlebar The handlebar can be rotated slightly forward or backwards so that all of the features and functions on it are easy for the rider to see and reach. The handbrakes, especially, should sit at an angle that makes them easy to grip. To rotate the handlebar: Step 1: Pull up the latch on the handlebar clamp so that it is in the open (unlatched) position.
  • Page 20 Step 2: Rotate the handlebar forward or backward to reposition it. Step 3: While holding the handlebar in the new position with one hand, use the other hand to push the latch down and back into the closed (latched) position. Troubleshooting: if the handlebar does not stay secure with the clamp closed, you may need to tighten the clamp.

  • Page 21: Charging Your Ebike

    Charging Your Ebike Connect the DC jack of the charger to the charging port of your ebike and then the AC plug into the outlet. The charger light turns from red to green when charging is complete. ------ Still Charging ------ Fully Charged Charging Indicator Light NOTICE - Important charging notes:...

  • Page 22: Get To Know Your Ebike

    Get to Know Your Ebike-Operation Power On/Off: Press and hold the power button on the left handle for 5 seconds to turn your bike on and off Lights On/Off: Press and hold the button below the battery level indicator on the right handle for 3 seconds to turn the headlight and taillight on and off.
  • Page 23 Get to Know Your Ebike-Operation cont’d Pedal Assist Mode: While you are pedaling, the motor also provides power. Throttle Mode: Twist the throttle to engage the motor for acceleration without pedaling. Battery Indicator: Four battery levels may be indicated on the right handle. When the battery is low, the indicator flashes to remind the owner of the need to charge # of lights Charge...
  • Page 24 Get to Know Your Ebike-Operation cont’d Headlight and Rear Light: Locate the button below the display on the right handle, press and hold for three seconds to switch the headlight on and off. The rear light turns on and off together with the headlight in the Night Ride Mode. In the braking mode, the rear light flashes when braking.

  • Page 25: Using The Kickstand

    KICKSTAND Using the Kickstand To use the kickstand, pivot it down and gently tilt your bike onto it to stand. To raise the kickstand, pivot it back up. Important: always raise the kickstand before riding.

  • Page 26: Battery And Charging

    Battery and Charging...

  • Page 27: Riding Your Ebike

    Riding your ebike 1. Do not use the eBike before reading this manual carefully and knowing your eBike thoroughly. 2. Do not lend your eBike to anyone who do not know how to use it, so as to avoid harm. 3.

  • Page 28: Maintenance

    Maintenance...

  • Page 29: Disclaimer & General Warnings

    Disclaimer General Warnings...

  • Page 30: Limited Warranty

    Limited Warranty...

  • Page 31: Additional Warranty Terms

    Additional Warranty Terms...
  • Page 32 We are here to help! If you have questions: Contact us directly by email to help@gopowerbike.com...
