Summary of Contents for GoPowerBike GoVelo

  • Page 1 GOPOWERBIKE GoVelo Owner’s Manual...
  • Page 2 WWW.GOPOWERBIKE.COM DO NOT RETURN TO STORE! If you need any help with your new GoVelo bike, whether it is missing parts or you need help with assembly, please email us at Help@gopowerbike.com. We will be sure to respond!
  • Page 3 Welcome Thank you for purchasing the GoVelo from GoPowerBike. We take pride in bringing you a quality product that will offer years of enjoyment. Please read and understand this manual fully before assembling and riding your bike. If you have any questions after reading this manual, please reference the GoPowerBike Help Center or contact us by email.
  • Page 4: Table Of Contents

    Table of Contents Using This Manual General Info Safety Check Getting Started Installing the Handlebar Installing the Front Wheel Adjusting the Handlebar Attaching the Pedals Installing the Seat Installing the Front Fender Installing the Kickstand Get To Know Your Ebike Removing &...
  • Page 5: Using This Manual

    Assembly and first adjustment of your bike from GoPowerbike requires special tools and skills and it is recommended that this should be done by a certified, reputable bike mechanic if possible.
  • Page 6: General Info

    NOTICE: A critical aspect of assembling your bike by GoPowerbike is securing the front wheel and checking the tightness of the rear wheel axle nuts. All bikes by GoPowerbike use a quick release front wheel mounting mechanism and the rear wheel is bolted on. These mechanisms may become loose or unsecured during shipment or over time.
  • Page 7: Safety Check

    If the throttle, brake lever cutoff switches, pedal assistance, or lighting are functioning abnormally, intermittently, or not working, please discontinue using your ebike immediately and contact the GoPowerbike Product Support team for assistance. Quick Release Levers Quick release levers are located on your ebike to secure the seat post. These provide convenience to the user since they allow the seat post to be adjusted without tools.
  • Page 8 Loose, worn, or damaged handlebar grips should be replaced before you ride and can be purchased from GoPowerbike. The seat and seat post should be properly aligned, fitted to the user, and the seat post quick release should be properly tightened, fully closed, and secured before riding.
  • Page 9 Fully Assembled GoVelo...
  • Page 10: Getting Started

    Getting Started Starting notes: · Remove all packaging before beginning assembly. · The directions given in this manual—right, left, front/forward, and rear/back—are oriented as the rider would see them when seated on the bike. The “right side” of the bike, for example, is the side where the rider’s right hand and foot will be.
  • Page 11: Installing The Handlebar

    Installing the Handlebar Step 1: Loosen and remove the 4 screws on the handlebar clamp by turning them counter-clockwise with the hex key. Step 2: Remove the clamp cover and set aside with the 4 screws Step 3: Rotate the clamp so that it and the front fork are facing forward.
  • Page 12 Step 4: Lift the handlebar onto the clamp base and position it such that it is: • Nestled into the curved bottom of the clamp • Oriented with the LCD display on the left-hand side of the handlebar • Centered and balanced in the clamp Step 5: Place the clamp cover onto the center of the handlebar such that: •...
  • Page 13 Step 7: Check that the handlebar is secure.
  • Page 14: Installing The Front Wheel

    Installing the Front Wheel Step 1: Gently balance the bike on the front fork and back wheel. (you may want a friend to help) Step 2: Check that all packing materials are removed from the wheel and front fork Step 3: Twist the knob on the quick release axle counter-clockwise to loosen and remove it.
  • Page 15 Step 6: Gently twist the knob clockwise onto the end of the axle but DO NOT fully tighten it. Step 7: Position the front wheel in between the front fork so that the disc side of the wheel is on the side of the fork with the brake components. Step 8: Slide the wheel down into place with the disc in between the brake pads and the two springs on the axle situated in the notches at the end of the fork.
  • Page 16 FRONT FORK BRAKE PAD DISC DISC Step 9: When the wheel is centered and in place, tighten the knob on the axle by turning it clockwise. Close the latch on the quick release axle. NOTICE! Ensure that the wheel is securely clamped onto the front fork with the axle.
  • Page 17 Step 10: Check that the wheel spins freely and is secured in place in the fork. Troubleshooting: If you cannot open or close the latch on the quick-release axle, loosen the knob little by little until you can do so. Do not over-loosen. You should feel some tension when opening and closing the latch.
  • Page 18: Adjusting The Handlebar

    Adjusting the handlebar (after front wheel assembly) Step 1: Align the handlebar so that it is perpendicular to the front wheel. Step 2: Tighten the top screw. When you are finished tightening the screw, add the small rubber cap.
  • Page 19 Step 3: After the handlebar is properly aligned and the top screw is tightened, tighten the 2 side screws, as indicated in the pictures. Step 4: Connect the two harness connections. Blue to blue- Green to green- Notice! Make sure the arrows on both ends are aligned to prevent damage to...
  • Page 20: Attaching The Pedals

    Attaching the pedals Note the “R" (right) and “L" (left) markings on the end of spindle of each pedal. Step 1: Align the spindle on “R" pedal with the hole at the end of the crank arm on the right side of the bike.
  • Page 21 15MM WRENCH Step 3: Finish inserting and then tightening the spindle into the crank arm by turning it clockwise with the 15 mm wrench or 15mm wrench tip of the multi-tool. Step 4: Check that the right pedal is secure. Step 5: Repeat steps 2 –...
  • Page 22: Installing The Seat

    Installing the Seat Step 1: Pull open the latch on the seat clamp. Step 2: Locate the "minimum insertion" SEAT POST mark engraved near the bottom of the MINIMUM INSERTION MARK seat post. CLAMP LATCH CLAMP KNOB OPPOSITE SIDE NOT SHOWN Step 3: Lower the seat post through the SEAT CLAMP clamp and into the seat tube, until the...
  • Page 23 Step 4: To lock the seat in place, close the latch on the seat clamp. Step 5: Check that the seat is secure: use your hand to put downward pressure on the seat. If the seat post slips further down into the tube, bring It back to position and tighten the clamp by turning the knob clockwise.
  • Page 24: Installing The Front Fender

    Installing the Front Fender Step 1: Loosen front screw on fork for fender installation. Step 2: Slide front fender through the front fork and over the tire until the tab on the fender meets the fork. Step 3: Move headlight into place and use the screw to attach the headlight and fender.
  • Page 25 Step 4: Align the fender “U” brace arms to the tabs on the rear side of the front fork Step 5: Insert screws and tighten them with the hex key.
  • Page 26: Installing The Kickstand

    Installing the Kickstand Step 1: Place the kickstand behind the kickstand bracket on the bike. Step 2: Align the screw holes on the kickstand and frame, insert the kickstand screws and tighten them with the hex key. (Screws go through the frame and then the kickstand) Frame bracket kickstand...
  • Page 27: Get To Know Your Ebike

    Get to Know Your Ebike-Operation Locate the power button on the left handle. Press it to power on, Power On/Off: and to power off, press and hold it for three seconds. The eBike automatically powers off upon ten minutes of inactivity Lights On/Off: After turning on the eBike, press the light button located left of handlebar.
  • Page 28 Power Cut-Off Brakes: When you pull the brake levers, the controller cuts off the motor output. The mechanical disc brakes are also engaged. As long as the brake levers are not completely released, Pedal Assist Mode or Throttle Mode remains disabled.
  • Page 29: Removing & Installing The Battery

    Removing and Installing the battery This battery is removable. To remove it, open the battery lock, and the upper part of the battery pops up. Take out the battery in the upward direction. To install the battery, start with the bottom of the battery and slide it down through the battery tube. Make sure the discharge port is connected well with the plug of the connector.
  • Page 30 Turn the key so the battery end pops up Gently lift the battery from the battery compartment by sliding upward. Reinstall battery by sliding the bottom of the battery into the battery compartment and sliding the battery in a downward motion locking it into the battery compartment.
  • Page 31: Charging Your Ebike

    Charging Your Ebike Connect the DC jack of the charger to the charging port of your ebike and then the AC plug into the outlet. The charger light turns from red to green when charging is complete. ------ Still Charging ------ Fully Charged Charging Indicator Light NOTICE - Important charging notes:...
  • Page 32: Battery And Charging

    Battery and Charging Do not connect the positive to negative, or vice versa. Do not damage, disassemble, or short-circuit ● the battery. Avoid water, other liquid, or other foreign matter inside the battery to prevent short circuit. Instructions in this manual must be followed when charging the battery, otherwise the owner shall take ●...
  • Page 33: Riding Your Ebike

    Riding your ebike Do not use the eBike before reading this manual carefully and knowing your eBike thoroughly. ● Do not lend your eBike to anyone who do not know how to use it, so as to avoid harm. ● When adjusting the steerer tube and seat tube, do not expose the minimum insertion marks.
  • Page 34: Maintenance

    Maintenance The front and rear wheels should be aligned to the center of the front fork and frame. ● Park away from direct sunlight and rain. ● Do not rinse the eBike. Wipe with a damp cloth to clean. ● Check the motor and brakes frequently.
  • Page 35: Disclaimer & General Warnings

    Disclaimer General Warnings...
  • Page 36: Limited Warranty

    Limited Warranty...
  • Page 37: Additional Warranty Terms

    Additional Warranty Terms...
  • Page 38 We are here to help! If you have questions: Contact us directly by email to help@gopowerbike.com...
