Matrix T-7xi-C Configuration

MYE Wireless Receiver Console Configuration

7xe Console Set-Up

1. On keypad type ENTER 1001 ENTER to log into the Manager Mode. Press the 'TV'
tab and press 'Remote TV'. Press 'Yes' to change the setting.
2. While still in the Manager Mode, press 'About' then 'Software'. Use the chart on Page
4 to find your console minimum software requirement.
a. If your console is not meeting these requirements, contact Matrix CTS with
the frame and console serial numbers along with what the current software
is. They will supply you with new software.
3. Press 'Home'.
4. Press and hold 'Channel Up' and 'Channel Down' to recycle the power on the unit.

7x Console Set-Up

1. On keypad type ENTER 1001 ENTER to log into the Manager Mode. Press the 'TV'
tab and press 'Remote TV'. Press 'Yes' to change the setting.
2. While still in the Manager Mode, press 'About' then 'Software'. Use the chart on Page
4 to find your console minimum software requirement.
b. If your console is not meeting these requirements, contact Matrix CTS with
the frame and console serial numbers along with what the current software
is. They will supply you with new software.
3. Press 'Home'.
4. From the frame power socket, recycle the power on the unit.
(900 MHz)
