Advantech ASMB-813I Series Startup Manual

ASMB-813I Intel® Xeon® E5-2600v3 Series ATX Server
Board with 8 DDR4, 5 PCIe x8, 6 USB 3.0, 8 SATA3
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 ASMB-813I Startup Manual
• 1 Driver CD (user's manual is included)
• 2 Serial ATA HDD data cables
• 2 Serial ATA HDD power cables
• 2 CPU power cables (8P)
• 1 I/O port bracket
• 1 Warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF
file.Acrobat Reader can be downloaded at:
www.adobe.com/Products/acrobat/readstep2.
html (Acrobat is a trademark of Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the ASMB-813I series Rev. A1
Part No. 2001813I10
Print in China
Specifications
Standard M/B Functions
• CPU: Dual LGA2011-R3 Intel Xeon® E5-2600v3 series
• BIOS: AMI 128 Mb SPI BIOS
• Chipset: Intel® C612 PCH
• System memory: 8* DDR4-1600/1866/2133 Registered
ECC DIMM, Max. Capacity 256 GB
Note:
• SATA Interface: 8 SATA3 6 Gb/s ports Intel Rapid
Storage (for Windows only) (SATA0-SATA3 and sSATA0-
sSATA3 Supports software RAID 0, 1, 10 & 5)
• Serial ports: One onboard header, only support RS-232
• Keyboard/mouse connector: Supports standard PS/2
keyboard and mouse
• Watchdog timer: 255 level timer intervals
• USB port: Supports up to 6 USB 3.0 ports (2 ports from
onboard 20-pin header) and 5 USB 2.0 ports (1*Type-A, 2
ports from onboard 10-pin header)
VGA Interface
• Chipset: Aspeed AST2400/1400
• Display Memory: 64 MB
• Resolution: Supports VGA up to resolution 1920 x 1200
@ 60 Hz refresh rate
Ethernet interface
• Interface: 10/100/1000 Mbps
• Controller: LAN1: Intel I210; LAN2: Intel I210; LAN3: Re-
altek 8201EL(10/100Mbps for IPMI, ASMB-813I sku only)
Mechanical and Environmental
• Dmensions (L x W): 244 x 304 mm (9.6" x 12")
• Power supply voltage: +3.3 V, +5 V, ±12 V, +5 Vsb
• Power consumption(Main board only, excluded IO de-
vice): Max. load: +3.3 V @ 1.53 A, +5 V@ 0.92 A, +12 V
• @ 12.21 A,+5 Vsb@ 0.04 A, -12 V@ 0.04 A
• Operating temperature: 0 ~ 60° C (depending on CPU)
• Weight: 1 kg (weight of board)
1st Edition,
july 2015
Due to the inherent limitations of PC architecture,
the system may not fully detect 256 GB RAM
when 256 GB RAM is installed.
ASMB-813I Startup Manual 1
