Keyboard

Dimensions: 80 x 35 x 10.3 cm
(31.5 x 13.78 x 4.05 inches)
Weight: 10kg (22.05 lbs)

Connections: Rear Panel

• MIDI In/Out/Thru
• USB type B port, class-compliant
• Headphone output (Desktop only)
• Impedance: 16 – 75 Ohm

Connections: Top Panel

CV inputs: Two (1/8" TS)

• Mod 1

CV/Gate/Clock outputs: Five (1/8" TS)

• Pitch

Control Voltages

• Range: -5V to 10V
• Pitch: + / - 99 cents
• Mod: + / - 3.0V
• Standards: 1Volt per octave, Hz/Volt

Gate Output

• Range: 3V, 5V, 10V
• Type: V-trig, S-trig

Connections: Front Panel (keyboard)

• Two headphone connectors
• 6.35 mm (1⁄4 in)
• 3.5 mm
• Impedance: 16 – 75 Ohm
• Shared volume control
• Mod 2
• Gate • Mod 1
97

Hydrasynth Specifications

Desktop

Dimensions: 44 x 22.3 x 7 cm
(17.32 x 8.78 x 2.76 inches)
Weight: 3.6kg (7.94 lbs)
• Stereo 1/4" outputs (unbalanced)
• Sustain pedal input (polarity-sensing)
• Expression pedal input (reversible)
• Mod 2

Clock Output

• Range: 3V, 5V, 10V
• Rates: 1 PPS, 2PPQ, 24 PPQ, 48PPQ
• Offset: + / - 100ms
• Division: 1/2x, 2x, 4x
• Clock
