Compressor

Control knob Parameter
2 Sidechain
3 [Ratio]
4 [Threshold]
5 Attack
6 Release
7 Output
8 [Dry/Wet]

Delay Types

Hydrasynth offers 5 delay types, each with distinct characteristics:
• Basic Mono combines the stereo input signal and produces a mono delay.
• Basic Stereo preserves the stereo positioning of the input signal.
• Pan Delay alternates between the right and left input signals.
• LRC Delay outputs the left input, then the right input, then both, and repeats that pattern.
• Reverse takes whatever comes in during the delay period and plays it backward.

Delay Parameters

All of the delays have identical parameters, so we'll describe them once.
Control knob Parameter
2 [Time]
3 [Feedback]
4 [Wet Tone]
6 BPM sync
7 [Feed Tone]
8 [Dry/Wet]
Range
Off, BPM Duck, Tap,
Mod In 1, Mod In 2
1.0 :1 to 20.0 :1
-64.0 to 0.0 dB
1-400 ms
5-560 ms
0-512
0.0-100.0%
Range
BPM = Off: 1 ms to 3.00
seconds
BPM = On: 0, 1/64T to
1/1 Dot
0.0-128.0
-/+ 64.0
Off, On
0.0-128.0
0.0-100.0%
58
Description
Selects sidechain source:
Arpeggiator clock, Tap Tempo button,
CV Mod Input 1 or CV Mod Input 2
Controls compressor strength above
threshold
Controls level at which compression
begins
Time until maximum compression
Time to zero compression if signal is
below threshold
Gain compensation
Blends unaffected and affected signals
Description
Delay period
Fade-out time for delay
Filter control for Wet signal:
-64.0 to -0.1: Low pass filter
0.0: No filtering
0.1 ~ 64.0: High pass filter
Toggles delay sync
Feedback high-frequency decay time
Blends uneffected and effected signals
