Operational Notes

Navigation

The System Setup pages work the same way
all other modules do, but here are some
reminders:
• To access the next or previous page, use
the Page Down / Up arrows.
• Cycle forward to the desired page quickly
by pressing [SYSTEM SETUP] repeatedly.
• Use [SHIFT] + the Page Down / Up arrows
to jump to the last page or back to first
page.

Access, Action

• Some fields have Control buttons that
execute a function, such as the Factory
Reset. These are indicated by the word
(action) in the charts.
• Some pages have access buttons that open
a Calibration page. These are indicated by
the word (access) in the charts. Follow the
instructions in the Left display to calibrate
the selected item.
Master: Page 1
Control knob Function
1 Transpose
2 Tuning
3 O'Scope
4 Memory protect On, Off
5 Left contrast
6 Right contrast
7 LED Dim
8 Light show

Saving the Settings

Press [EXIT] or any module button to save
System Setup changes. The message "System
saving... " will be shown in the Left display for
about 1 second. Note that sound output is
silenced while the settings are being saved.

Notes About Notes

Some parameters are self-explanatory, but
others have additional information below the
chart.
Range Description
- / +11 semitones Transpose keys, pads chromatically
380 to 500 Hz Sets center tuning frequency
On, Off Toggles waveform animation in
Left display
Prevents overwriting of patches
0 to 127 Sets contrast for Left display
0 to 127 Sets contrast for Right display
On, Off Toggles LED brightness between
50% and full
Off, 5-, 15-, 30 Sets timeout period for onset of
minutes light show
84

The System Setup Pages
