Flanger; Rotary; Phaser - Ashun Sound Machines HYDRASYNTH Owner's Manual

Flanger

Control knob Parameter
2 Preset
3 [Rate]
4 [Depth]
5 Offset
6 Feedback
7 Mono/St
8 [Dry/Wet]

Rotary

Control knob Parameter
2 Preset
3 [Lo-Speed]
4 [Hi-Speed]
5 Lo-Depth
6 Hi-Depth
7 Low/High
8 [Dry/Wet]

Phaser

Control knob Parameter
2 Preset
3 [Rate]
4 [Feedback]
5 Depth
6 Phase
7 Offset
8 [Dry/Wet]
Range Description
1-3 Selects preset template
0.02-10.0 Hz Controls the flanger rate
0.0-128.0 Controls the flanger depth
+/- 180° Sets initial phase of effect relative to input
+/- 63 Feeds flanger back into itself (positive or
negative polarity)
Mono, Stereo Selects mono or stereo output
0.0-100.0% Blends unaffected and affected signals
Range Description
1-3 Selects preset template
0.02-10.0 Hz Sets speed of low rotor
0.02-10.0 Hz Sets speed of high rotor
0-127 Controls depth of low rotor
0-127 Controls depth of high rotor
-/+ 63 Volume balance between the low and high
rotors
0.0-100.0% Blends unaffected and affected signals
Range Description
1-3 Selects preset template
0.02-10.0 Hz Controls the rate of the phase modulation
+/- 63.0 Feeds phaser back into itself (positive or
negative polarity)
0-127 Controls the depth of the phase modulation
0-127 Adjusts lowest frequency point of phase
modulation
+/- 180° Controls amount of phase offset relative to
input
0.0-100.0% Blends unaffected and affected signals
56
