Ashun Sound Machines HYDRASYNTH Owner's Manual page 43

Control knob Parameter
2 Control (type = Vowel only) 0.0-128.0 Formant control
3 Cutoff
4 Resonance
5 ENV 1 amount
6 LFO 1 amount
7 Vel Env
8 Keytrack
Control
This parameter is visible only when the Filter
type is set to Vowel. It provides control over
location and spread of the formants, which
are certain peaks and nodes in the filter
frequencies that help to approximate the
resonance of the human vocal apparatus. Use
this with the Cutoff, Resonance, and Vowel
Order parameters for greater precision.
Cutoff
This controls the Cutoff frequency for every
filter type except the Vowel filter, for which
it becomes the vowel control. When Filter 1
is selected on the top panel, the Cutoff knob
also controls this parameter.
Resonance
This adjusts the resonance of the filter. When
Filter 1 is selected on the top panel, the
Resonance knob in the Filter Controls section
also controls this parameter.
ENV 1 amount
This parameter defines the amount and
polarity of the effect Envelope 1 will have on
Filter 1. There is a similar, separate parameter
for Filter 2.
Envelope 1 has a pre-wired connection to the
Filter section, which saves a mod route. But a
different envelope can be used to control the
filter if you want; just set this value to 0 and
create a new route via
Keyboard model only: When Filter 1 is selected
on the top panel, the ENV 1 knob in the Filter
Controls section also controls this parameter.
The Mod Matrix (p. 73)
43
Range Description
0.0-128.0 Cutoff frequency for most; vowel
control for Vowel filter
0.0-128.0 Controls resonance or Q
+/- 64.0 Sets amount & polarity of Envelope 1
effect on filter
+/- 64.0 Sets amount & polarity of LFO 1 effect
on filter
+/- 64.0 Allows velocity to set maximum
range of filter envelope
+/- 200% Scales filter response across
keyboard; C2 = center note
LFO 1 amount
This parameter defines the amount and
polarity of the effect LFO 1 will have on Filter
1. There is a similar, separate parameter for
Filter 2.
LFO 1 has a pre-wired connection to the
Filter section, which saves a mod route. But a
different LFO can be used to control the filter
if you want; just set this value to 0 and create a
new route via The Mod Matrix
Keyboard model only: When Filter 1 is selected
on the top panel, the LFO 1 knob in the Filter
Controls section also controls this parameter.
Vel Env
This is an abbreviation for "Velocity to
Envelope". It adjusts the depth of the filter
envelope based on note velocity: notes
played at maximum velocity allow Envelope
1 to have maximum impact on the filter
frequency, within the range set by the Env 1
amount parameter. It can be set negatively,
so that higher velocities reduce the range of a
positive-going filter envelope or increase the
range of a negative-going filter envelope.
There is a similar, separate parameter for
Filter 2.
Vel Env operates within the range set
by the Env 1 Amount parameter;
if you have no envelope amount set,
the parameter will do nothing.
(p. 73).
