Modulation Sources

These the mod sources available in the Hydrasynth. A few may need explanation; see below the
chart.
Group Modulators
Env Env 1, Env 2, Env 3, Env 4, Env 5
LFO [1] LFO 1, LFO 2, LFO 3, LFO 4, LFO 5, LFO 1+, LFO 2+, LFO 3+, LFO 4+, LFO 5+
Aftertouch MonoAftT (Channel Aftertouch), PolyAftT (Polyphonic Aftertouch)
Keytrack Keytrack (center note = C4 for all mod sources except filter keytrack [center =
C2])
Velocity Velo On (Note On velocity), Velo Off (Note Off velocity)
Wheel PitchWhl (Pitch wheel), ModWhl (Modulation wheel)
Ribbon [2] RbnAbs (Ribbon Absolute bipolar), RbnAbs+ (Ribbon Absolute unipolar),
RbnRel (Ribbon Relative)
Pedal ExpPedal (Expression pedal)
CV Mod In 1, Mod In 2
MIDI CC [000-127]
[1] An LFO is by nature a bipolar source. A plus sign [+] indicates a unipolar source derived from
that LFO.
[2] See The Ribbon as a Mod Source (p. 65)

Modulation Destinations

These the potential mod destinations in the Hydrasynth. A few may need explanation; see
below the chart.
Type Group
1 Arp
2 Osc 1
Osc 2
Osc 3
All Osc [1]
3 Mutator 1
Mutator 2
Mutator 3
Mutator 4
4 Ring Mod
5 Mixer
6 Filter 1
Filter 2
7 Amp
for a description of each mode.
Parameters
Mode, TimeDiv, Swing, Gate, Range,
OctMode, Length, Phrase, Ratchet, Chance
Pitch (+12/-12 semitones), WaveScan
Pitch (+12/-12 semitones), WaveScan
Pitch (+12/-12 semitones)
Pitch (+12/-12 semitones)
Ratio, Depth, Window, Feedback, Dry/Wet, Warp [1-8]
Ratio, Depth, Window, Feedback, Dry/Wet, Warp [1-8]
Ratio, Depth, Window, Feedback, Dry/Wet, Warp [1-8]
Ratio, Depth, Window, Feedback, Dry/Wet, Warp [1-8]
Ring Depth
Osc1Vol, Osc2Vol, Osc3Vol, RingVol, NoiseVol, Osc1Pan, Osc2Pan,
Osc3Pan,
RingPan, NoisePan, Osc1F1/2, Osc2F1/2, Osc3F1/2, RingF1/2, NoisF1/2
Cutoff, Resonance, Drive, Control, Env1Amt, LFO1Amt, Keytrack
Morph, Cutoff, Resonance, Env1Amt, LFO1Amt, Keytrack
LFO2Amt, Level
