Thales TTT-Compact II Manual page 7

5) Put into operation
Tonearm
For assembling the tonearm, please follow the manual of the tonearm itself carefully. The base-
1
ring of the tonearm shall be connected with the three mounting-bolts (1) of the chassis rigidly.
A cable-holder (2) allows you to guide either single or double executed phono-cables out of the
turntable nicely.
As an option, a connection-box (RCA or XLR) is available.
2
Set the level
Place the unit on an even and horizontal base. The level of the TTT-Compact II can be set by
turning the spikes in and out of the main chassis. Please use a level gauge to level the unit
exactly horizontal. Please make sure at least one of the spikes is tightened fully.
The spikes are guided not only by a fine pitch thread but by a cylindrical fitting as well.
Therefore, no locking of the spike is needed. The maximum range of adjustment is 6mm.
3
Interconnects
Connect the ground wire (deliverd with your TTT-Compact II) with either the jack of the cable-
holder (4), or the jack of the chassis (5) and with the fitting connection of your phono-stage. If
the tonearm is connected by a DIN-cable, no separate ground-wire is needed.
Connect the external charger with the power plant and with the fitting jack (5) of the TTT-Com-
pact II. Plug the external charger into the electrical socket. The external charger can handle all
6
usual input voltage.
5
Page 7/10
4
