Thales TTT-Compact II Manual page 6

4) Installing platter
The main-platter (1) is bearing freely on the sub-platter (2). During assembling, please make
sure to guide the main-platter exactly vertically on the sub-platter. The main-platter has an
inlay of a specified high density mat (3). Please take care on this mat for not destroying it during
installation.
1. Guide the main platter (1) carefully from above on the sub-platter (2).
2. Make sure the main-platter is bearing completely on the sub-platter.
3. If needed, dress the inlay-mat (3) around the centre (4) carefully, so the record will lay
on an absolutely even surface.
Page 6/10
1
3
2
4
