Front View
The front panel of the Firebox T15:
Fail Over
The Fail Over indicator is lit when there is a WAN failover from the primary external interface to the
backup interface. After the external interface connection fails back to the primary external interface,
the indicator is not lit.
WAP
On the Firebox T15-W, the WAP indicator is lit when the appliance is activated as a wireless access
point or a wireless client. The color indicates the active wireless radio band.
Indicator
WAP
Network interface status indicators
The Firebox T15 has three network interfaces. There are two status indicators for each interface.
Indicator
1000
10/100
Status
The Status indicator shows when there is a management connection to the device. The Status
indicator is lit for 30 seconds after you connect to the device with the Fireware Web UI or the
command line interface. It is also lit when the device is polled by WatchGuard System Manager.
Mode
The Mode indicator shows the status of the external network connection. If the device can connect
to the external network and send traffic, the indicator is green. The indicator flashes if the device
cannot connect to the external network and send traffic.
Hardware Guide
Indicator color
Yellow
Green
Indicator color
Yellow
Blinks (speed of blink
increases as the data flow
increases)
Green
Blinks (speed of blink
increases as the data flow
increases)
Hardware Specifications
Wireless Band
2.4 GHz radio band
5 GHz radio band
Interface Status
Link speed: 1000 Mbps
Data sent and received
Link speed: 10 Mbps or 100
Mbps
Data sent and received
