  • Page 1 IONPS-D-R1 DC Power Supply User Guide 33707 Rev. A...
  • Page 2 All trademarks and registered trademarks are the property of their respective owners. Copyright Notice/Restrictions Copyright © 2016, 2017 Transition Networks. All rights reserved. No part of this work may be reproduced or used in any form or by any means (graphic, electronic or mechanical) without written permission from Transition Networks.
  • Page 3 Transition Networks, Inc. IONPS-D-R1 User Guide Cautions and Warnings Definitions Cautions indicate that there is the possibility of poor equipment performance or potential damage to the equipment. Warnings indicate that there is the possibility of injury to person. Cautions and Warnings appear here and may appear throughout this manual where appropriate. Failure to read and understand the information identified by this symbol could result in poor equipment performance, damage to the equipment, or injury to persons.

  • Page 4: Table Of Contents

    3. Maintenance ............................... 20 Replacing the Power Supply Module ........................20 Replacing the Fuse ............................... 21 4. IONPS-D-R1 Software Configuration ........................22 IONPS-D-R1 CLI Commands ..........................22 Set Power Supply or Fan STID .......................... 24 IONPS-D-R1 CLI Messages ..........................29 Power Supply Config –...
  • Page 5 Segurança eléctrica............................49 Seguridad eléctrica ............................49 Elsäkerhet ................................ 49 Figures Figure 1: IONPS-D-R1 (DC) Power Supply ........................6 Figure 3: Component Identification ........................13 Figure 2: Grounding Screw ............................15 Figure 4: Removing the Euro Block from Power Module ..................16 Figure 5: Installing Power Wires ..........................

  • Page 6: Introduction And Description

    1. Introduction and Description IONPS-D-R1 Description Transition Networks’ IONPS-D-R1 power module can deliver power or provide optional, redundant DC power for the ION219 chassis. The ION platform is an intelligent, high-density, multi-protocol system supporting a variety of network interface devices. Designed for both carrier class and enterprise network applications where multiple points of fiber integration and secure network management of the fiber interface devices is essential.

  • Page 7: Primary/Secondary Mode

    IONPS-D-R1 always attempts to standby, only providing power to the chassis when no other source is providing sufficient power. The IONPS-D-R1 is shipped in Primary mode by default, meaning it will always attempt to power the chassis; if two IONPS-D-R1s are installed in a chassis, they will both attempt to power the chassis, resulting in load- sharing, with the constant ability for either one to take on the full load of the chassis, should a failure occur.

  • Page 8: Failover And Load Sharing

    The IONPS-D-R1 default setting is Primary mode. If you try to set both P/S #1 and P/S #2 are set to Secondary mode, a warning message displays (a control system exist that prevents both modules from being set to Secondary mode).

  • Page 9: Ion Power Supply Interoperability

    IONPS-D-R1 User Guide ION Power Supply Interoperability The table below shows ION power supply module interoperability. In the table below, where IONPS-x-R1 is referenced, the x indicates A or D (IONPS-A-R1 or IONPS-D-R1). PS #1 (Slot #22) PS #2 (Slot #23)

  • Page 10: Related Manuals And Online Help

    Brochures, Data Sheets, Specifications, etc. go to the Support Library (no logon required). Note that this manual provides links to third party web sites for which Transition Networks is not responsible. Other related manuals are listed below. 1. Product Documentation Postcard, 33504 2.

  • Page 11: Installation

    ION219 Chassis Power Consumption Note: The IONPS-D-R1 can power a fully populated ION219 chassis when loaded with chassis cards that consume 5 Watts of power or less. The IONPS-D-R1 is not recommended for use with the C4120 chassis card as it uses too much power. All other ION chassis cards use 5 Watts of power or less (except the C4120 chassis card).
  • Page 12 Read, understand, and follow all CAUTION and WARNING notices, instructions marked on the product, including in this manual. The IONPS-D-R1 DC Power Supply can replace an existing IONPS-A or IONPS-D, or it can be installed as the redundant Power Supply in an AC powered ION219-A chassis.

  • Page 13: Description

    Read and follow all CAUTION and WARNING instructions marked on the product and in this manual.  The IONPS-D-R1 DC power module is intended for installation in restricted access location only. The IONPS-D-R1, DC power module can replace an existing DC power module or an AC power module in an ION219 Chassis. 33707 Rev. A https://www.transition.com...

  • Page 14: Power Source Circuit Requirements

    Failure to observe this caution could result in damage to, or failure of the power module. Power Source Circuit Requirements The IONPS-D-R1 power module must be connected to a Safety Extra Low Voltage (SELV) circuit. The installer must first determine the circuit’s characteristics (limited current, and hazardous energy levels, etc.) and then install the power module reliably, routing and securing the DC input wires safely in accordance with local and national electrical codes.

  • Page 15: Grounding Screw

    Transition Networks, Inc. IONPS-D-R1 User Guide Grounding Screw The IONPS-D-R1 back panel provides access to the Grounding Screw as shown below. Figure 2: Grounding Screw Jumper J5 – USB Connector The USB connector (J5) is not used. It is not included on all builds.

  • Page 16: External Overcurrent Protection Requirements

    Figure 4: Removing the Euro Block from Power Module 3. Note polarity; insert the two (2) power wires into the Euro Block. The IONPS-D-R1 has reverse polarity protection; if incorrectly wired, the IONPS-D-R1 will not power up. If incorrectly wired, change the wiring connection polarity and continue.

  • Page 17: Figure 5: Installing Power Wires

    Transition Networks, Inc. IONPS-D-R1 User Guide 4. Use the two (2) wire-securing screws to secure the power wires in the Euro Block. See Figure 5 below. Figure 5: Installing Power Wires 5. Connect the other end of the power wires to the main power source.

  • Page 18: Redundant (Failover) Chassis Power Module

    3. Ensure that the main power source is switched OFF. 4. Note polarity, insert the two (2) power wires into the Euro Block and secure them. The IONPS-D-R1 has reverse polarity protection; if incorrectly wired, the IONPS will not power up. Change the wiring connection polarity and continue.

  • Page 19: Power Module Redundancy

    9. Switch main power source ON — the LED on the redundant module should be lit. Power Module Redundancy The IONPS-D-R1, DC Power Module includes Instant failover (IFO) circuitry that provides the capability for the primary Power Module to power the chassis backplane while the Secondary Power Module is in ‘hot’ standby mode.

  • Page 20: Maintenance

    6. Carefully pull the power module from the chassis. 7. Locate the new power module. 8. Install the Euro Block containing the two (2) power wires. The IONPS-D-R1 has reverse polarity protection; if incorrectly wired, the IONPS-D-R1 will not power up. Change the wiring connection polarity and continue.

  • Page 21: Replacing The Fuse

    Transition Networks, Inc. IONPS-D-R1 User Guide Replacing the Fuse WARNING: Ensure that the IONPS-D-R1, DC power module has been disconnected from the external power source. Failure to observe this warning could result in an electrical shock or death. Caution: For continued protection against risk of fire, replace with same Type & Rating of fuse: 12A / 450VAC.

  • Page 22: Ionps-D-R1 Software Configuration

    In this configuration, the power supplies operate in an instant-fail-over mode. The IONPS-D-R1 supports a Dry Contact Relay (DCR) which can be enabled and disabled in the Entity Sensor Thresholds for "Temperature", "Voltage", "Power", and "Fan".
  • Page 23 Agent III C1|S23|L1D> Message: The message “There are 2 IONPS-D-R1 in chassis, you cannot set all of them to Secondary mode!” displays on the Web UI. The CLI lets you set master/slave mode, but without limitation. It allows setting both power supplies to slave.

  • Page 24: Set Power Supply Or Fan Stid

    Transition Networks, Inc. IONPS-D-R1 User Guide Set Power Supply or Fan STID Command: Set PS Sensor Threshold Parameters Syntax: set sensor stid=(notification/relation/severity/value) Sets the current IONPS-A-R1 Sensor Transaction ID (stid) settings. The STID is used for power Description: supply / sensor configuration via the set sensor stid command to define notification, relation, severity, and value parameters.
  • Page 25 Transition Networks, Inc. IONPS-D-R1 User Guide (Voltage) Agent III C1|S22|L1P1>go l1p=2 Agent III C1|S22|L1P2>set sensor stid=1 relation=lessOrEqual Agent III C1|S22|L1P2>set sensor stid=2 value=12900 Agent III C1|S22|L1P2>set sensor stid=3 severity=other Agent III C1|S22|L1P2>set sensor stid=4 value=14600 (Power) Agent III C1|S22|L1P2>go l1p=3 Agent III C1|S22|L1P3>set sensor stid=1 value=9...
  • Page 26 Description: Displays the current IONPS-D-R1’s Temperature, Voltage, Power, and Fan data. ION Power Supply SENSORID: The ION power supplies have four sensors: Temperature, Voltage, Power, and Fan. You can view a summary of the current status and settings by accessing the power slot- device level (e.g., go c=1 s=22 L1D) and performing a “show power config”...
  • Page 27 Transition Networks, Inc. IONPS-D-R1 User Guide Relay: Type: other Scale: units Precision: Value: Operation status: Units display: The data units displayed for Relay is in units(9) Installed: true State: disable Module type: disable Oper mode: master Fan-1: Type: Scale: units...
  • Page 28 Transition Networks, Inc. IONPS-D-R1 User Guide Command: Show Current Stack Status Syntax: stat Description: Display the current ION219 chassis stack configuration in terms of slots, devices and ports. Example: Agent III C1|S23|L1D>stat ION statck Chassis -- BPC IONMM Port 1...

  • Page 29: Ionps-D-R1 Cli Messages

    Transition Networks, Inc. IONPS-D-R1 User Guide IONPS-D-R1 CLI Messages Error: Cannot set IONPS-A/D-R1 operation mode on this card! Error: Cannot display card information on this module! Error: Software version of this card is too old, please upgrade it! Error: System is busy, please retry this command later!

  • Page 30: Power Supply Config - Web Method

    The ION Web interface allows configuration of the IONPS-D-R1 Power Supply’s Temperature Sensor, Voltage Sensor, Power Sensor, and Fan. 1. Select the IONPS-D-R1 Power Supply. The MAIN tab displays the current power supply information. The MAIN tab displays an overview of power supply model information, data on the sensor and fan(s), and Miscellaneous information.
  • Page 31 Transition Networks, Inc. IONPS-D-R1 User Guide The Temperature Sensor, Voltage Sensor, Power Sensor, and Fan configuration and status information is described in the following sections. 33707 Rev. A https://www.transition.com Page 31 of 50...

  • Page 32: Temperature Sensor Configuration

     Relay Enabled: select True to enable relay operation. The IONPS-D-R1 supports a Dry Contact Relay which can be enabled or disabled in the Entity Sensor Thresholds for "Temperature", "Voltage", "Power", and "Fan". See the example below for operating details.
  • Page 33 Transition Networks, Inc. IONPS-D-R1 User Guide  Relation: Less Than (<), Less Or Equal (≤), Greater Than (>), Greater Or Equal (>), Equal To (=), or Not Equal To (≠). Less Than: if the sensor value is less than the threshold value.
  • Page 34  When “Relay Enabled “is set to False, it means the Voltage Sensor readings of the IONPS-D-R1 in slot 22 [Box A] will not have any effect on the Dry Contact Relay alarm indications. No alarm will ever be set based on power supply voltage output.

  • Page 35: Voltage Sensor Configuration

    Transition Networks, Inc. IONPS-D-R1 User Guide Voltage Sensor Configuration The Threshold Settings table lists the threshold severity, relation, and comparison value for a sensor listed in the Entity-MIB Physical Table.  Voltage: displays the most recent voltage measurement obtained by the agent for this sensor in milliVolts.
  • Page 36 Transition Networks, Inc. IONPS-D-R1 User Guide o Equal To: if the sensor value is equal to the threshold value. o Not Equal To: if the sensor value is not equal to the threshold value. Indicates the relation between sensor value (SensorValue) and threshold value (SensorThresholdValue), required to trigger the alarm.

  • Page 37: Power Sensor Configuration

    Transition Networks, Inc. IONPS-D-R1 User Guide Power Sensor Configuration The Threshold Settings table lists the threshold severity, relation, and comparison value for a sensor listed in the Entity-MIB Physical Table.  Power: displays the most recent power measurement obtained by the agent for this sensor in Watts.
  • Page 38 Transition Networks, Inc. IONPS-D-R1 User Guide o Not Equal To: if the sensor value is not equal to the threshold value. Indicates the relation between sensor value (entSensorValue) and threshold value (ionEntSensorThresholdValue), required to trigger the alarm. When evaluating the relation, entSensorValue is on the left of SensorThresholdRelation, and SensorThresholdValue is on the right (e.g., entSensorValue ≥...

  • Page 39: Fan Configuration

    Transition Networks, Inc. IONPS-D-R1 User Guide Fan Configuration The IONPS-D-R1 fan control mode and speed can be set via the ION software. The IONPS-D-R1 uses an intelligent temperature monitor and fan controller.  Fan-1 Speed: displays the current actual (measured) fan speed in RPMs from 1000 - 9900 RPMs (e.g., 1304).
  • Page 40 Transition Networks, Inc. IONPS-D-R1 User Guide  Value: defines the value of the threshold (e.g., for a Major threshold severity selection, set a relation of Greater than or equal to 14000 as the requirement for notification). To correctly display or interpret this variable's value, you must also know the SensorType, SensorScale, and SensorPrecision.

  • Page 41: Upgrading The Ionps-D-R1

    IONPS-D-R1 finishes upgrading successfully, it will reboot itself and let the bootloader check the firmware again. If a valid firmware file is found, the IONPS-D-R1 will load the firmware and enter normal operation mode; otherwise the IONPS-D-R1 will continue entering the upgrade mode.

  • Page 42: Troubleshooting, Support, And Compliance Information

    Message: Primary power supply is at critical temperature: %d Secondary power supply is at critical temperature: %d Meaning: Notification that an IONPS-D-R1 is overheated. The Power Supply temperature trap “tnPowerSupplyEnvMonTemperatureNotif” was sensed. Recovery: 1. Message: Error: only IONPS-D-R1 can run this command! Meaning: You tried to enter an unsupported command.
  • Page 43 Meaning: You tried to configure both IONPS-D-R1 power supplies as “Secondary” devices. Recovery: 1. Review the “General Specifications” section. 2. Re-configure one of the two IONPS-D-R1 devices as the “Primary” supply (see chapter 3. IONPS-D-R1 Software Configuration on page 17. Message: Error: Relay state can only be set on IONPS-A! Meaning: You tried to enter an unsupported command for this device.

  • Page 44: Snmp Service And Function

    IONPS-D-R1 User Guide SNMP Service and Function When installed in an ION219 chassis, the IONPS-D-R1 can be managed with the SNMP protocol via the IONMM (the ION platform management unit). The IONPS-D-R1 supports SNMP V1, V2c, and V3. The IONPS-D-R1 implements these MIBs: ...

  • Page 45: Troubleshooting

    477. 3. When a problem or exception occurs, the IONPS-D-R1 sends the related Trap messages to the FP 3.0 Trap Server to report this event. You can launch the Trap Server in Focal Point 3.0 to capture the Trap message to get more details of the running IONPS-D-R1 status.

  • Page 46: Recording Information

    Transition Networks, Inc. IONPS-D-R1 User Guide Recording Information Gather information needed for the TN Tech Support Specialist, including information on the ID Sticker on the bottom of the IONPS-D-R1: Model Number: _______________________________ Serial Number: ________________________________ Firmware Rev. ______________________________ Related TN and 3...

  • Page 47: Limited Lifetime Warranty

    IONPS-D-R1 User Guide Limited Lifetime Warranty To return a defective product for warranty coverage, contact Transition Networks’ technical support department for a return authorization number. Transition Network's technical support department can be reached 24-hours a day by any of the following means:...

  • Page 48: Declaration Of Conformity

    Transition Networks, Inc. IONPS-D-R1 User Guide Declaration of Conformity Electrical Safety Warnings Electrical Safety IMPORTANT: This equipment must be installed in accordance with safety precautions. Elektrische Sicherheit WICHTIG: Für die Installation dieses Gerätes ist die Einhaltung von Sicherheitsvorkehrungen erforderlich. Elektrisk sikkerhed VIGTIGT: Dette udstyr skal installeres i overensstemmelse med sikkerhedsadvarslerne.

  • Page 49: Sicurezza Elettrica

    Transition Networks, Inc. IONPS-D-R1 User Guide Sicurezza elettrica IMPORTANTE: questa apparecchiatura deve essere installata rispettando le norme di sicurezza. Elektrisk sikkerhet VIKTIG: Dette utstyret skal installeres i samsvar med sikkerhetsregler. Segurança eléctrica IMPORTANTE: Este equipamento tem que ser instalado segundo as medidas de precaução de segurança.
