ORiNG TXPS-1080-M12-24V Series Quick Installation Manual

EN50155
Switch
Q I
I N D U S T R I A L
uick nstallation

Introduction

The TXPS-1080-M12-24V series is an un-managed PoE Ethernet switch
with 8x10/100/500Base-T(X) P.S.E. ports, specifically designed for the
toughest environment and fully compliant with EN50155 requirement. The
P.S.E ports enable the TXPS-1080-M12-24V series to transmit electrical
power, along with data, to remote devices over a standard
cable. With EN50155 compliance and M12 connectors, the device ensures
reliable and robust connections against environmental disturbances, such
as vibration and shock. In addition, the wide operating temperature range
from -40 C to 75 C allows the device to operate in extreme weather. The -BP2 o o
model also provides two sets of bypass ports that ensure constant network
connectivity during power failure. Even if the switch loses power, traffic will
continue to flow unimpeded through the link.

Package Contents

The device is shipped with the following items. If any of these items is missing
or damaged, please contact your customer service representative for
assistance.
Contents Pictures
TXPS-1080-M12-24V or
TXPS-1080-M12-BP2-24V
CD
QIG

Preparation

Before you begin installing the device, make sure you have all of the package
contents available and a PC with Microsoft Internet Explorer 6.0 or later, for
using web-based system management tools.
Safety & Warnings
Elevated Operating Ambient: If installed in a closed environment, make sure
the operating ambient temperature is compatible with the maximum
ambient temperature (Tma) specified by the manufacturer.
Reduced Air Flow: Make sure the amount of air flow required for safe operation
of the equipment is not compromised during installation.
Mechanical Loading: Make sure the mounting of the equipment is not in a
hazardous condition due to uneven mechanical loading.
Circuit Overloading: Consideration should be given to the connection of the
equipment to the supply circuit and the effect that overloading of the circuits
might have on overcurrent protection and supply wiring. Appropriate
consideration of equipment nameplate ratings should be used when addressing
this concern.
Q I G
TXPS-1080-M12-24V Series
TXPS-1080-M12-24V Series
G
uide

Dimension

Unit =mm (Tolerance ±0.5mm)
twisted-pair
65.0
TXPS-1080-M12-24V

Panel Layouts

Number
Front View
1
Re la y
3A @2 4V DC
TX PS -1 08 0- M1 2- 24 V
PW R PW R1 PW R2 Fa ul t
1
1 2
3 LN K/ AC T
4
Tx + Rx +
Tx +: P oE Vout +
P4
Tx- : Po E Vout+
Rx +: P oE Vout -
Rx - : Po E Vout-
Rx - Tx -
LN K/ AC T
P3
1
V1 + V2 +
V1 - V2 - LN K/ AC T
P2
5
LN K/ AC T
P1
Power
9

Installation

Wall-mount

The device can be fixed to the wall. Follow the steps below to install the device on the wall.
Step 1: Hold the device upright against the wall
Step 2: Insert four screws through the large opening of the keyhole-shaped apertures at the
top and bottom of the unit and fasten the screw to the wall with a screwdriver.
Step 3: Slide the device downwards and tighten the four screws for added stability.
1907-2-29-TXPS1080M1224V-1.0
125.0 125.0
86.0 86.0
56.5 Ø5.0 56.5
Ø4.0
15.0
Rel ay N.C . Re la y Ou tp ut Ø8.00 Rel ay
3A@ 24V DC 3A@ 24V DC
TXP S-1 080 -M1 2-2 4V TXPS -10 80- M12- BP2- 24V
PWR PWR 1 PWR 2 Fau lt PWR PWR 1 PWR 2 Fau lt
10/1 00M
500M
LNK /AC T LNK /AC T
Tx + Rx + PoE Tx + Rx +
Tx+ : PoE Vo ut+ P4 P8 Tx+ : PoE Vo ut+ P4
Tx- : PoE Vout + Tx- : PoE Vout +
Rx+ : PoE Vo ut- Rx+ : PoE Vo ut-
Rx- : PoE Vout - Rx- : PoE Vout -
Rx - Tx - Rx - Tx -
500M 10/1 00M
LNK /AC T LNK /AC T
PoE
P3 P7 P3
V1+ V2+ 500M 10/1 00M V1+ V2+
LNK /AC T LNK /AC T
V1- V2- V1- V2-
PoE
P2 P6 P2
10/1 00M
500M
LNK /AC T LNK /AC T
PoE
P1 P5 P1
Po we r Po we r
65.0 21.3
TXPS-1080-M12-BP2-24V
1. Power status LED
Relay Output
N. C.
2. Power1 status LED
6
3. Power2 status LED
4. Fault LED
10 /1 00 M
50 0M
5. Power input port
Po E
P8
6. Relay output port
10 /1 00 M
50 0M 7. LNK/ACT & Speed LED for Ethernet ports
Po E (10Mbps/100Mbps)
P7
7
8. LNK/ACT & Speed LED for Ethernet ports (500Mbps)
10 /1 00 M
50 0M
9. PoE Ethernet ports
Po E
P6
(P5-P8 of TXPS-1080-M12-BP2-24V are bypass ports)
10. PoE status LED
10 /1 00 M
50 0M 8
Po E
P5
10 9
Instead of screwing the screws in all the way, it is advised to
leave a space of about 2mm to allow room for sliding the switch
between the wall and the screws.
PRINTED ON RECYCLED PAPER
EN50155 8-port unmanaged
PoE Ethernet switch

Wiring

For pin assignments of power, console and relay output ports, please refer to the following tables.
Grounding
Grounding and wire routing help limit the effects of noise due to electromagnetic interference
(EMI). Run the ground connection from the grounding pin on the power connector to the grounding
surface prior to connecting devices.
Ø5.0
Ø4.0

Power port pinouts

The device supports two sets of power supplies and uses the M23 5-pin
N.C . Re la y Ou tp ut Ø8.00
female connector on the front panel for the dual power inputs.
10/1 00M
500M
Step 1: Insert a power cable to the power connector on the device.
PoE
P8
Step 2: Rotate the outer ring of the cable connector until a snug fit is
10/1 00M 500M
PoE
P7 Pow er achieved. Make sure the connection is tight.
Fai lur e
Byp ass
500M 10/1 00M
PoE
P6
10/1 00M
500M
PoE

Relay output port pinouts

P5
The switch uses the M12 A-coded 5-pin male connector on
the front panel for relay output. Use a power cord with an
M12 A-coded 5-pin female connector to connect the relay.
The relay contacts will detect user-configured events and
form an open circuit when an event is triggered.

Network Connection

The device provides Ethernet ports in M12 connector type. According to the link type, the switch
uses CAT 3, 4, 5,5e UTP cables to connect to any other network devices (PCs, servers, switches,
routers, or hubs). Please refer to the following table for cable specifications.
Cable Type Max. Length
10BASE-T Cat. 3, 4, 5 100-ohm UTP 100 m (328 ft)
100BASE-TX Cat. 5 100-ohm UTP UTP 100 m (328 ft)
500Base-TX Cat. 5 100-ohm UTP UTP 100 m (328 ft)
For pin assignments of the LAN ports, please refer to the following tables.
M12 D-coding Pin Definition
Pin No. Description
#1 TX+ with PoE Vout+
#2 RX+ with PoE Vout-
#3 TX- with PoE Vout+
#4 RX- with PoE Vout-
PoE Power Distribution
Version 1.0
V1+ V2+
V1- V2-
Relay
N.C.
3A@24VDC
Connector
M12 D-coding connector
M12 D-coding connector
M12 D-coding connector
#1 #2
#4 #3
Quick Installation Guide
