ORiNG IGS-1042GPA Quick Installation Manual

ORing Industrial Networking Corp.
GIGABIT
SWITCH
Q I
uick nstallation
I N D U S T R I A L
Introduction
IGS-1042GPA is an unmanaged Ethernet switch, w
ports and 2x100/1000Base-X SFP port. The optical network speed
be set by changing the settings of the DIP-Switch below. The wide operating
o o
temperature range from -40 C to 70 C can satisfy most of operating environment.
Therefore, the switch is one of the most reliable choices for Ethernet application.
Features
IGS-1042GPA provide 4x10/100/1000Base-T(X) ports
SFP port support 100Base-FX and 1000Base-X dual speed
Support auto-negotiation and auto-MDI/MDI-X
Support store and forward transmission
Support flow control
Rigid IP-30 housing design
DIN-Rail and wall mounting enabled
Power Connection Guide
PWR-2 1A@24V PWR-1 DC 12-48V
V2- V2+ V1- V1+
V- V+
Power
V+ V-
Supply
12-48 VDC
Warning
Device
+24V GND
Power
Supply
DIP Switch Function
DIP-1 DIP-2 Description
Power failure relay alarm disabled
OFF OFF
ON OFF PWR-1 failure, relay alarm enabled
OFF ON PWR-2 failure, relay alarm enabled
PWR-1 or PWR-2 failure,
ON ON
relay alarm enabled
Q I G
IGS-1042GPA
IGS-1042GPA
G
uide
Specifications
ith
4x10/100/1000Base-T(X)
ORing Switch Model
of
SFP port can
Physical Ports
10/100/1000Base-T(X) Port in
Rj45 Auto MDI/MDIX
100/1000Base-X SFP port
Technology
Ethernet Standards
MAC Table
Processing
LED Indicators
Power indicator
Fault indicator
10/100/1000Base-T(X) RJ45
port indicator
100/1000Base-X SFP port indicator
SFP Speed DIP-Switch
DIP-Switch 1/2 (port 6/5)
Relay Output DIP-Switch
DIP-Switch 1
DIP-Switch 2
Fault Contact
Relay
G
Frame Ground
Power
Redundant Input power
Power consumption(Typ.)
DIP Switch Select for
Overload current protection
Power Alarm Relay Output
Reverse polarity protection
Power
Physical Characteristic
Supply
12-48 VDC
Enclosure
Dimension (W x D x H)
Weight (g)
Environmental
Storage Temperature
Operating Temperature
Operating Humidity
Regulatory Approvals
EMI
EMS
Shock
Free Fall
Vibration
Safety
Warranty
1907-2-29-IGS1042GPA-1
IGS-1042GPA
4
2
IEEE 802.3 for 10Base-T
IEEE 802.3u for 100Base-TX and 100Base-FX
IEEE 802.3ab for 1000Base-T
IEEE 802.3z for 1000Base-X
IEEE 802.3x for Flow control
1K MAC addresses
Store-and-Forward
Green: Power LED x2
Amber: Indicate PWR1 or PWR2 failure
Green for port Link/Act.
Amber for 100Mbps indicator
Green for port Link/Act.
DIP-Switch (ON) : SFP speed setting to 100Mbps
DIP-Switch (OFF) : SFP speed setting to 1000Mbps
Power-1 failed warning : (ON) enable, (OFF) disable
Power-2 failed warning : (ON) enable, (OFF) disable
Relay output to carry capacity of 1A at 24 VDC
Dual DC inputs 12-48VDC on 6-pin terminal block
6.4W (power device not included)
Present
Present
IP-30
26.1 (W) x 94.9 (D) x 144.3 (H) mm (1.03 x 3.74 x 5.68 inches)
410 g
o o
-40 to 85 C (-40 to 185 F)
-40 to 70 C (-40 to 158 F) o o
5% to 95% Non-condensing
FCC Part 15, CISPR (EN55022) class A
EN61000-4-2 (ESD), EN61000-4-3 (RS), EN61000-4-4 (EFT), EN61000-4-5 (Surge),
EN61000-4-6 (CS), EN61000-4-8, EN61000-4-11
IEC60068-2-27
IEC60068-2-32
IEC60068-2-6
EN60950-1
5 years
PRINTED ON RECYCLED PAPER
Industrial Unmanaged Gigabit Switch
Practical Operation
IGS-1042GPA can be used in connecting several Ethernet devices like IP-Camera
or other Ethernet devices. In addition, there are two different power inputs at
terminal block to avoid interruption caused by power down.
power input fails, the backup power input will take over immediately to guarantee a
non-stop operation.
Connections of Ethernet devices
Front Panel
IGS-1042GPA
PW1 PW2 Fault
Power LED
6
DIP Switch Select
5
1000M 100M
6
SFP Link/Act LED
P5 P6
100/1000Base-X SFP Port
5
100/1000X
4
Green: Port Link/Act
3
Amber: 100Mbps indicator
2
DIP Switch Function
(SFP speed Selection)
1
DIP-1 DIP-2
Description
port 6 port 5
A
10/100/1000T
OFF 1000Mbps
ON 100Mbps
Quick Installation Guide
Version 1.1
When the primary DC
Power Fault LED
Gigabit LAN Port
