- Page 1 LED Squash Scoreboards Display Manual Rev 2 – 24 May 2010 ED-12365 Model SQ-2001...
- Page 2 – graphic, electronic, or mechanical, including photocopying, taping, or information storage and retrieval systems – without written permission of the publisher. ® ® All Sport and PanaView are trademarks of Daktronics, Inc. Other trademarks used in this manual are the property of their respective owners.
-
Page 3: Table Of Contents
Segmentation & Digit Designation ..................16 Schematics ..........................17 Replacement Parts ......................... 17 Daktronics Exchange and Repair & Return Programs ............. 17 Exchange Program ......................17 Repair & Return Program ..................... 18 Daktronics Warranty and Limitation of Liability ............19 Appendix A: Reference Drawings .................... - Page 5 Figure 1: Daktronics Drawing Label Reference Drawing: System Riser Diagram ................Drawing C-325405 Daktronics identifies manuals by the DD or ED number located on the cover page of each manual. For example, this manual would be referred to as ED-12365.
-
Page 6: Model Number
Power or signal jack Figure 3: Typical Label Power or signal plug for the opposite jack Following the Replacement Parts List is the Daktronics Exchange Policy and the Repair & Return Program. Refer to these instructions if replacing or repairing any display component. - Page 7 Daktronics scoreboards are differentiated by their model numbers and two-letter prefixes for each sport. Most Daktronics scoreboards also carry a two-number suffix that refers to the type of power supply and digit color. Refer to the following tables: Squash indoor scoreboards, 120 V, PanaView digits ®...
-
Page 9: Section 2: Specifications
Notes: 1) All displays require a 120 V AC, 15 A circuit. Displays with a 230 V A C power requirement are also available. 2) Signal wire must be minimum of 22 AWG with shield. Daktronics recommends W-1614. Model Dimensions:... -
Page 11: Section 3: Mechanical Installation
Be sure that the installation complies with local building codes. Note: Daktronics does not assume any liability for any installation derived from the information provided in this manual or installations designed and installed by others. - Page 12 (Figure 6). Figure 6: Wall Mounting Due to the variety of wall materials used in sports facilities, Daktronics cannot anticipate a user‟s individual installation needs or provide mounting hardware suitable for every installation.
-
Page 13: Section 4: Electrical Installation
Daktronics engineering staff must approve all changes or the warranty will be void. Each scoreboard features a 120 V AC power cord with a three-prong plug. Install a grounded receptacle near the equipment so that the power cord can easily reach it. - Page 14 (J-box) near the display. Refer to Drawing A-133369 in Appendix A for more information about signal wire connections. At a minimum, use a paired, 22 AWG shielded cable (Daktronics part number W- 1077) and connect the cable to a J-box at the control console end.
-
Page 15: Radio Settings
If a problem occurs that is not listed or that cannot be resolved using the solutions in the following table, contact Daktronics using the information provided in Section 5.8. Problem... -
Page 16: Section 5: Scoreboard Troubleshooting
Problem Possible Cause Solution/Items to Check Move the console 20-30 feet from the scoreboard and test again. Verify that both the console and scoreboard antennae are securely tightened and in a vertical position. Replace the radio receiver. Check that the scoreboard is receiving the correct 120 (or 230) V AC power (see Section 2). - Page 17 It may be necessary to run a wired signal connection instead. All Daktronics LED squash scoreboards are front-access scoreboards, meaning that internal electronic components and digits are reached by opening a face panel on the front of the display.
-
Page 18: Led Drivers
Secure the face panel to the display with the screws, then power up and test the display to see if changing the digit has resolved the problem. Figure 7: PanaView Digit Assembly In each scoreboard, one or more LED drivers perform the task of switching LEDs on and off. LED drivers are located inside of a driver enclosure. - Page 19 The scoreboards in this manual use 16-column drivers. Each driver has numerous connectors providing power and signal inputs and outputs to the scoreboard digits and indicators. The table below shows the function of these connectors for a 16-column driver: Connector # Function 1-16 Output to digits and indicators...
-
Page 20: Setting The Driver Address
If the driver status indicators do not appear to be working correctly, it may be necessary to replace the driver. Open the face panel as described in Section 5.2. Disconnect all connectors from the driver by squeezing together the locking tabs and pulling the connectors free. -
Page 21: Schematics
The Daktronics Exchange Program is a quick, economical service for replacing key components in need of repair. If a component fails, Daktronics sends a replacement part to the customer who, in turn, returns the failed component to Daktronics. This not only saves money but also decreases equipment downtime. -
Page 22: Repair & Return Program
In most circumstances, the replacement part will be invoiced at the time it is shipped. If the failed part or replacement part is not returned to Daktronics within 3 weeks of the ship date, Daktronics will assume that the customer is purchasing the replacement part and will send an invoice for the value of the new sale part. -
Page 23: Daktronics Warranty And Limitation Of Liability
201 Daktronics Drive, Dock E Brookings, SD 57006 Fax: 605-697-4444 The Daktronics Warranty and Limitation of Liability is located in Appendix B. The Warranty is independent of Extended Service agreements and is the authority in matters of service, repair, and display operation. -
Page 25: Appendix A: Reference Drawings
Schematic; LED Driver II Plate w/xfmr; 16 Column ........... Drawing A-115502 16 Column LED Driver II Specifications ..............Drawing A-126174 System Riser Diagram; Squash Scoreboard ............. Drawing A-133369 Electrical & Signal Spec, SQ-2001-13 ............... Drawing A-133613 Mechanical Specs, SQ-2001-13 ................Drawing A-133616... - Page 29 DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESS ADDED J45 FOR POWER AND SIGNAL DATE: WRITTEN CONSENT OF DAKTRONICS, INC. FOR RADIO INTERFACE COPYRIGHT 2015 DAKTRONICS, INC. 13 JUL 00 UPDATED SIGNAL WIRES, ADDED VIOLET...
- Page 33 THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DAKTRONICS, INC. DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESS WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2014 DAKTRONICS, INC. STANDARD INDOOR LED SCOREBOARDS MECHANICAL SPECS- SQ-2001-9 A VANBEMMEL...
- Page 35 Appendix B: Daktronics Warranty and Limitation of Liability...
- Page 37 WARRANTY AND LIMITATION OF LIABILITY This Warranty and Limitation of Liability (the “Warranty”) sets forth the warranty provided by Daktronics with respect to the Equipment. By accepting delivery of the Equipment, Purchaser agrees to be bound by and accept these terms and conditions. Unless otherwise defined herein, all terms within the Warranty shall have the same meaning and definition as provided elsewhere in the Agreement.
- Page 38 In no event shall Daktronics be liable to Purchaser or any other party for loss, damage, or injury of any kind or nature arising out of or in connection with this Warranty in excess of the purchase price of the Equipment actually delivered to and paid for by the Purchaser. The Purchaser’s remedy in any dispute under this Warranty shall be ultimately limited to the Purchase Price of the Equipment to the extent the Purchase Price has been paid.
