Summary of Contents for Daktronics TN-2016
- Page 1 Single-Court Outdoor LED Tennis Scoreboards Display Manual Rev 1 – 15 November 2012 DD2172229 Models TN-2016 TN-2605 TN-2601 TN-2606 TN-2603 TN-2607 TN-2604 201 Daktronics Drive PO Box 5128 Brookings, SD 57006-5128 Tel: 1-800-DAKTRONICS (1-800-325-8766) Fax: 605-697-4746 www.daktronics.com...
- Page 3 DD2172229 Product 1164 Rev 1 – 15 November 2012 Please fill in the information below to use for reference when calling Daktronics for assistance. Display Serial No. _______________________________________________________ Display Model No. _______________________________________________________ Date Installed ___________________________________________________________ DAKTRONICS, INC. Copyright 2011-2012 All rights reserved.
-
Page 5: Table Of Contents
Footings & Beams ........................7 Lifting the Scoreboard ......................7 Scoreboard Mounting ......................9 Scoreboard Mounting Using Vertical Spacers ............10 TN-2016 Mounting ........................ 10 Ad Panel Mounting....................... 11 Scoreboard Protective Devices .................... 12 Section 4: Electrical Installation ......................13 Installation Overview ...................... - Page 6 TNMC Maintenance ......................41 6.10 Replacement Parts List ......................41 Section 7: Daktronics Exchange and Repair & Return Programs ..........43 Exchange Program ........................ 43 Before Contacting Daktronics ..................43 Repair & Return Program ....................44 Shipping Address ......................44 Daktronics Warranty and Limitation of Liability .............
-
Page 7: Introduction
Section 1: Introduction This manual explains the installation of Daktronics single-court outdoor LED tennis scoreboards and provides details for maintenance and troubleshooting. For additional information regarding the safety, installation, operation, or service of this system, refer to the telephone numbers listed in Section 7. -
Page 8: Scoreboard Label
Scoreboard Label Serial and model numbers of a Daktronics scoreboard can be found on the ID label on the display as shown in Figure 1. Figure 1: Scoreboard ID Label Please list the model number, display serial number, and the date this display became operational in the blanks provided on the second page of this manual. -
Page 9: Daktronics Nomenclature
Power or signal jack Power or signal plug for the opposite jack Following the Replacement Parts List is the Daktronics Exchange Policy and the Repair & Return Program. Refer to these instructions if replacing or repairing any display component. Product Safety Approval Daktronics outdoor scoreboards are ETL listed and tested to CSA standard for outdoor use. -
Page 11: Specifications
120 / 240 V AC & Address* H 1'-9", W 2'-0", D 7" 30 lb 300 W 2.5 A TN-2016 (533 mm, 610 mm, 178 mm) (14 kg) (120 V AC only) H 1'-6", W 4'-0", D 6" 24 lb 300 W 2.5 A / 1.25 A... -
Page 13: Mechanical Installation
Lifting the Scoreboard Daktronics scoreboards are shipped equipped with eyebolts used to lift them. The eyebolts are located along the top of the cabinet for each scoreboard or scoreboard section. Daktronics scoreboards use " and "... - Page 14 Figure 5: Eyebolt Plane Load plane of the eyebolt as shown in Figure 5. Note: Daktronics assumes no liability for damages resulting from incorrect setup or lifting methods. Eyebolts are intended for lifting only. Do not attempt to permanently support the display by the eyebolts.
-
Page 15: Scoreboard Mounting
Scoreboard Mounting An inverted channel mounting installation uses C-channels; clip angles; -13" threaded rods; and " square nuts, hex nuts, lock washers, and optional spacers. Refer to Figure 6 and Drawing A-55101 in Appendix A. Figure 6: C-channel Mounting Method, Side View Mount the scoreboard as follows: Place the C-channel against the upper and lower rear flanges of the scoreboard. -
Page 16: Scoreboard Mounting Using Vertical Spacers
This will typically be scoreboards that are 8" deep. To create a uniform appearance for the overall display, Daktronics recommends using vertical spacers behind the scoreboard so that the front face of the display lines up evenly with the front face of the added component. -
Page 17: Ad Panel Mounting
Ad Panel Mounting The installation uses C-channels; clip angles; -13" threaded rods; and " square nuts, hex nuts, lock washers, and optional spacers. Refer to Figure 8 and Drawing A-52187 in Appendix A. Figure 8: Ad Panel Mounting with C-channel, Side View Mount the ad panel(s) as follows: Use the width of the beam to determine which hole combination to use for the bolts. -
Page 18: Scoreboard Protective Devices
Note: Some users install devices to protect the scoreboard from projectiles. Scoreboard protection devices not provided by Daktronics must be approved by Daktronics prior to installation. Failure to follow this approval procedure will void the scoreboard warranty. -
Page 19: Electrical Installation
It is the responsibility of the electrical contractor to ensure that all electrical work meets or exceeds local and national codes. Daktronics engineering staff must approve all changes or the warranty will be void. Installation Overview The diagram shown in Figure 9 illustrates a typical wireless setup between a single-court tennis scoreboard and the control system. -
Page 20: Power
The diagram shown in Figure 10 illustrates a typical wired setup between a single-court tennis scoreboard and the control system. Daktronics part numbers are shown in parentheses. Figure 10: Wired Installation Power Correct power installation is imperative for proper display operation. The subsections that follow give details of display power installation. -
Page 21: Grounding
Proper grounding is necessary for reliable equipment operation and protects the equipment from damaging destructive disturbances and lightning. Daktronics recommends a resistance-to-ground of 10 ohms or less. The electrical contractor performing the electrical installation can verify ground resistance. Daktronics Sales and Service personnel can also provide this service. -
Page 22: Power Connection
Figure 12: Driver Enclosure & Power Terminal Block Note: If a power receptacle is needed to operate the control console at the scoreboard for troubleshooting, Daktronics recommends that an installation electrician provides a 120 V outlet close to the disconnect box specifically for this purpose. -
Page 23: Power-On Self-Test (Post)
(silver) wire to the SHIELD terminal. Figure 14: Signal Surge Arrestor Card For signal cable, Daktronics recommends, as a minimum, single-pair, shielded cable, 22 AWG (part # W-1077). Two-pair shielded cable (part # W-1234) is preferred. When several single-court scoreboards are used together with a multi-court DakTennis™... -
Page 24: Fiber Optic
16-column driver. This method requires a signal converter between the All Sport console‟s scoreboard output and the fiber optic cable (not provided by Daktronics). Figure 15: Driver Fiber Connection Location Lightning Protection The use of a disconnect near the scoreboard to completely cut all current-carrying lines significantly protects the circuits against lightning damage. -
Page 25: Scoreboard Troubleshooting
If a problem occurs that is not listed or that cannot be resolved using the solutions in the following table, contact Daktronics using the information provided in Section 7. Problem... - Page 26 Problem Possible Cause Solution/Items to Check Check that the green POWER and amber RADIO IN RANGE indicators on the radio receiver in the scoreboard light up when the control console is powered on (see Section 5 .8). Keep the console between 20 to 1500 feet from the scoreboard.
- Page 27 Problem Possible Cause Solution/Items to Check Verify the power/signal connector on the back of the digit circuit board is secure (see Section 5 .3). Bad connection Verify power/signal interconnect(s) between scoreboard sections Scoreboard works, but some properly connected (see Section LEDs do not light or they ...
-
Page 28: Component Locations
Component Locations Component location varies with each scoreboard model. Refer to the component location drawings in Appendix A. Drivers and power and signal components are typically mounted inside the scoreboard behind a digit or access panel. There are several ways to locate the access panels: Power Warning Label Look for a power warning label toward the bottom of the access panel (Figure 11). -
Page 29: Replacing Digits
Replacing Digits LEDs are embedded in a circuit board that is mounted to the back of the digit panel, as shown in Figure 17. Do not attempt to remove individual LEDs. In the case of a malfunctioning LED or digit segment, replace the entire digit circuit board. Figure 17: Digit Assembly To replace a digit circuit board: Open the digit panel as described in Section ... -
Page 30: Replacing Indicators
Replacing Indicators As with smaller digits, indicator circuit boards are mounted to the back of the digit panel. Do not attempt to remove individual LEDs. To replace an indicator: Open the digit panel as described in Section 5 .3. Disconnect the power/signal connectors from the back of the indicator by squeezing together the locking tabs and pulling the connector free. -
Page 31: Led Drivers
LED Drivers The LED drivers perform the task of switching digits on and off within the scoreboard. LED drivers are located inside of a driver enclosure. Refer to Figure 18 to view the location and components of a driver enclosure. Driver component arrangement may vary by scoreboard model. -
Page 32: Replacing A Driver
When troubleshooting driver problems, three LEDs labeled DS1, DS2, and DS3 in Figure 19, provide the following diagnostic information: Color Function Operation Summary Green Power Steady on DS1 will be on and steady to indicate the driver has power. Signal RX Steady on DS2 will be on or blinking when the driver is or blinking... -
Page 33: Setting The Driver Address
Reconnect all power/signal connectors. Note: The connectors are keyed and will attach in one way only. Do not attempt to force the connections. Ensure the driver is set to the correct address (refer to Setting the Driver Address). Close and secure the digit panel, then power up and test the scoreboard to see if changing the driver has resolved the problem. -
Page 34: Radio Connections
Radio Connections To determine the settings for radio connections between the scoreboard and control console: Power off any radio-equipped consoles in the area. Cycle power to the scoreboard, and watch for the radio settings (Figure 21). Figure 21: Radio Settings in Game/Set Digits ... -
Page 35: Radio Interference
Enter the correct channel setting and sport code into the RC-100 handheld controller to test the radio connection. Channel Select Switch Figure 23: Channel Select Switch (Internal Receiver) For more information, refer to the Remote Control System RC-100 All Sport Operation Manual (ED-15133), available online at www.daktronics.com/manuals. Scoreboard Troubleshooting... -
Page 36: Radio Receiver (All Sport 5000)
(refer to the appropriate control console manual listed in Section 1 .1). Figure 25: Radio Receiver Switches For more information, refer to the Gen V Radio Installation Manual (ED-13831) or the Gen VI Radio Installation Manual (DD2362277), available online at www.daktronics.com/manuals. Scoreboard Troubleshooting... -
Page 37: Segmentation And Digit Designation
TN-2601 TN-2603 A-752372 TN-2605 TN-2604 A-179790 TN-2607 TN-2606 To Be Determined 5.11 Replacement Parts Refer to the following table for common Daktronics scoreboard replacement parts: Description Location Daktronics Part # J-Box, " phone, indoor Signal 0A-1009-0038 J-Box, " phone, outdoor... - Page 38 " phone 20' Signal W-1236 Signal cord; " phone 50' Signal W-1237 Signal cord; " phone 30' Signal W-1238 Signal cord; " phone 10' Signal W-1340 See Section 7 for information on Daktronics Exchange and Repair and Return program. Scoreboard Troubleshooting...
-
Page 39: Team Name Message Center Troubleshooting & Maintenance
Section 6: Team Name Message Center Troubleshooting & Maintenance IMPORTANT NOTES: 1. Always disconnect scoreboard power before doing any repair/maintenance work on the message centers. 2. Permit only qualified service personnel to access internal display electronics. 3. Disconnect power when not using the scoreboard. Display Overview Team name message centers (TNMCs) use amber, red, or white LEDs to display Home and Guest team names or messages of about 15 characters in place of vinyl captions (Figure 26). -
Page 40: Tnmc Troubleshooting Table
If a problem occurs that is not listed or that cannot be resolved using the solutions in the following table, contact Daktronics using the information provided in Section 7. Symptom/Condition Possible Remedy Check/replace the ribbon cables on the module. -
Page 41: Power & Signal Summary
Power & Signal Summary Reference Drawings: Schematic, OD, 3500 TNMC, 34mm, Red/Amb ........Drawing B-783938 Schematic, OD, 3500 TNMC, 34mm, Wht ..........Drawing B-906385 Schematic, OD, 3500, 46mm TNMC, Red/Amb ........Drawing B-923941 Schematic, OD, 3500 TNMC, 46mm, Wht ..........Drawing B-1036125 Refer to Drawings B-783938, B-906385, B-923941, or B-1036125 for detailed schematics about TNMC power and signal routing. -
Page 42: Component Locations & Access
Component Locations & Access Reference Drawings: Component Loc.; 34mm Red/Amb/Wht LED TNMC G4 ......Drawing B-975100 Component Loc.; 46mm Red/Amb/Wht LED TNMC G4 ......Drawing B-975635 Figure 27 illustrates the component locations of an 8x48-34mm display with all modules removed. This layout will be similar for 8x32-34mm cabinets as well. The 8x64-34mm cabinets require an additional power supply behind the sixth module. -
Page 43: Front Access
Standard Daktronics outdoor LED scoreboards are typically front-accessible, but some models may be ordered with rear service access. For that reason, TNMCs have been designed so that they may be accessed from both the front and rear. Front Access Loosen the latch fasteners on the front face the LED module using a 1/8"... -
Page 44: Tnmc Drivers
TNMC Drivers Reference Drawings: Specifications; Driver, MCAST, 4 Col ............Drawing A-793970 Address Details; Outdoor Tennis Scoreboards ........Drawing A-1054089 The display driver receives signal from the control console via a signal surge arrestor card and sends data to the modules. Refer to Section 6 .4 for more information on signal routing. The driver itself is detailed in Drawing A-793970 in Appendix A. -
Page 45: Replacing A Driver
Each module assembly is made up of a module housing (containing LEDs and the driver) and a louver assembly. Individual components such as louvers can be removed for service, but Daktronics recommends that the module be kept intact and that the entire assembly be sent in for repair or replacement. -
Page 46: Weather-Stripping
Figure 32: Module, Rear View Weather-stripping To ensure that the display is waterproof, weather-stripping has been installed around each module. It is important that the weather-stripping is attached properly at all times, or water may leak into the display and damage the components. When installing a new module, take note of the following points: ... -
Page 47: Tnmc Maintenance
Power Supply; 8.5-12.5V, 90-264V AC (white 46mm) A-2481 Cable; 20 pos, Ribbon, 36" W-1495 Cable; 20 pos, Ribbon, 18" W-1387 ® Electrical contact lubricant (CaiLube CH-1019 See Section 7 for information on Daktronics Exchange and Repair and Return program. TNMC Troubleshooting & Maintenance... -
Page 49: Daktronics Exchange And Repair & Return Programs
The Daktronics Exchange Program is a service for quickly replacing key components in need of repair. If a component fails, Daktronics sends a replacement part to the customer who, in turn, returns the failed component to Daktronics. This decreases equipment downtime. -
Page 50: Repair & Return Program
Repair & Return Program For items not subject to exchange, Daktronics offers a Repair & Return Program. To send a part for repair, follow these steps: Call or fax Daktronics Customer Service: Refer to the appropriate market number in the chart listed on the previous page. -
Page 51: Appendix A: Reference Drawings
Ad Panel Mounting ........................A-52187 Scoreboard Mounting ......................... A-55101 Beam Mounting Procedure; TN-2016-11 .................. A-175677 Beam Mounting; Side View, TN-2016-11 ................. A-175696 Beam and Footing Recommendations; TN-2016-11 ..............A-175784 System Riser; Tennis; Single Court w/ TNMC, AS 5000 ............A-177098 Schematic;... - Page 59 THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DAKTRONICS, INC. DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESSED WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2012 DAKTRONICS, INC. TENNIS SCOREBOARDS UPDATED BOARD AND TITLE BLOCK DATE: REMOVED PART NUMBER FROM THE RADIO SYSTEM RISER;...
- Page 63 THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DAKTRONICS, INC. DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESSED WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2012 DAKTRONICS, INC. TENNIS SCOREBOARDS SYSTEM RISER; TENNIS; INDOOR/OUTDOOR SINGLE COURT, RC-100 TJOHNSON...
- Page 68 DAKTRONICS HOME GUEST...
- Page 69 DAKTRONICS HOME GUEST...
- Page 81 Appendix B: Daktronics Warranty and Limitation of Liability Daktronics Warranty and Limitation of Liability...
- Page 83 WARRANTY AND LIMITATION OF LIABILITY This Warranty and Limitation of Liability (the “Warranty”) sets forth the warranty provided by Daktronics with respect to the Equipment. By accepting delivery of the Equipment, Purchaser agrees to be bound by and accept these terms and conditions. All defined terms within the Warranty shall have the same meaning and definition as provided elsewhere in the Agreement.
- Page 84 In no event shall Daktronics be liable to Purchaser or any other party for loss, damage, or injury of any kind or nature arising out of or in connection with this Warranty in excess of the purchase price of the Equipment actually delivered to and paid for by the Purchaser.
