Summary of Contents for Daktronics FB-2006
- Page 1 Generation III Stackable LED Scoreboards Display Manual ED-14091 Rev 5– 23 March 2012 Models FB-2006 MS-2016 MS-2014 MS-2017 MS-2015 MS-2018 201 Daktronics Drive PO Box 5128 Brookings, SD 57006-5128 Tel: 1-800-DAKTRONICS (1-800-325-8766) Fax: 605-697-4700 Web: www.daktronics.com...
- Page 3 – without written permission of the publisher. All Sport is a registered trademark of Daktronics, Inc. National Electric Code is a registered trademark of NFPA International.
-
Page 5: Table Of Contents
Segmentation and Digit Designation ............28 Lightening Protection .................. 28 Troubleshooting ................... 28 Replacement Parts ..................29 Daktronics Exchange and Repair and Return Programs ......30 Exchange Program................30 Repair & Return Program ..............31 Daktronics Warranty and Limitation of Liability ......... 32 Appendix A: Reference Drawings ............... -
Page 7: Introduction
This manual explains the installation and maintenance of the Stackable Outdoor Scoreboards. If you have other questions regarding the safety, installation, operation, or service of these systems, contact Daktronics. Customer Service Help Desk telephone numbers are listed on the cover page of this manual. -
Page 8: Daktronics Nomenclature
For example, this manual would be referred to as ED-14091. The serial and model numbers of a Daktronics scoreboard can be found on the ID label on the display. The label will be similar to the one shown in Figure 2. When calling Daktronics Customer Service, please have this information available to ensure that your request is serviced as quickly as possible. -
Page 9: Manual Overview
The label ‘‘A’’ on a drawing item typically denotes an assembly. An assembly can be a single circuit board or a collection of components that function together, usually mounted on a single plate or in a single enclosure. In addition, the following labeling formats might be found on various Daktronics drawings: ... -
Page 10: Product Overview
& guest score, period, foul information, player foul information, possession and bonus.. Model FB-2006 is a three-section display with powered clock/score and statistics sections as well as an unpowered caption panel. Each scoreboard on this series begins with a one- or two-line section, which means the section either has a single row or two rows of 10"... -
Page 11: Scoreboard Options
PENALTY for both teams and use permanent, 5" vinyl captions for the digit mounted directly below it. The caption section in model FB-2006 indicates DOWN, yards TO GO, BALL ON and QTR (quarter) for the digit section mounted directly below it as well. -
Page 12: Product Safety Approval
Product Safety Approval Daktronics stackable scoreboards are ETL-listed and tested to CSA standards. Contact Daktronics with any questions regarding the testing procedures. Introduction... -
Page 13: Specifications
Section 2: Specifications The following table lists all of the mechanical and electrical specifications, as well as power requirements for each model listed in this manual. Models are listed in alphanumeric order. Specifications... -
Page 15: Model Fb-2006-11/21
Model FB-2006-11/21 Amps per Driver Weight Digit Size Dimensions Maximum Line Number Model Section Uncrated Power (Height, Width, Depth) Wattage (Single (Crated) Digit Color Phase) Address FB-2006 Clock/Score H2'-4" 711 mm 60 lb 27 kg 10" 300 W 120 V AC 2.5 A... -
Page 16: Models Ms-2014 And Ms-2015
Models MS-2014 and MS-2015 Note: Signal wires must be a minimum of 22 AWG with shield. Amps per Dimensions Weight Digit Size Driver Maximum Line Model Section (Height, Width, Uncrated Power Number and Wattage (Single Depth) (Crated) Digit Color Address Phase) MS-2014 Clock/Score... -
Page 17: Model Ms-2016
Model MS-2016 Amps per Driver Weight Digit Size Dimensions Maximum Line Number Model Section Uncrated Power (Height, Width, Depth) Wattage (Single (Crated) Digit Color Phase) Address MS-2016 Clock H1'-2" 356 mm 45 lb 20 kg 10" Unpowered W9'-0" 2743 mm (86 lb 39 kg) -11 red -21 amber... -
Page 18: Model Ms-2017
Model MS-2017 Amps per Driver Weight Digit Size Dimensions Maximum Line Number Model Section Uncrated Power (Height, Width, Depth) Wattage (Single (Crated) Digit Color Phase) Address MS-2017 Score/Period H1'-2" 356 mm 75 lb 34 kg 10" 300 W 120 V AC 2.5 A W9'-0"... -
Page 19: Model Ms-2018
Model MS-2018 Amps per Dimensions Weight Digit Size Driver Maximum Line Model Section (Height, Width, Uncrated Power Number and Wattage (Single Depth) (Crated) Digit Color Address Phase) MS-2018 Clock/Score H2'-4" 914 mm 75 lb 34 kg 10" 300 W 120 V AC 2.5 A W9'-0"... -
Page 21: Mechanical Installation
The caption modules are attached to the top or bottom of a digit module with No.10 machine screws. Refer to Drawing A-130840. With Models MS-2014-11 and MS- 2018-11, attach the caption module to the top of the player/penalty module. With model FB-2006-11, attach the caption module to the top of the statistics module. Mechanical Installation... -
Page 22: Mounting Digit Modules
This manual addresses only beam mounting. Daktronics recommends using universal mounting struts, or channels. Use " bolts through the holes in both ends of the module frame. For displays with multiple digit modules, mount the lowest module first and work upward. - Page 23 MS-2018-11 or the statistics digit section in the FB-2006-11). Fasten the brackets to the modules by inserting 10-24 x 5/8" screws through the holes in each bracket and threading into the captivated nuts in the back of the module.
-
Page 25: Electrical Installation
Refer to the following sections for details of display power installation. Daktronics outdoor LED scoreboards have been designed for easy access to components, and the power and control signal hookup has been simplified. Front panels are removable to allow access to digits, cabling, and other electronic components. -
Page 26: Power Installation
The display system must be connected to an earth electrode installed at the display. Proper grounding is necessary for reliable equipment operation. It also protects the equipment from damaging electrical disturbances and lightning. The display must be properly grounded, or the warranty will be void. Refer to the schematic, Drawing A-177931, for information on where to connect the grounding wire. -
Page 27: Power And Signal Connection
V power receptacle. There is no 120 V receptacle in Generation III displays. If you want power to operate the control console at the scoreboard for troubleshooting, Daktronics recommends that you have the installation electrician provide a 120 V outlet close to the disconnect box specifically for this purpose. -
Page 28: Connections Between Sections
Figure 4 on the previous page illustrates the PCB and the terminal blocks. For signal cable, Daktronics recommends, as a minimum, single- pair, shielded cable, 22 AWG (Daktronics part number W-1077). Two-pair shielded cable... - Page 29 Power terminates at the power terminal block in the driver tray. Refer to Drawing A-177931 for wiring termination details. The signal wires from the scoreboard controller connect directly to the signal surge arrestor card, which is located on the lower left side of the master driver on the driver tray.
-
Page 31: Maintenance And Troubleshooting
3. Disconnect power when not using the scoreboard. Cabinet Specifications Cabinets for Daktronics outdoor LED scoreboards are constructed of heavy-gauge aluminum. Dimensions and weights for each model are listed in the chart in Section 2. Removable panels for digits and indicators and for component access are detailed in each model's component locations drawing, listed in Section 5.2 below. -
Page 32: Replacing A Digit
The digits are secured to the inside of the panel with fixed machine screws, spacers, and push nuts. Remove the nuts and lift the digit off the standoff screws. (The push nuts can be removed in several ways, but Daktronics recommends using a " nut driver.) Position a new digit over the screws and tighten the nuts. -
Page 33: Replacing A Driver
Output connectors 1 through 16 each have nine pins. Pin 7 provides power (hot) to the digit or indicators wired to that connector. The other eight pins provide switching connections. For the scoreboard to receive signal and function properly, the driver must be set to the correct address. -
Page 34: Segmentation And Digit Designation
Segmentation and Digit Designation Reference Drawing: Digit Service, Stackable Scoreboards ......Drawing A-156994 In each digit, certain LEDs always go on and off together. These groupings of LEDs are referred to as segments. The Digit Segments A-G detail on Drawing A-156994 shows which connector pin number is wired to each digit segment, as well as the wiring color code used throughout the display (illustrated at lower left on drawing). -
Page 35: Replacement Parts
Symptom/Condition Possible Cause Scoreboard will not light Console not connected or poor connection No power to control console No power to the scoreboard Garbled display Internal driver logic malfunction Control console malfunction Digit will not light Black wire to digit broken ... -
Page 36: Daktronics Exchange And Repair And Return Programs
Exchange Program The Daktronics Exchange Program is a service for quickly replacing key components in need of repair. If a component fails, Daktronics sends a replacement part to the customer who, in turn, returns the failed component to Daktronics. This decreases equipment downtime. -
Page 37: Repair & Return Program
Repair & Return Program For items not subject to exchange, Daktronics offers a Repair & Return Program. To send a part for repair, follow these steps: Call or fax Daktronics Customer Service: Refer to the appropriate market phone number in the chart on the previous page. -
Page 38: Daktronics Warranty And Limitation Of Liability
Brookings, SD 57006 Daktronics Warranty and Limitation of Liability The Daktronics Warranty and Limitation of Liability is located in Appendix C. The Warranty is independent of Extended Service agreements and is the authority in matters of service, repair, and display operation. -
Page 39: Appendix A: Reference Drawings
Layout View; MS-2017-11, G3 ............... A-213041 Component Locations; MS-2017-11/-21, G3 ..........A-214362 Beam and Footing Recommendations, MS-2017 .......... A-214370 Layout View; FB-2006-11, G3 ................ A-221063 Component Locations; FB-2006-11/-21, G3 ..........A-221085 Beam and Footing Recommendations, FB-2006-11/-21 ........ A-221087 Reference Drawings... - Page 69 Appendix B: Scoreboard Options Drawing Title Drawing Number Horn, 12 V DC w/Filter ..................B-111265 Caption Module Detail ..................A-130840 Scoreboard Options...
-
Page 73: Appendix C: Daktronics Warranty And Limitation Of Liability
Appendix C: Daktronics Warranty and Limitation of Liability Appendix C... - Page 75 WARRANTY AND LIMITATION OF LIABILITY This Warranty and Limitation of Liability (the “Warranty”) sets forth the warranty provided by Daktronics with respect to the Equipment. By accepting delivery of the Equipment, Purchaser agrees to be bound by and accept these terms and conditions. All defined terms within the Warranty shall have the same meaning and definition as provided elsewhere in the Agreement.
- Page 76 In no event shall Daktronics be liable to Purchaser or any other party for loss, damage, or injury of any kind or nature arising out of or in connection with this Warranty in excess of the purchase price of the Equipment actually delivered to and paid for by the Purchaser.
