- Page 1 Multi-Section DistaView LED Scoreboards Generation IV Display Manual Rev 1 – 04 April 2008 ED-16963 Models BA-1518-31 FB-1424-31 FB-2003-31 BA-1524-31 FB-1524-31 FB-2007-31 BA-3718-31 FB-2002-31...
- Page 2 – without written permission of the publisher. ® All Sport , DistaView are registered trademarks of Daktronics, Inc. Other trademarks used in this manual are the property of their respective owners.
-
Page 3: Table Of Contents
Segmentation and Digit Designation ............5-4 Lightning Protection .................. 5-5 Replacement Parts ..................5-5 Troubleshooting ..................5-5 Daktronics Exchange and Repair and Return Programs ......5-6 Exchange Program ................5-6 Repair and Return Program ..............5-7 How to reach us .................. 5-7... -
Page 5: How To Use This Manual
Reference drawings are grouped and inserted in alphanumeric order in the Appendix. Listed below are a number of drawing types commonly used by Daktronics, along with the information that each is likely to provide. System riser diagrams: overall system layout from control room to display, power and phase requirements. -
Page 6: Daktronics Nomenclature
For example, this manual would be referred to as ED-16963. The serial and model numbers of a Daktronics scoreboard can be found on the ID label on the display. The label will be similar to the one shown in Figure 2. When calling Daktronics Customer Service, please have this information available to ensure that your request is serviced as quickly as possible. -
Page 7: Product Overview
In addition, the following labeling formats might be found on various Daktronics drawings: “TB _ _” denotes a termination block for power or signal cable. “F _ _” denotes a fuse. -
Page 8: Model Names
Product Safety Approval Daktronics outdoor scoreboards are ETL and CE listed and tested to CSA standard for outdoor use. Contact Daktronics with any questions regarding testing procedures. - Page 9 The following table shows all of the mechanical specifications, circuit specifications and maximum power requirements for each model in this manual. Models are listed in alphanumeric order. Notes: Driver address setting can be configured using the J19 address plug. Also, the S1 dip switch is found in all Gen IV drivers. For more details see Section 5.4. Model Dimensions Weight...
- Page 10 Model Dimensions Weight Digit Size Maximum Power Amps Driver Height, Width, Depth Uncrated Wattage Number Digit Color Line Crated (Single Address Phase) H8'-0", W18'-0", D6" 400 lb 24" (610 mm) 200 W 120 V AC 1.7 A FB-1524-31 (2438 mm, 5486 mm, 152 mm) (181 kg) Red DistaView 845 lb...
-
Page 11: Scoreboard Protective Devices
Note: Some users install devices to protect the scoreboard from projectiles. Scoreboard protection devices not provided by Daktronics must be approved by Daktronics prior to installation. Failure to follow this approval procedure will void the scoreboard warranty. Daktronics makes available optional devices, including screens and netting, to help protect the scoreboard from damage due to normal ball impacts. - Page 12 Note: Daktronics strongly recommends using a spreader bar, or lifting bar, to lift the display. Using a spreader bar ensures that the force on the eyebolts is straight up, minimizing lifting stress. Lifting methods are shown in Figure 3 and in Drawing A-44548.
-
Page 13: Scoreboard Mounting
Installation Specifications, BA-1524 ......Drawing A-120972 Installation Specifications, BA-3718 ......Drawing A-126455 Installation Specifications, FB-2002 & FB-2003 ... Drawing A-128044 Daktronics Multi-Section DistaView LED scoreboards are typically mounted to steel beams. Beam-mounted installations require that a qualified engineer provide specifications for both the reinforced concrete footings and the steel support beams. -
Page 14: Ad Panel Mounting
Position the scoreboard at the front of the beams with the threaded rods extending from the rear of the clamps, straddling the beams. Raise the scoreboard section to the desired height. Slide clamping angles over the ends of the rods and loosely install the washers and nuts. -
Page 15: Power
Multi Driver Display ..........Drawing A-229706 Schematic; XFMR 16 Col, GEN IV, DistaView LED ..Drawing A-286657 Daktronics LED scoreboards have been designed for easy access to components and the power and control signal hookup has been simplified. Front panels are removable to allow access to the digits, cabling, and other electronic components. -
Page 16: Grounding
Daktronics recommends a resistance-to-ground of 10 ohms or less. The electrical contractor performing the electrical installation can verify ground resistance. Daktronics Sales and Service personnel can also provide this service. The display system must be connected to an earth electrode installed at the display. -
Page 17: Power And Signal Connection
W-1614) is preferred. For multi-driver displays, the power and signal are connected using inter-connection harness, which is installed at Daktronics. Refer to Drawing A-229706 for more information. For additional information on signal connection, refer to the All Sport 5000 Series control console operation manual, ED-11976. - Page 19 2. Permit only qualified service personnel to access internal display electronics. 3. Disconnect power when not using the scoreboard. Cabinets for the Daktronics multi-section DistaView LED scoreboards are constructed of heavy-gauge aluminum. Exact dimensions and weights for each model are listed in the chart in Section 2. Removable panels for digits and indicators and for component access are detailed in each model’s component locations drawing, listed...
- Page 20 In the Daktronics multi-section DistaView LED scoreboards, digits are attached to the hinged doors on the front of the scoreboard. Refer to the drawings listed above for more details on each model. Component location varies with each scoreboard model, but drivers and power and signal components are typically mounted inside the scoreboard behind an access panel or a digit.
- Page 21 Schematic; XMFR 16 Col, GEN IV, DistaView LED ..Drawing A-286657 Drawing A-229706 and A-286657 are schematic diagrams for the 16-column driver used in Daktronics multi-section DistaView LED scoreboards. The schematics include power and signal inputs and all wiring for the models described in this manual.
- Page 22 In the scoreboard, the LED drivers perform the task of switching digits on and off. Refer to Drawings A-154792 and A-134371. Each driver has 20 or more connectors providing power and signal inputs to the circuit and outputs to the digits and indicators.
-
Page 23: Replacement Parts
The same surges that may damage the scoreboard’s driver can also damage the console’s circuit. Refer to the following table for Daktronics scoreboard replacement parts. Description Daktronics Part No. -
Page 24: Exchange Program
You must send the problem part to Daktronics within 30 days. If you do not ship it to Daktronics within 30 working days from the invoice date, Daktronics assumes you are purchasing the replacement part outright with no exchange. - Page 25 For items not subject to exchange, Daktronics offers a Repair and Return Program. To send a part for repair, follow these steps.
- Page 27 Segmentation; 7 Segment Bar Digit ..........Drawing A-38532 Installation Specifications; FB-1424-31 ..........Drawing A-44412 Beam & Footing Recommendations, FB-XX24 ......... Drawing A-44514 Lifting Scoreboard ................Drawing A-44548 Ad Panel Mounting................Drawing A-52187 Installation Specifications, BA-1518 ..........Drawing A-55008 Installation Specifications, BA-1524 ..........Drawing A-120972 Installation Specifications, BA-3718 ..........
- Page 51 Eyebolts ......................ED-7244 Eyebolts...
- Page 53 Eyebolts Almost every display that leaves Daktronics is equipped with eyebolts for lifting the display. There are two standard sizes of eyebolts: ½″ and ⅝″. Load Increase Factor: The load increases as the lift angle (θ) decreases. The allowable load on the eyebolts also decreases with the lift angle due the bending stress on the eyebolts.
- Page 54 F. Eyebolts should never be painted or otherwise coated when used for lifting. Such coatings may cover potential flaws in the eyebolt. G. To attain the safe working loads listed for regular eyebolts, 90% of the thread length must be engaged. Copyright © 1996-2001 ED-7244 Daktronics, Inc. Rev. 4 – 14 March 2001...
- Page 55 Appendix C...
- Page 57 WARRANTY AND LIMITATION OF LIABILITY This Warranty and Limitation of Liability (the “Warranty”) sets forth the warranty provided by Daktronics with respect to the Equipment. By accepting delivery of the Equipment, Purchaser agrees to be bound by and accept these terms and conditions. All defined terms within the Warranty shall have the same meaning and definition as provided elsewhere in the Agreement.
- Page 58 In no event shall Daktronics be liable to Purchaser or any other party for loss, damage, or injury of any kind or nature arising out of or in connection with this Warranty in excess of the purchase price of the Equipment actually delivered to and paid for by the Purchaser.
