Page 1 LED Scoreboards Display Manual Rev 9 – 15 January 2013 ED-16711 Models BB-3101 BB-3115 SD-3101 BB-3103 BB-3121 SD-3102 BB-3105 BB-3123 SD-3103 BB-3107 BB-3125 BB-3114 BB-3142 201 Daktronics Drive PO Box 5128 Brookings, SD 57006-5128 Tel: 1-800-DAKTRONICS (1-800-325-8766) Fax: 605-697-4746 Web: www.daktronics.com...
Page 3 – graphic, electronic, or mechanical, including photocopying, taping, or information storage and retrieval systems – without written permission of the publisher. ® ® ® All Sport , ColorSmart , and UniView are trademarks of Daktronics, Inc. All others are trademarks of their respective companies.
Page 5: Table Of Contents
Segmentation and Digit Designation .................. 24 Schematics ..........................24 Replacement Parts List ......................25 Daktronics Exchange and Repair & Return Programs ............. 26 Exchange Program ......................26 Repair & Return Program ..................... 27 Daktronics Warranty and Limitation of Liability ............27 Section 6: Scoreboard Options ......................
Page 6 Mechanical Specification Drawings ................. 37 Appendix B: Electrical Specification Drawings ..................39 Appendix C: Scoreboard Options ......................41 Appendix D: Schematic Drawings ......................43 Appendix E: Additional Reference Drawings ..................45 Appendix F: Daktronics Warranty and Limitation of Liability ............47 Table of Contents...
Page 7: Introduction
Project-specific information takes precedence over any other general information found in this manual. Scoreboard Controllers Daktronics ColorSmart scoreboards are designed for use with the All Sport 5500 series ® control console. This console uses keyboard overlays (sport inserts) to control numerous sports and scoreboard models.
Page 8: Scoreboard Label
Scoreboard Label Serial and model numbers of a Daktronics scoreboard can be found on the ID label on the display, similar to that shown in Figure 1. Figure 1: Display ID Label Please list the model number, display serial number, and the date this display became operational in the blanks provided on the second page of this manual.
Page 9: Daktronics Nomenclature
Power or signal jack Power or signal plug for the opposite jack Following the Replacement Parts List is the Daktronics Exchange Policy and the Repair & Return Program. Refer to these instructions if replacing or repairing any display component. Product Safety Approval Daktronics ColorSmart scoreboards are ETL listed and tested to CSA standards, and CE- labeled for indoor use.
Page 11: Specifications
Section 2: Specifications The chart on the following pages details all of the mechanical specifications, circuit specifications, and power requirements for each display in this manual. Models are listed in alphanumeric order. Notes: 1) All displays require a 120 VAC, 15 A circuit. 2) Values in [Brackets] indicate scoreboards with Team Name Message Centers (TNMCs) or statistic displays with electronic captions.
Page 12 Dimensions: Uncrated Driver # Model Watts Amps Height, Width, Depth Weight & Address BB-3123-19 6'-0" H, 10'-0" W, 6" D 230 lb 400 W 3.3 A (1829 mm, 3048 mm, 152 mm) 104 kg [245 lb [500 W] [4.2 A] 111 kg] BB-3125-19 4'-0"...
Page 13: Mechanical Installation
Be sure that the installation complies with local building codes. Note: Daktronics does not assume any liability for any installation derived from the information provided in this manual or installations designed and installed by others.
Page 14: Scoreboard & Statistics Display Mounting
Appendix A. Figure 6: Wall Mounting Due to the variety of wall materials used in sports facilities, Daktronics cannot anticipate a user‟s individual installation needs or provide mounting hardware suitable for every installation. Choose a method of installation that will safely support the weight of the display.
Page 15: Shot Clock Mounting
Notes: 1) Daktronics recommends that two cables be used at each end of the scoreboard. 2) Cables and hardware must be specified by a licensed engineer. 3) Do not attach suspension hardware to ad panels – attach to top of scoreboard.
Page 17: Electrical Installation
It is the responsibility of the electrical contractor to ensure that all electrical work meets or exceeds local and national codes. Daktronics engineering staff must approve all changes or the warranty will be void. Installation Overview The diagram shown in Figure 7 illustrates a typical wired setup between a scoreboard and the control system.
Page 18: Power
Connect the scoreboard to earth ground. Proper grounding assures reliable equipment operation and protects the equipment against damaging electrical disturbances and lightning. Daktronics recommends a resistance-to-ground of 10 ohms or less. The electrical contractor performing the electrical installation can verify ground resistance. Daktronics Sales and Service personnel can also provide this service.
Page 19: Power-On Self-Test (Post)
(J-box) near the display. See also Drawing A-28124 in Appendix E and Drawing A-125316 in Appendix D. At a minimum, use a paired, 22 AWG shielded cable (Daktronics part # W-1077) and connect the cable to a dual "...
Page 20: Statistics Display Signal Connection
Refer to Figure 7 for more information about connecting the signal wiring that runs from the scoreboard to the controller. See also Drawing A-124688 in Appendix E. At a minimum, use a paired, 22 AWG shielded cable (Daktronics part # W-1077) and connect the cable to a dual "...
Page 21: Shot Clock Signal Connection
See also Drawings A-124688 and A-125415 in Appendix E. At a minimum, use a paired, 22 AWG shielded cable (Daktronics part # W-1077) and connect the cable to a dual " J-box at the control console end.
Page 22: Portable Shot Clock Installations
Portable shot clock model BB-3115 comes prewired with a twistlock male power inlet. A female plug is provided by Daktronics that must be attached to a power cord by the customer. For installations that use LED backstop light strips, refer to the LED End-of-Period Basketball Lighting Display Manual (ED-13652), available online at www.daktronics.com/manuals...
Page 23: Scoreboard Troubleshooting
If a problem occurs that is not listed or that cannot be resolved using the solutions in the following table, contact Daktronics using the information provided in Section ‎ 5 .8. Problem...
Page 24 Problem Possible Cause Solution/Items to Check Move the console 20-30 feet from the scoreboard and test again. Verify that both the console and scoreboard antennae are securely tightened and in a vertical position. Replace the radio receiver. Check that the scoreboard is receiving 120 VAC power.
Page 25: Component Access & Locations
Problem Possible Cause Solution/Items to Check Bad digit or driver (see solution on previous page) Incorrect sport code (see solution on previous page) Incorrect driver address (see solution on previous page) Another console’s radio signal could Wrong console controlling Scoreboard works, but some scoreboard be transmitting to the scoreboard.
Page 26: Replacing Digits
Replacing Digits LEDs are embedded in a circuit board that is mounted to the back of a digit panel, as shown in Figure 14. Do not attempt to remove individual LEDs. In the case of a malfunctioning board, replace the entire digit circuit board. To replace a digit circuit board: Open the digit panel as described on the previous page.
Page 27: Led Drivers
LED Drivers In each scoreboard, one or more LED drivers perform the task of switching LEDs on and off. LED drivers are located inside of a driver enclosure. Refer to Figure 15 to view the location and components of a ColorSmart driver enclosure. Figure 15: Driver Enclosure Location &...
Page 28 Connector No. Function 1-16 Output to digits and indicators Control signal Control for horn Address (DIP switch package) TNMC (DIP switch package) Power Refer to Drawing A-284554 in Appendix E for detailed driver pin out/switch specifications. The table below shows the function of the primary connectors for a 4-column driver: Connector No.
Page 29: Replacing A Driver
Figure 16: Driver Status Indicators Replacing a Driver If the driver status indicators do not appear to be working correctly, it may be necessary to replace the driver. Open the digit panel or scoreboard face panel as described in Section ‎ 5 .2. Disconnect all connectors from the driver by squeezing together the locking tabs and pulling the connectors free.
Page 30: Setting The Driver Address
Setting the Driver Address Since the same LED drivers can be used for many scoreboard models, each driver must be set to receive the correct signal input, or address, for the model being used. Addresses are set through the S1 DIP switch on the driver (Figure 17) using a pen or small, pointed object. Figure 17: Driver Address DIP Switch (ColorSmart Driver) When setting the driver address, first refer to the specifications table in Section 2 to find the correct...
Page 31: Replacement Parts List
Replacement Parts List Refer to the following table for Daktronics scoreboard replacement parts. Description Daktronics Part # Horn, 120V with capacitor 0A-1152-0332 Main clock, start/stop switch 0A-1166-0003 Shot clock, start/stop switch 0A-1196-0031 LED driver, MCAST, 16-column 0P-1388-0100 LED driver, MCAST, 4-column 0P-1388-0101 Digit, 13"...
Page 32: Daktronics Exchange And Repair & Return Programs
The Daktronics Exchange Program is a service for quickly replacing key components in need of repair. If a component fails, Daktronics sends a replacement part to the customer who, in turn, returns the failed component to Daktronics. This decreases equipment downtime.
Page 33: Repair & Return Program
Repair & Return Program For items not subject to exchange, Daktronics offers a Repair & Return Program. To send a part for repair, follow these steps: Call or fax Daktronics Customer Service: Refer to the appropriate market number in the chart listed on the previous page.
Page 35: Scoreboard Options
Visual Horn Indicator (VHI) In addition to the horn, Daktronics offers a visual horn indicator (VHI) that lights up when the buzzer sounds. To install a VHI, users must tap into the existing horn wiring to provide power and signal.
Page 36: Time Outs Left (Tol) Digits
Changeable Captions Team name and statistics caption kits contain hardware for one caption only and consist of an upper caption retainer, a lower caption retainer, a changeable caption panel and screws. The standard HOME and GUEST captions are applied directly to the face of the scoreboard. Team name captions are on changeable panels that fit into retainers mounted above and below the standard captions.
Page 37: Tnmc & Electronic Caption Troubleshooting & Maintenance
Section 7: TNMC & Electronic Caption Troubleshooting & Maintenance IMPORTANT NOTES: 1. Always disconnect scoreboard power before doing any repair/maintenance work on the message centers. 2. Permit only qualified service personnel to access internal display electronics. 3. Disconnect power when not using the scoreboard. Display Overview Team Name Message Centers (TNMCs) are programmable LED displays that allow users to show custom Home and Guest names or messages of ~15 characters on the scoreboard in...
Page 38: Initialization Information At Startup
If a problem occurs that is not listed or that cannot be resolved using the solutions in the following table, contact Daktronics using the information provided in Section ‎ 5 .8. Symptom/Condition...
Page 39: Power & Signal Summary
Power & Signal Summary Reference Drawings: Address Table; Driver- MCAST- TNMC DIP Switch ....... Drawing A-284773 Schematic: Multicast TNMC 3/4" (.75) ........... Drawing B-296394 Refer to Drawing B-296394 in Appendix D for detailed schematics about display power and signal routing. Display signal routing can be summarized as follows: ®...
Page 40: Modules
Modules Display modules consist of LEDs embedded in a circuit board. One or more circuit boards are mounted to the back of a display face panel. Do not attempt to remove individual LEDs. In the case of malfunctioning LEDs, replace the entire module circuit board. Replacing Modules Access the internal components as described in Section ‎...
Page 41: Display Maintenance
Part Number Module; 8x16, Amber 0P-1186-0112 Power Supply; 5V @ 10A, 85-264VAC A-1568 Cable; 18 pos, Ribbon, 6" W-1320 See Section ‎ 5 .8 for information on Daktronics Exchange and Repair and Return program. TNMC & Electronic Captions Maintenance & Troubleshooting...
Page 43: Appendix A: Mechanical Specification Drawings
Appendix A: Mechanical Specification Drawings Drawing Title Drawing Number Mechanical Spec- MCAST- BB-3101 ..................A-282951 Mechanical Spec- MCAST- BB-3103 ..................A-282953 Mechanical Spec- MCAST- BB-3105 ..................A-282955 Mechanical Spec- MCAST- BB-3107 ..................A-282957 Mechanical Spec- MCAST- BB-3114 ..................A-282959 Mechanical Spec- MCAST- BB-3115 ..................A-282961 Mechanical Spec- MCAST- BB-3121 ..................
Page 48 260 LBS (118 KG) 3. SEE DRAWING 1237-R10A-148644 FOR OPTIONAL PERMANENT SUSPENSION OF THE SCOREBOARD. TUFFSPORT COLORSMART & UNIVIEW ARE TRADEMARKS OF DAKTRONICS 4. THE SCOREBOARD IS SHOWN WITH THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DAKTRONICS, INC. DRAWING ARE CONFIDENTIAL AND PROPRIETARY.
Page 57 SHOTS SHOTS SAVES SAVES TO GO CURRENT SET LAST SET SCORE MATCH SCORE daktronics HOME GUEST PERIOD FOULS PLYR FOUL FOULS...
Page 59: Appendix B: Electrical Specification Drawings
Appendix B: Electrical Specification Drawings Drawing Title Drawing Number Electrical and Signal Spec- MCAST- BB-3101/BB-3102 ............A-282952 Electrical and Signal Spec-MCAST-BB-3103/BB-3104 ............A-282954 Electrical and Signal Spec-MCAST-BB-3105/BB-3106 ............A-282956 Electrical and Signal Spec-MCAST-BB-3107/BB-3108 ............A-282958 Electrical and Signal Spec- MCAST- BB-3114 (prior to Sept 2011) ......... A-282960 Electrical and Signal Spec- MCAST- BB-3115 (prior to Dec 2012) ..........
Page 61 HOME GUEST PERIOD HOME GUEST PERIOD...
Page 62 HOME GUEST PERIOD FOULS PLAYER FOUL FOULS T.O.L. T.O.L. SCORE MATCH SCORE HOME GUEST PERIOD PERIOD FOULS PLAYER FOUL FOULS T.O.L. T.O.L. SCORE MATCH SCORE...
Page 63 HOME GUEST PERIOD HOME GUEST PERIOD...
Page 64 HOME GUEST PERIOD FOULS T.O.L. PLAYER FOUL T.O.L. FOULS SCORE MATCH SCORE daktronics HOME GUEST PERIOD FOULS T.O.L. PLAYER FOUL T.O.L. FOULS SCORE MATCH SCORE...
Page 66 THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DAKTRONICS, INC. DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESSED WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2013 DAKTRONICS, INC. TUFF SPORT COLORSMART SCOREBOARDS ELECTRICAL AND SIGNAL SPEC- MCAST- BB-3115 JFELDHA...
Page 67 HOME GUEST PERIOD daktronics HOME GUEST PERIOD...
Page 71 HOME PERIOD GUEST HOME PERIOD GUEST...
Page 72 HOME GUEST PERIOD FOULS T.O.L. PLAYER FOUL T.O.L. FOULS SCORE MATCH SCORE daktronics HOME GUEST PERIOD FOULS T.O.L. PLAYER FOUL T.O.L. FOULS SCORE MATCH SCORE...
Page 73 HOME GUEST PERIOD FOULS PLYR FOUL FOULS daktronics HOME GUEST PERIOD FOULS PLYR FOUL FOULS Patent Pending...
Page 74 DAKTRONICS DAKTRONICS HAZARDOUS VOLTAGE AT EXPOSED TERMINALS. DISCONNECT POWER BEFORE SERVICING. SIGNAL IN SIGNAL OUT CUR. LOOP RED BLK SIGNAL UNIVIEW DIGIT TECHNOLOGY US PATENT # 6,631,575 B1 ADDED NOTE #4 & #5 DATE: 4 JAN 13...
Page 75 THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DAKTRONICS, INC. DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESSED WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2013 DAKTRONICS, INC. TUFF SPORT COLORSMART SCOREBOARDS ELECTRICAL AND SIGNAL MCAST, BB-3115 CHAMILT...
Page 77: Appendix C: Scoreboard Options
Appendix C: Scoreboard Options Drawing Title Drawing Number Backstop Mounting Suggestions ....................A-91230 Wiring for Shot Clock on Portable Backstop ................A-98293 Advertising/Identification Display Mounting ................A-147668 Suspension Lift Eye Installation ....................A-148644 12V DC Horn Option Installation ....................A-148960 T.O.L.
Page 88 SIGNAL...
Page 91: Appendix D: Schematic Drawings
Appendix D: Schematic Drawings Drawing Title Drawing Number Schematic; Dual 1/4" Phone J-box w/ Shunt Jack ..............A-125316 Schematic: BB-2114 / BB-3114- 120VAC (prior to Nov 2011) ..........B-202715 Schematic; 2-Driver, Color Smart ..................... B-283553 Schematic; 3-Driver, Color Smart ..................... B-283857 Schematic- MCAST Game/Shot Clock (prior to Dec 2012) ............
Page 103: Appendix E: Additional Reference Drawings
Appendix E: Additional Reference Drawings Drawing Title Drawing Number Signal Connection; Installation ....................A-28124 Segmentation, 7 Segment Bar Digit ................... A-38532 Address Table, 1 Through 128 ....................A-115078 4 Column LED Driver II; Specifications ..................A-123783 Block Diagram: AS5000 BB- VB & WR #1 ................A-124686 Block Diagram: AS5000 BB- VB &...
Page 119: Appendix F: Daktronics Warranty And Limitation Of Liability
Appendix F: Daktronics Warranty and Limitation of Liability Daktronics Warranty and Limitation of Liability...
Page 121 WARRANTY AND LIMITATION OF LIABILITY This Warranty and Limitation of Liability (the “Warranty”) sets forth the warranty provided by Daktronics with respect to the Equipment. By accepting delivery of the Equipment, Purchaser agrees to be bound by and accept these terms and conditions. All defined terms within the Warranty shall have the same meaning and definition as provided elsewhere in the Agreement.
Page 122 In no event shall Daktronics be liable to Purchaser or any other party for loss, damage, or injury of any kind or nature arising out of or in connection with this Warranty in excess of the purchase price of the Equipment actually delivered to and paid for by the Purchaser.
