  • Page 1 The Traveler Series : Wanderer 30A PWM Solar Charge Controller Version 1.0...
  • Page 2 Important Safety Instructions Please save these instructions. This manual contains important safety, installation, and operating instructions for the charge controller. The following symbols are used throughout the manual: Indicates a potentially dangerous condition. Use extreme caution WARNING when performing this task Indicates a critical procedure for safe and proper operation of the CAUTION controller...
  • Page 3 Battery Safety let the positive (+) and negative (-) terminals of the battery touch each other. Use only sealed lead-acid, flooded, gel or lithium batteries which must be deep cycle. Explosive battery gases may be present while charging. Be certain there is enough ventilation to release the gases.

  • Page 4: Table Of Contents

    Table of Contents General Information Optional Components Identification of Parts Installation Mounting Recommendations Operation LED Indicators System Status Troubleshooting Maintenance Fusing Technical Specifications Electrical Specifications Battery Charging Parameters Dimensions...

  • Page 5: General Information

    General Information The Wanderer is an advanced charge controller for off-grid solar applications and can be used with a 12V battery or battery bank. Integrating highly efficient PWM charging, the Wanderer increases battery life and improves system performance. The controller comes equipped with fully comprehensive self-diagnostics and electronic protection functions to prevent damage from installation mistakes or system faults.
  • Page 6 Bulk Charge: This algorithm is used for day to day charging. It uses 100% of available solar power to recharge the battery and is equivalent to constant current. Boost Charge: When the battery has charged to the Boost voltage set-point, it undergoes an absorption stage which is equivalent to constant voltage regulation to prevent heating and excessive gassing in the battery.

  • Page 7: Optional Components

    The BT-1 Bluetooth module is a great addition to any Renogy charge controllers with a RS232 port and is used to pair charge controllers with the Renogy BT App. After pairing is done you can monitor your system and change parameters directly from you cell phone or tablet.

  • Page 8: Identification Of Parts

    Identification of Parts Key Parts 1. Battery Select Button 2. Battery Type Indicator 3. Battery Indicator 4. PV Indicator 5. Remote Temperature Sensor Port (optional accessory) 6. PV Terminals 7. Battery Terminals 8. RS-232 Port (optional accessory) Installation WARNING Connect battery terminal wires to the charge controller FIRST then connect the solar panel(s) to the charge controller.
  • Page 9 Battery Solar Panel...
  • Page 10 Bluetooth Module Communication (optional) Temperature Sensor (optional, not polarity sensitive) Place the sensor close to the battery...

  • Page 11: Operation

    Operation After connecting the battery to the charge controller, the controller will turn on automatically. Operation of this controller is very simply. Users set the battery type, and leave the rest of the work to the charge controller. Setting Battery Type Simply hold the gray button for approximately 7 seconds until the LED flashes.

  • Page 12: System Status Troubleshooting

    System Status Troubleshooting Description Troubleshoot Use a multi-meter to verify the rated battery voltage. Battery is low-voltage Disconnect any loads connected to the battery to allow it to charge. Use a multi-meter to check the voltage of the battery. Make Battery is over-voltage sure the battery voltage is not exceeding the rated specification of the charge controller.

  • Page 13: Maintenance

    Maintenance For best controller performance, it is recommended that these tasks be performed from time to time. 1. Check that controller is mounted in a clean, dry, and ventilated area. 2. Check wiring going into the charge controller and make sure there is no wire damage or wear. 3.

  • Page 14: Technical Specifications

    Technical Specifications Electrical Specifications Description Parameter Nominal system voltage 12 VDC Rated Charge Current Max. PV Input Voltage 25 VDC Self-Consumption ≤10mA Temp. Compensation -3mV/°C/2V Max. Terminal Size 10mm 8 AWG Working Temperature -35°C to +45°C / -20°F to 113°F Net Weight 0.29 kg 0.65 lb.

  • Page 15: Dimensions

    * Battery charging parameters in LI mode can be programmed using Renogy BT App. ** Default charging parameters in LI mode are programmed for 12.8V LFP battery. Before using Wanderer to charge other types of lithium battery, set the parameters according to the suggestions from battery manufacturer.
  • Page 16 2775 E. Philadelphia St., Ontario, CA 91761 1-800-330-8678 Renogy reserves the right to change the contents of this manual without notice.
