ML501 QuickStart
June 2010
www.BDTIC.com/XILINX
© Copyright 2010 Xilinx

Advertisement

loading

Related Manuals for Xilinx ML501

Summary of Contents for Xilinx ML501

  • Page 1 ML501 QuickStart June 2010 www.BDTIC.com/XILINX © Copyright 2010 Xilinx...
  • Page 2 Overview  ML501 Setup  Bootload  Applications – Slideshow – Web Server – Simon – Board Diagnostics – USB Keyboard – My ACE – Ringtone  References www.BDTIC.com/XILINX Note: This presentation applies to the ML501...
  • Page 3 – BRAM – External Memory Controller (EMC) • ZBT SRAM – Networking – UART – Interrupt Controller – System ACE CF Interface – GPIO (IIC, LEDs and LCD) – Timer – PLB Arbiter www.BDTIC.com/XILINX Note: Presentation applies to the ML501...
  • Page 4 ML501 Setup  Connect the Xilinx Platform Cable USB to the ML501 board  Connect the RS232 null modem cable to the ML501 board www.BDTIC.com/XILINX Note: Presentation applies to the ML501...

  • Page 5: Hardware Setup

    Hardware Setup  The ML501 uses a DVI video interface  Connect a DVI monitor  Use a DVI/VGA adapter to connect a VGA monitor – http://www.belkin.com www.BDTIC.com/XILINX Note: Presentation applies to the ML501...
  • Page 6 Hardware Setup  USB Keyboard – www.dell.com www.BDTIC.com/XILINX Note: Presentation applies to the ML501...
  • Page 7 Factory CompactFlash  The CompactFlash shipped with the ML501 board has the following ace files preloaded: www.BDTIC.com/XILINX Note: Presentation applies to the ML501...
  • Page 8 ML501 Setup  Insert the Factory CompactFlash into the ML501 board (1)  Set the DIP switches as seen here (00010101) (2)  Power-up the ML501 board www.BDTIC.com/XILINX Note: Presentation applies to the ML501...
  • Page 9 ML501 Setup  Set ML501 Jumper for GMII – Set both J40 to positions 1-2 (as shown) www.BDTIC.com/XILINX Note: Presentation applies to the ML501...
  • Page 10 ML501 Setup  Start the Terminal Program: www.BDTIC.com/XILINX Note: Presentation applies to the ML501...
  • Page 11  Refer to ml501_overview_setup.ppt for details on: – Software Requirements – ML501 Board Setup – Equipment and Cables – Software – Network  Terminal Programs – This presentation requires the 9600-8-N-1 Baud terminal setup www.BDTIC.com/XILINX Note: Presentation applies to the ML501...
  • Page 12 Bootload  The system_bootload.ace loads: www.BDTIC.com/XILINX Note: Presentation applies to the ML501...
  • Page 13  The terminal window also reflects the bootload application  Use the left/center/right buttons to choose an application or type a number in the terminal window  After each demo, push the SysACE reset to return to bootload www.BDTIC.com/XILINX Note: Presentation applies to the ML501...
  • Page 14 Slideshow  Type 1, to launch the slideshow application in Configuration 1  The slideshow loads the presentation into memory then presents it www.BDTIC.com/XILINX Note: Presentation applies to the ML501...
  • Page 15 Slideshow  The slideshow app will present a series of slides on the Monitor: www.BDTIC.com/XILINX Note: Presentation applies to the ML501...

  • Page 16: Web Server

     Type 2, to launch the web server application in Configuration 2 – Note: You may need to turn off your browser's proxy and specify a direct connection to the Internet in your browser options www.BDTIC.com/XILINX Note: Host IP is 1.2.3.9, subnet mask is 255.0.0.0; Ethernet conn. is 100 Full Duplex...
  • Page 17 Web Server  In your web browser, enter http://1.2.3.4:8080/index.html www.BDTIC.com/XILINX...
  • Page 18 Simon  Type 3, to launch the Simon application in Configuration 3 www.BDTIC.com/XILINX Note: Presentation applies to the ML501...

  • Page 19: Usb Keyboard

    USB Keyboard  Type 5, to launch the USB Keyboard application in Configuration 5 – Type ML501 and view results: www.BDTIC.com/XILINX Note: Presentation applies to the ML501...
  • Page 20 My ACE  Type 6, to launch the My ACE application in Configuration 6 www.BDTIC.com/XILINX Note: Presentation applies to the ML501...
  • Page 21 Ringtone  Type 7, to launch the Ringtone application in Configuration 7  Press any key then press 1-7 to play a simple melody www.BDTIC.com/XILINX Note: Presentation applies to the ML501...
  • Page 22 References www.BDTIC.com/XILINX...
  • Page 23 References  Virtex-5 – Virtex-5 FPGA Family http://www.xilinx.com/products/virtex5/index.htm  Platform Studio – Embedded Development Kit (EDK) Resources http://www.xilinx.com/tools/platform.htm – Embedded System Tools Reference Manual http://www.xilinx.com/support/documentation/sw_manuals/xilinx12_1/est_rm.pdf – EDK Concepts, Tools, and Techniques http://www.xilinx.com/support/documentation/sw_manuals/xilinx12_1/edk_ctt.pdf www.BDTIC.com/XILINX...
  • Page 24 Documentation www.BDTIC.com/XILINX...
  • Page 25 Documentation  ML501 Documentation – ML501 Overview http://www.xilinx.com/ml501 – ML501 Evaluation Platform User Guide – UG226 http://www.xilinx.com/support/documentation/boards_and_kits/ug226.pdf – ML501 Getting Started Tutorial – UG228 http://www.xilinx.com/support/documentation/boards_and_kits/ug228.pdf – ML501 Reference Design User Guide – UG227 http://www.xilinx.com/support/documentation/boards_and_kits/ug227.pdf www.BDTIC.com/XILINX...
