Eurocave MODULOTHEQUE Assembly Instructions Manual page 5

C
ORNER
GB
FASTENINGS
ax8
TOOL REQUIRED
PARTS
A
B
Cx2
4
P
EDESTAL
Warning:Take the size of the corner module into account before positioning the assembly.
1
+ 2 foot supports for the 1st module (MV9)
2
3
4
5
6
7
M (MV17)
ODULE
A
1
pedestal module and just 2 for every other
abutting pedestal) in the grooves provided and
align the foot support holes with those in the
wooden pedestal (A).Tighten the 2 screws (a) in
a
each foot support diagonally inside the pedestal
and lock off.
C
B
a
2
height of pedestal using a spirit level.
3
B
ADDITIONAL MODULES
4
remembering that each corner module makes a
45° curve. Position the foot supports of the
previous module in the grooves of the new
pedestal module.
5
the remaining free holes in each foot support.
6
B
7
1st MODULE
: Locate the foot supports (C) (4 for the first
: Place the module on the floor and check the
: Place the rack (B) in its housing.
: Place the module next to the previous one,
: Line up the holes and insert the 2 screws (a) in
: Check the level of the assembly.
: Place the rack (B) in its housing.
