Eurocave MODULOTHEQUE Assembly Instructions Manual page 11

FASTENINGS
ax2
bx2
TOOL REQUIRED
PARTS
Ax2
FASTENINGS
ax4
TOOL REQUIRED
PARTS
Ax2
10
U F
PPER INISH
1
A
b
2
S
HELVES
1
A
(MV3)
1
: Insert the dowels (a) into the front hole of the
upper finish (A), pushing them in until they stop
and keeping the pressure on until the upper finish
makes contact with the module underneath.
a
2
: Once the finish is in place, secure it with the
securing plates (b), using a Phillips screwdriver.
(MV7)
1
: Secure the shelves (A) using the 4 screws (a)
onto the side of a basic module, lining up the holes
on the shelving unit with those on the module.
a
GB
ASSEMBLY
GB
ASSEMBLY
