Additional Modules - Eurocave MODULOTHEQUE Assembly Instructions Manual

GB
PART
x2
P
EDESTAL
GB
FASTENINGS
ax8
TOOL REQUIRED
(supplied)
PARTS
A
B
Cx2
2
F
EET
Abutting columns of Modulotheque share a pair of feet (see Pedestal Module figs. 5 and 6) Thus to enable you to
assemble a run of abutting columns each Pedestal module (MV2) is supplied with 1 pair of feet. You need 1 extra pair
of feet to complete the run or for an isolated single column. See installation and assembly (Chapter MV2 or MV17).
M
ODULE
1
+ 2 foot supports for the 1st module (MV9)
2
4
5
6
(MV9)
(MV2/MV2L40)
A
a
C
a
B
7
1st MODULE
1
: Position the foot supports (C) (4 for the first
pedestal module and just 2 for every other
abutting pedestal) in the grooves provided, lining
them up with the holes in the wooden pedestal.
Screw together diagonally until tight, using 2
screws (a).
2
: Place the module on the floor and set the level
and height if it is to be a single or initial module.
3
: Locate the rack (B) in its housing.
3

ADDITIONAL MODULES

4
: Line up the module with the previous module
and locate the previous module's foot supports in
the grooves of the new basic module.
5
: Line up the holes and insert the 2 screws (a) in
the remaining holes in each foot support.
6
: Check the height and level of the assembly.
7
: Locate the rack (B) in its housing.
