  • Page 1 Imani Usual Manual...

  • Page 2: Table Of Contents

    Content 1 Production Overview................1 1.1 Production Description..................1 1.2 Technical Specification..................2 1.2.1 Interface Description................2 1.2.2 Icons......................3 1.3 Installation......................4 1.4 Installation Considerations................4 1.5 Equipment Packaging..................5 2 Settings..................... 6 2.1 Main interface....................6 2.2 Static........................6 2.3 Network......................8 2.4 Register Account....................9 2.5 Display......................
  • Page 3 3.1.5 Call DoorPhone..................21 3.1.6 Call Center..................... 21 3.2 Receive a call....................22 3.3 Answer a call....................22 3.4 Reject a call......................23 3.5 contact......................23 3.5.1 Add a new contact.................24 3.5.2 Modify the contact................24 3.5.3 Delete the contact................. 25 3.5.4 Delete all contacts................. 26 3.6 Call log......................

  • Page 4: Production Overview

    1 Production Overview 1.1 Production Description Imani is a smart video indoor phone. It can be connected with Slinex door phone for unlock and monitor. Residents can communicate with visitors via audio and video call, and unlock the door for the visitors.

  • Page 5: Technical Specification

    1.2 Technical Specification Model Imani  7 inch capacitive touch screen TFT LCD, 800x480 pixels, 16:9 Graphic Display wide screen aspect ratio Network Protocol  SIP RFC3261,TCP/UDP/IP,RTP Voice Codec  G.711A/U, G.729, G.722 Video Codec  H.264 Audio Features  Echo Canceller Video Features ...

  • Page 6: Icons

    10PINconnector For 8 security connector Ethernet 1 Network interface can be connected to a hub, switch or other network access devices. Share the network access from ethernet 1 port, and for PC and Ethernet 2 other equipment connection. 1.2.2 Icons Icon Description Network（LAN Port）is connected.

  • Page 7: Installation

    1.3 Installation Wall Bracket Installation Use a 5mm hand drill to Use the pencil to mark 4 make the 4 fixation holes fixation holes through on the wall wall bracket on the wall Once the fixation holes Use 4 ST4X20 screws to fix the are made, insert the four wall bracket in the wall expansion anchors...

  • Page 8: Equipment Packaging

    Place the device away from traffic areas to prevent collisions.  Please use the equipment with the matching power adapter or POE.  1.5 Equipment Packaging Name Quantity Imani Wall bracket Quick Start Guide 10 Pin cable 8 Pin cable Expansion anchor ST4x20 screw...

  • Page 9: Settings

    Settings 2.1 Main interface The default screen is shown as above. User can click the corresponding area to into the interface. 2.2 Static Basic Status  You can view the IP Address, MAC Address, Firmware information in the Basic Status page.
  • Page 10 Network  To check the LAN Type, LAN IP, LAN Mask, Gateway, DNS1,DNS2 information in the Network status page. Phone  View the Model, Hardware, Firmware information in the Phone status page.

  • Page 11: Network

    You can view the sip account status in the Account status page. 2.3 Network DHCP use DHCP mode to get IP address by default. Please go to Imani Setting-Advanced(password:123456)-Network Choose DHCP, press CONFIRM, the phone will get IP address automatically. Static IP...

  • Page 12: Register Account

    area. 2.4 Register Account SIP account is provided by SIP server. Go to Setting-Advanced-Sip Account . Fill int the corresponding sip account parameters, slide down to check more account information. Click Save to save. Click Right key or Left key to switch account 1 or account 2.

  • Page 13: Display

    2.5 Display 2.5.1 Brightness Click Brightness, it will show up modification interface. Click key to adjust the screen brightness, click OK to save.

  • Page 14: Sleep

    2.5.2 Sleep Click Sleep, it will show up a modification interface. Choose the sleep time from 15 seconds to Never. Value 1 minute is setup by default. After the sleep time without any operation, the phone will black screen. Touch it to wake up. 2.6 Sound...

  • Page 15: Ring Tones

    Ring Tones 2.6.1 Click Ring Tones area to select a suitable ringtone, press Save key to confirm. 2.6.2 Door Unit Ring Tones Users can setup the ring tone from the corresponding door phone. Note:This function can only be used with SDMC . Please consult your administrator for more information.

  • Page 16: Dnd Setting

    2.8 DND setting This function is used to prevent the phone from disturbing. Go to Setting-DND. if open DND, external phone call is unable to call in, turned off by default. 1. Enable/Disable DND function. 2. Select valid time of DND. If you don’t enable the IVR, use Whole day by default. 3.

  • Page 17: Album

    To reboot the device, click OK when you see the prompt. The phone will reboot. 2.10.2 Screen clean This function is used to protect the device from being pressed any keys when users clean the screen. 2.10.3 Language To choose a suitable language for Imani monitor. English is set be default.

  • Page 18: Door Station

    2.11 Door Station 1) Go to the path: Setting->Advance(default password: 123456)->Door Station. 2) Click the Door Station Number to type the number. Click OK label to save. 2.12 Password Go to the path: Settings-> Advance(Password:123456)-> Password. Users can modify the password of Advance interface.

  • Page 19: Backup

    2.13Backup Go to Advance-Reset. Choose the Reset mode, click CONFIRM when you see the prompt. The phone will reset to factory setting automatically.

  • Page 20: Function

    3 Function 3.1 Make a call User can directly dial from the soft keypad, select from the contact list or from call log to call out the number. User can choose one of the following steps to enter the dialing interface. Mode 1: Click Call icon on the main screen.

  • Page 21: Call Resident

    3.1.2 Call Resident If you want to call room number, you can select Call Resident label. For example, if you want to call community 1, Building 1, Unit 1, Floor 1, Room1, you can input digits “001001010101”. Shown as below. 3.1.3 Call from Call Log User can enter the call log page to make a call.

  • Page 22: Call From Phonebook

    3.1.4 Call from Phonebook User can enter phonebook interface to make a call. Mode 1: Directly click Contact icon Mode 2: Click Call icon -> click PhoneBook label. If you want to make an audio call, click Audio Call icon .

  • Page 23: Contacts Fuzzy Matching Query

    3.1.4.1 Contacts Fuzzy Matching Query Phone supports contacts fuzzy matching queried, intuitive, concise dialing interface for the intelligent input, greatly reducing the number of buttons, achieve rapid, effective positioning search, avoid duplication of invalid operation, saving time. Click the gray space bar to enter the key character or number to search the contact. The result will be displayed on the left list.

  • Page 24: Call Doorphone

    3.1.5 Call DoorPhone If you want to call door phone number, click Call DoorPhone label call out.  Go to the path: Setting-> Advance( default password: 123456)->Door Station-> click Door Station Number to enter the door number.  After setup the door phone number, users can call out the Door Phone directly. Click Cancel label to end the call.

  • Page 25: Receive A Call

    Incoming calls include audio and video calls. If the caller has been stored in the contacts, it will show the contact name, otherwise it will only show the caller number. When Imani receives the video call, it automatically make a screenshot and save it to the Album.

  • Page 26: Reject A Call

    3.4 Reject a call If user want to reject a call, click Reject label in incoming interface. 3.5 contact User can view, audio call, video call, add, edit, delete the contacts. Two ways to enter the contact page. 1) Directly click Contact icon 2) Click Call icon ->...

  • Page 27: Add A New Contact

    Click to video call the contact 3.5.1 Add a new contact The following shown the ways to enter the add contact page. 1) Click Contact icon -> click on the bottom of the screen. 2) Click Call icon -> Call Log->All Calls -> click on the bottom of the screen.

  • Page 28: Delete The Contact

    2) Click icon 3) Enter contact edit page to modify the contact information. Click OK label to save. Note: Number 1 is room number, Number 2 is sip account. 3.5.3 Delete the contact 1) Select the contact need to delete in the contact list. 2) Click icon 3) It will pop up the prompt “Are you sure?”.

  • Page 29: Delete All Contacts

    3.5.4 Delete all contacts Click icon . It will pop up the prompt “Clear All, Are you sure?”. Click Confirm label to clear all contacts. 3.6 Call log Missed call ...
  • Page 30 1) Go to the path: Call-> Call Log->Missed Calls. 2) Click one of missed call on the right list, the more detail information will be displayed on the left list. Click to establish audio call Click to establish video call Click to delete the missed call number Click to clear call missed call number Click to add the missed call number to contact list...

  • Page 31: Unlock

    Click to clear call history number Click to add the history number to contact list 3.7 Unlock Imani supports remote unlock the door phone via using DTMF code. During the call, users can press Open Lobby label or unlock physical key to open the door during the call.

  • Page 32: Do Not Disturb

    Click DND icon in main interface. When enable DND function, DND icon will be green in the main screen. 3.9 Auto answer If enabled, Imani will automatically answer when there is an incoming call. Configuration on the phone:, 1) Click Setting icon ->...

  • Page 33: Monitor

    out without answer. Configuration on the phone: 1) Click Setting icon -> Advance(default password: 123456)-> click Sip Account. 2) Down slide, check to enable No Answer Forward feature. 3) Input the forward number into the Forward Target bar. 4) Click Ring Time column to input the no one answer ringing time. For example, set 5 seconds.
  • Page 34 WebCam: Users can directly enter the IP camera IP address. Choose one blank and hold it, it will show up the URL modification interface. Enter the IP address of camera , then click OK to save. Once you need to monitor, please click the URL to view.

  • Page 35: Message

    3.12Message 3.12.1 Notice When received new messages, the digit icon will display on the right corner of the Message icon on the main screen. Shown as below. Icons Description New message Old message 3.12.1.1 View a message 1) Go to the path: Click Message icon ->...

  • Page 36: Reply A Message

    3.12.1.2 Reply a message Mode 1: Click Message icon -> click the icon -> click Reply label. Mode 2: Click Message icon -> touch and hold a message will pop up “Option Selector” page-> select Reply column. The “send to” column shows the target number, you can click the empty place to input the content.

  • Page 37: Delete A Message

    3.12.1.3 Delete a message 1) Click Message icon ->touch and hold a message will pop up “Option Selector” page-> select Delete column. Shown as below. 2) Click Delete column to delete this message. Click Confirm label to delete this message.

  • Page 38: Delete All Messages

    3.12.1.4 Delete all messages 1) Click Message icon -> click icon . Click Confirm label to clear all message. Shown as below. 3.12.2 Send Box 1) Go to the path: Message->Send Box.
  • Page 39 2) Click icon to enter the message edit page. Click “send to:” column to input the target number you want to send, click the empty place to input the message content. Click send label to send the text message. 3) You can check the message status in the left list. 4) Click icon can clear all the message.

  • Page 40: Maintenance

    3.12.3 Maintenance In the maintenance page, you can report to property management center if need help. For example, if the light doesn’t work, you can click Light column, then click Confirm label to ask for help.

  • Page 41: Capture

    3.12.4 Capture The album is used to store the screenshots. When monitor received the video call, it can automatically get a screenshot and save it in the album. Click the corresponding column to view the picture. Press and hold one column to delete the selected item. Click icon to delete all pictures.
  • Page 42 Click the empty place on the picture. It will display three icons. Shown as below. Click to back to the previous screenshot Click to back to the Capture Log page Click to enter the next screenshot...

  • Page 43: Family Msg

    Modify: Choose an existed message,then click to delete. 3.13 Zone setting Imani could manage up to 8 alarm devices. In Zone setting interface you can set the alarm device parameters. 1) Go to the path: Setting->Advance( default password: 123456)->Zone Settings.
  • Page 44 Balcony, Kitchen, Study and Bathroom.x 3) Click Type column to select the alarm type. There are many kinds of alarm type: Infrared, Drmagnet, Smoke, Gas, Urgency. 4) Click Trigger mode column, you can select the trigger mode. NC means No Connection, NO means No Open.

  • Page 45: Sos Emergency

    Closed, Opened and 24H. 3.14 SOS emergency When need help, you can click SOS Emergency icon to dial out for Imani emergency help can call out for three predefined numbers in a loop, each number will be called for 60 seconds (by default).
