1) Pull out power line and take out the fuse box at power line jack with a small
screw driver. As shown below.
2) If the fuse is fused, please change fuse of same specification based on
machine model. See the table blow for matching information of fuse and
machine model.
Product
Fuse specification(110VAC)
IT8811
T 2.5A 250V
IT8812
T 2.5A 250V
IT8812B
T 2.5A 250V
IT8812C
T 2.5A 250V
3)
After replacement, install the fuse box back to original position, as shown
below.
Copyright © ITECH Electronic Co., Ltd.
Quick Start
Fuse specification(220VAC)
T1.25A 250V
T1.25A 250V
T1.25A 250V
T1.25A 250V
11
