ORQA FPV.ONE User Manual page 18

DVR
The DVR also records audio from any of the inputs.
Additionally, DVR can record audio from an external microphone, when Receiver
or AV-In inputs are used. To record microphone audio, plug in the microphone
into the 3.5 mm jack on the left side of the goggles. Make sure you have the
correct pinout of the 3.5 mm jack. Check the diagram on page 18.
The microphone recording level should be adjusted through the "Microphone
Volume" menu. The default level is set to 50%. To adjust this setting, press
on
the "Microphone Volume" menu item and then move the right-hand joystick
right-left to increase-decrease the value. Once set, press the left-hand joystick
to confirm and save.
To adjust the audio recording level of the receiver installed in the receiver bay,
on the "Receiver Volume" menu item and then move the right-hand
press
joystick right-left to increase-decrease the value. Once set, press the right-
hand joystick to confirm and save. Note that this setting also adjusts the
recorded audio volume of the AV-in input.
If you try to start the DVR recording or formating the SD card without the SD card
inserted, the "NO SD CARD" message will be displayed.
Format SD Card is used to fast format the inserted micro SD card to the
corresponding FAT system. The system can manage SD Cards up to 2TB.
