For 6.5' & 8' bed lengths components must be confi gured for Passenger or Drivers-Side as
shown.
For 5.5' bed length components must be confi gured for Passenger or Drivers-Side as shown.
1
AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 6:00 AM - 5:00 PM PST
BedStep2™ is invented, designed, engineeried and manufactured exclusively by AMP Research and may be covered by one of the following patents:
6,641,158; 6,830,257; 6,938,909; 7,055,839; 7,380,807; 7,398,985; 7,584,975. Made in USA © 2011 AMP Research
Three-year limited warranty. Professional installation is recommended.
www.amp-research.com
15-03839-90
16-03850-90
NOTE: For Dually applications
see kit 75611-01A for proper
bracket orientation.
Driver-Side Orientation
Driver-Side Orientation
Dodge Ram DS
1500 (2009-Current)
2500/3500 (2010-Current)
16-03852-90
19-02389-90
10-00115-60
19-03037-90
Passenger-Side Orientation
1/4
PART NUMBER:
75406-01A
Torque wrench
1/4" Drill Bit
19-03341-90
3/8" Drill Bit
19-03563-90
11-03639-90
13 mm
15 mm
Passenger-Side Orientation
IM75406 rev 01.02.12
T25
Advertisement
Table of Contents
Related Manuals for AMP Research BedStep 2
Summary of Contents for AMP Research BedStep 2
- Page 1 AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 6:00 AM - 5:00 PM PST BedStep2™ is invented, designed, engineeried and manufactured exclusively by AMP Research and may be covered by one of the following patents: 6,641,158; 6,830,257; 6,938,909; 7,055,839; 7,380,807; 7,398,985; 7,584,975. Made in USA © 2011 AMP Research Three-year limited warranty.
- Page 2 Use supplied drill template (See page 4) and Hole set A is to be used on 6.5’ and 8’ beds mark holes in front bed channel mount. Pre drill Hole set B is to be used on 5.5’ beds. holes using 1/4” drill bit. Next drill hole to 3/8”. Using a 15mm Socket assemble Lateral mount onto linkage.
- Page 3 Using a 13mm Socket with extension, align bolts Set bolts into lower lateral mount. Set bracket with threaded plate. Torque to 16ft-lbs. into place and use provided hardware to bolt bracket to inner bed brace. 13mm Set linkage into position, tighten bolts using Tighten bracket bolt with 13mm socket and 15mm Socket.
- Page 4 To retract, gently kick up on the underside of the step To deploy the step, press down using your foot on pad. the outside edge of the step pad. Template for Step 3 on page 2. Center Template on bed chan- Align this edge up to vertical reinforcement nel and align edge up to vertical plate on edge of bed channel...
