b. Attach the J3 Plus Back to the hardware
receivers by inserting left and right
mounting pins (F) in the left and right
receivers (G).
c. Locate the back to the approximate
location, relative to both the chair and
the user.
d. Tighten bolts on the inside of the
mounting pin (F). The recommended
torque specification is 100-110 in-lbs.
(11.3-12.4 Nm)
e. Once all components have been properly
aligned, tighten the clamp screws (C) to
approximately 75-85 in-lbs. (8.5-9.3 Nm)
f. Finish by inserting the locking pin into the
receiver and releasing a few times to
ensure smooth operation.
NOTE - Back depth and angle may require
additional adjustment to ensure proper fit to
the user.
