Please read these instructions carefully before beginning the installation. Failure to understand and follow installation instructions
may result in injury to installer and/or end user and may void the warranty.
If you have any questions call Sunrise Medical Technical support at 800.333.4000

Parts included:

1x Full Footbox
4x Screws

1. Mount Single Footbox onto foot-plate

a. Fasten Full Footbox onto foot-plate (A) using
screws (B), as shown.
b. Please see drill guide on back of this sheet if foot-
plate holes cannot accommodate Full Footbox
holes.
c. Place velcro strap (C) around leg rest extension bar.
F ULL FOOT BOX I N ST L L T I ON S HE E T

Tools needed for installation:

1x 4mm Hex Wrench
1
C
Customer Service: 800.333.4000
www.SunriseMedical.com
Sunrise Medical • 2842 Business Park Ave. • Fresno, CA 93727 • USA
1
B
In Canada (800) 263-3390
©2014 Sunrise Medical (US) LLC
06.14
129295 Rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FULL FOOTBOX and is the answer not in the manual?

Questions and answers

Summary of Contents for Jay FULL FOOTBOX

  • Page 1 1x 4mm Hex Wrench 4x Screws 1. Mount Single Footbox onto foot-plate a. Fasten Full Footbox onto foot-plate (A) using screws (B), as shown. b. Please see drill guide on back of this sheet if foot- plate holes cannot accommodate Full Footbox holes.
  • Page 2 Footplate Template 9/32 DRILL SIZE 4 INCHES Left Side Right Side...
