- Page 1 AUTOMATION WITH “PRATICO SYSTEM” FOR SLIDING GATES SERIES INSTALLATION MANUAL BX-P...
- Page 2 4 Description 4.1 Gearmotor The BX-P ratiomotor is designed and built by CAME CANCELLI AUTOMATICI S.p.A. and it meets the safety standards in force. Guaranteed 24 months if not tampered with. The case consists partly of cast aluminium, inside of which operates the non-reversible electromechanical gearmotor, and partly of a covering in ABS plastic inside of which is an electronic card, the transformer and the emergency battery holder.
-
Page 3: Parts Description
4.3 Parts description GEARMOTOR UNIT 1 - Gearmotor 2 - Board cover support 3 - End-stop flaps 4 - ZBX8 basic control board 5 - Electric board front cover 6 - Release door 7 - Base plate 8 - Securing screws 9 - Plates for securing screws 10 - Nuts ACCESSORIES... -
Page 4: Installation
5 Installation Installation must be carried out by expert qualified personnel and in full observance of regulations in force. 5.1 Preliminary checks Before proceeding with the installation, it is necessary to: • Make sure the door is rigid and compact and that the sliding wheels are well oiled and in good condition. •... - Page 5 1- BX-P unit 6- Key-operated selector switch 2- Control board incorporated 7- Flashing light indicating door movement 3- Radio receiver 8- Antenna 4- Limit-switch tabs 9- Safety photocells 5- Rack 10- Photocell column 11- Closure stop 5.4 Motor to base anchorage The following applications are only examples, as the space required for unit installation and the accessories vary de- pending on dimensions and therefore it is up to the installer to select the best solution.
-
Page 6: Unit Installation
5.5 Unit installation During the initial phase of installation, the feet should protrude by 5-10 mm. in order to allow for alignment, anchorage of the rack and further adjustments. Perfect alignment with the guide rail is made possible by the (paten-ted) built-in regulation system, which consists of: - slots for horizontal adjustment;... - Page 7 5.7 Attaching the switch tabs Position the limit-switch tabs (whose positions determine the limits of gate travel) on the rack. Note: do not allow the gate to strike the mechanical stops in the open or closed positions. 5.8 Manual release of the gearmotor To open the access door, insert the key, push down and rotate clockwise.
-
Page 8: Control Board
6 Control board 6.1 Technical description board This control board is powered by 230V a.c. across terminals L and N, and is protected by a 5A fuse on the main power line. Control systems are powered by low voltage and protected with by a 1A fuse. The total power consumption of 24V accessories must not exceed 40 W. -
Page 9: Electrical Connections
6.3 Electrical connections 230 V (a.c.) power supply 230 V (a.c.) motor (Condenser) - in motion (e.g. fl ashing light 25W) 230V output - cycle lamp (max. 60W), to position the dips 1 and 6 in ON 24V powering accessories max. 40W Pushbutton stop (N.C.) Pushbutton partial opening (N.O.) see par. - Page 10 6.4 Gearmotor end-stop connection Gearmotor end-stop assembly already connected for For right-hand installation: installation on the left-hand side seen from inside. - reverse FA-FC of the end stops on the terminal board; - reverse the U-V phases of the motor on the terminal board. 6.5 Motor torque limiter To change the torque, move the faston identifi...
- Page 11 6.6 unction selections (dip-switch) 1 ON - Automatic closing - The automatic closing timer is automatically activated at the end of the opening cycle. The preset, adjustable automatic closing time is automatically interrupted by the activation of any safety system, and is deactivated after a total stop command or in case of power failure;...
- Page 12 7 Installation procedure of the transmitter for remote control Read the three steps below before beginning installation procedures: - prepare the radio board (paragraph 7.1); - procedure for codifying the transmitter (paragraph 7.2); - memorizing the code on the command board (paragraph 7.3). 7.1 Prepare the radio board (AF1) 1) On AM transmitters operating at Frequency/MHz...
- Page 13 T434M - T314M T432S - T432SA - T434MA - T432NA - T434NA set code only see instructions on pack P1 = CH1 P2 = CH2 P3 = CH3 P4 = CH4 T432 - T434 - T438 - TAM432SA T132 - T134 - T138 T152 - T154 - T158 see instruction sheet inside the...
- Page 14 3) Repeat the procedure of parts 1 and 2 with the “CH2” key, associating it wit another transmitter key. N.B.: if the code needs to be changed, repeat the sequence described above. 8 Installation procedure for the remote control for automatically releasing the motor (pratico system) The “pratico system”...
- Page 15 8.2 Battery connection and memorization of the code on the control board Terminal -, + Transformer 1) Insert the terminal (-, +) connected to the battery Electric lock to the free coupling of the motherboard. Note: the board must be battery- powered for saving procedures.
- Page 16 9 Connection of two paired ratiomotors with a single control 1) Coordinate ratiomotor A and B’s movement direc- tion, changing the rotation of motor B (see paragraph 6.4 ratiomotor/end-stop connection). 2) Perform the electric connections on motor A’s control board as instructed in paragraph 6.3 electric connections, page 9.
-
Page 17: Maintenance
UNI EN ISO 14001 standard to ensure environmental protection. Please continue our efforts to protect the environment which CAME considers one of the cardinal elements in the development of its operational and market strategies simply by observing brief recommendations as regards disposal: DISPOSAL OF PACKAGING –... - Page 18 CAME UNITED KINGDOM LTD UNIT 3, ORCHARD BUSINESS PARK TOWN STREET, SANDIACRE NOTTINGHAM - NG10 5BP - U.K. Tel 0044 115 9210430 Fax 0044 115 9210431...
