I N S T A L L A T I O N I N S T R U C T I O N S FCA4U LCM4U Quad Ceiling Accessory Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description FCA4U / LCM4U... -
Page 3: Important Safety Instructions
A WARNING alerts you to the possibility of serious injury or death if you do not follow the instructions. IMPORTANT ! : The FCA4U is designed to be mounted to a 1-1/2" NPT or NPSM following ANSI/ASME B1.20.1 (Schedule 40, 0.154" minimum thickness steel or... - Page 4 Installation Instructions FCA4U / LCM4U DIMENSIONS FCA4U DIMENSIONS: INCHES [MILLIMETERS] LCM4U - Consists of FCA4U plus four LCM1U mounts COLUMN SOLD SEPARATELY 10.5 265.9 C/L OF MOUNT DIMENSIONS: INCHES [MILLIMETERS]...
- Page 5 FCA4U / LCM4U Installation Instructions DIMENSIONS (cont’d) DIMENSIONS: INCHES LCM4U - Consists of FCA4U plus four LCM1U mounts [MILLIMETERS] SHOWN WITH SIMULATED 60" SCREENS SHOWN WITH SIMULATED 55" SCREENS LEGEND Tighten Fastener Open-Ended Wrench Apretar elemento de fijación Llave de boca Befestigungsteil festziehen Gabelschlüssel...
-
Page 6: Tools Required For Installation
Installation Instructions FCA4U / LCM4U TOOLS REQUIRED FOR INSTALLATION 1/8" (included) 3/16" (included) 1/2" or 13mm PARTS B (1) [Bottom coupling] A (1) [Quad ceiling accessory] C (1) 10-24 x 1/4" D (8) [Rotation ring] E (8) G (10) 5/16 x 3/4"... -
Page 7: Installation
1-1/2" NPT or NPSM following ANSI/ASME B1.20.1 (Schedule 40, 0.154" minimum thickness steel or aluminum-ASTM B221) threaded extension column, or a UL Listed Chief CPA column (not included) have been properly installed following instructions provided with ceiling plate and extension column. - Page 8 Installation Instructions FCA4U / LCM4U Slide quad ceiling accessory (A) up from below onto installed column (not included). (See Figure 3) Tighten two existing 5/16 x 1-1/2" button head cap screws in center of quad ceiling accessory. (See Figure 3) Slide bottom stop collar onto installed column, lining up holes in collar with holes in column.
- Page 9 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief, a products division of Asia Pacific A Office No. 918 on 9/F, Shatin Galleria Milestone AV Technologies 18-24 Shan Mei Street...
