Summary of Contents for Clarke IVP14A
- Page 1 SUBMERSIBLE WATER PUMP MODEL No: IVP14A Part No: 7230095 OPERATION & MAINTENANCE INSTRUCTIONS 08/08...
-
Page 2: Specifications
INTRODUCTION Thank you for purchasing this CLARKE water pump. This highly efficient centrifugal pump is designed for pumping clean water, or water containing sand or solids in suspension, that is with a maximum of 5% solid content, and a maximum 12mm in diameter. -
Page 3: Pump Features
PUMP FEATURES The pump is of rugged and durable construction, designed for long lasting continuous operation and its’ stainless steel body provides good anticorrosive properties. The motor is provided with built in overload protection. IDEALLY SUITED FOR • Draining ponds, pools, cellars, drains, building excavations , etc., where water temperature does not exceed 40°C. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS 1. This pump is designed to pump WATER ONLY. Never use for pumping flammable liquids or chemicals of any kind. 2. NEVER allow the pump to run dry. 3. An approved Residual Current Device (RCD) MUST be used when pumping from ponds or swimming pools. -
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS The mains lead should be connected to a standard 230Volt (50Hz) electrical supply through an approved 13Amp BS 1363 plug or a suitably fused isolator switch. We recommend that the pump be connected via a Residual Current Device (RCD). IMPORTANT: If used for draining swimming pools or ponds, it is mandatory that the pump be fitted with a Residual Current Device (RCD), with a rated residual operating current of no greater 30mA. -
Page 6: Parts Identification
PARTS IDENTIFICATION Handle Outlet Connector Pump Float Switch Base... - Page 7 NOTE: When the pump is used in a permanent or semi-permanent installation, a check valve MUST be fitted in the delivery pipe. NOTE: Suitable hoses are available from your Clarke dealer. LOCATING THE PUMP 1 Tie a rope to the lifting handle of the pump and lower the pump on a flat surface in the area that you want to drain.
-
Page 8: Using The Pump
USING THE PUMP CAUTION: CHECK THE PUMP FOR DAMAGE BEFORE USE, DO NOT USE THE PUMP IF IT IS DAMAGED IN ANY WAY. 1 Connect the mains plug to a high sensitivity residual current device (RCD) which has a tripping current of less then 30mA. 2 Switch the mains power supply on. -
Page 9: Cleaning And Maintenance
WARNING: DO NOT ATTEMPT TO STRIP THE PUMP FURTHER AS THIS WILL INVALIDATE THE GUARANTEE. ANNUALLY OR EVERY 2000 WORKING HOURS (Whichever is sooner) The sealing oil must be checked by a qualified pump engineer. Consult your Clarke dealer, or Clarke International Service Department. -
Page 10: Troubleshooting
, s t e l l PARTS & SERVICE CONTACTS For spare parts and service, please contact your nearest dealer, or CLARKE International, on one of the following numbers. PARTS & SERVICE TEL: 020 8988 7400 or e-mail as follows: PARTS: Parts@clarkeinternational.com... -
Page 11: Declaration Of Conformity
The CE mark was first applied in: 2007 Product Description: Submersible Water Pump Model number(s): IVP/14A Serial / batch Number: Current Manufacture. Date of Issue: 15/002/2007 Signed A.C. AIKEN Senior Manager Clarke International. 07-0738 IVP14A Sub Pump RV1.doc Page 1 of 1...
