Mating Connector

The mating connector for the PremierWave system on module is Hirose part number DF40C
(2.0)-80DS-0.4V (51). Special care must be taken when mating and unmating the
PremierWave module to the mating connector. Refer to the Hirose DF40 data sheet below
for proper connector mating and unmating, along with the proper connector footprint.
The mating connector data sheet is available for download at:
connectors.com/connectors/H204ProductListCompare.aspx?clprm=06844132651&mode=%
EF%BC%90%EF%BC%91

Module Radio and Antenna Connection Options

The PremierWave EN module supports connectivity with two antenna ports for single stream
diversity. The unit can be operated with diversity enabled or in single antenna mode using
either antenna port. The PremierWave EN module has two options for antenna connections.
SKU 1 may be operated in single antenna mode without an external antenna using the on-
board chip antenna.
PremierWave SKU options
SKU 1 with Chip Antenna
P/N PEN100100A-01 bulk
P/N PEN10010SA-01 sample
SKU 2 without Chip Antenna
P/N PEN10010NA-01 bulk
P/N PEN10010NASA-01 sample

External Antennas

The PremierWave EN module has been certified using the external antennas listed below in
addition to the internal antenna provide on the module. Per FCC guidelines, the
PremierWave certification remains valid if using an antenna similar to the antennas below or
the internal chip antenna. If using an antenna similar to one of the antennas below, but from
a different manufacturer part number the antenna gain must be equal to or less than specified
in the table. Consult with your certification lab for more details.
Antenna Type
Swivel type antenna, with RP-
SMA(M) connector
Swivel type antenna, with RP-
SMA(M) connector
Internal Chip Antenna Option
PremierWave® Embedded System on Module Integration Guide
Table 2-2 PremierWave Antenna SKU options
Antenna Port 1
Connection
Internal Chip antenna
U.FL for external antenna
Table 2-3 PremierWave External Antenna Options
Peak Gain Typical
5 dBi, 2.4 Ghz to 2.5 Ghz,
5 dBi, 5.15 Ghz to 5.85 Ghz
2 dBi, 2.4 Ghz to 2.5 Ghz,
2 dBi, 5.15 Ghz to 5.85 Ghz
2.17 dBi, 2.4 GHz to 2.5 Ghz
2.74 dBi, 4.9 Ghz to 5.8 Ghz.
2: Description and Specifications
https://www.hirose-
Antenna Port 2 Connection
U.FL for external antenna
U.FL for external antenna
Vendor Vendor Part
Number
Taoglas GW.71.5153
Wanshih WSS002
N/A N/A
