TN-SFP-xx25G-xR-S Series
Cisco Compatible 10G/25GBase SFP28 Modules
10G/25GBase-X, SFP28 With DMI (LC)
User Guide
Part Number 33815
Revision C February 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TN-SFP 25G R-S Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Lantronix TN-SFP 25G R-S Series

  • Page 1 TN-SFP-xx25G-xR-S Series Cisco Compatible 10G/25GBase SFP28 Modules 10G/25GBase-X, SFP28 With DMI (LC) User Guide Part Number 33815 Revision C February 2022...
  • Page 2 TN-SFP-xx25G-xR-S Series User Guide Intellectual Property © 2022 Lantronix, Inc. All rights reserved. No part of the contents of this publication may be transmitted or reproduced in any form or by any means without the written permission of Lantronix. Lantronix is a registered trademark of Lantronix, Inc. in the United States and other countries.
  • Page 3: Table Of Contents

    Lantronix TN-SFP-xx25G-xR-S Series User Guide Table of Contents Product Description ..............................4 Ordering Information ..............................4 Optical Specifications ..............................5 Specifications and Standards .............................5 Applications ................................6 Safety Instructions ...............................6 SFP Unpacking ................................7 SFP Installation ................................7 Cautions .................................7 Installing an SFP Module ............................7 Fiber Cable Physical Characteristics ........................8 Connecting Fiber Cables ............................8...
  • Page 4: Product Description

    TN-SFP-xx25G-xR-S Series User Guide Product Description The Lantronix TN-SFP-xx25G-xR-S Series 25G SFP28 transceiver modules are designed to install in any SFP28 port allowing for 25G/10GBase-X interfaces to the network via the SFP28 connector. The TN-SFP-xx25G-xR-S transceivers are Cisco Compliant and are designed for bi-directional serial-optical data communication such as 25G Ethernet at speeds up to 26.5 Gbps.
  • Page 5: Optical Specifications

    • Compliant with SFF-8431 and SFF-8472 • RoHS Compliant Optical Specifications The Optical Specs for all Lantronix SFPs are listed at www.transition.com/sfp.pdf. Specifications and Standards The TN-SFP-10G-xxx and TN-CWDM-10G-xxx are designed to meet these standards and specifications: Standards IEEE 802.3z, IEEE 802.3, IEEE 802.3ae, IEEE 802.3CC Output Wavelength -5.5nm <...
  • Page 6: Applications

    Do not power up the laser product without connecting the laser to the optical fiber and putting the cover in position, as laser outputs will emit infrared laser light at this point. See the Lantronix SFP page for our full line of SFP transceivers. See the FOA webpage for additional information.
  • Page 7: Sfp Unpacking

    Save the packaging for possible future use. Note: TN-SFP distances, TX power, RX power, and link budgets can be found on Lantronix website. The fiber optic transmitters on this device meet Class I Laser safety requirements per IEC-825/CDRH standards and comply with 21 CFR1040.10 and 21CFR1040.11.
  • Page 8: Fiber Cable Physical Characteristics

    Lantronix TN-SFP-xx25G-xR-S Series User Guide 7. Connect the fiber cable to the fiber port connector of the SFP device. Make sure the SFP release latch is in the up (closed) position when you insert the cable connector into the SFP.
  • Page 9: Removing An Sfp Module

    Lantronix TN-SFP-xx25G-xR-S Series User Guide Removing an SFP Module Caution: Be careful when removing the SFP or SFP+ from a device. Some SFP transceiver module temperatures may exceed 160°F (70°C) and be too hot to touch with bare hands. Note: Do not remove and replace the SFP modules more often than necessary;...
  • Page 10: Ddmi (Digital Diagnostics Monitoring Interface)

    Lantronix TN-SFP-xx25G-xR-S Series User Guide DDMI (Digital Diagnostics Monitoring Interface) DDMI (Digital Diagnostics Monitoring Interface) provides enhanced digital DMI for optical transceivers which allows real time access to device operating parameters. The following DMI port screen and explanation table contains brief definitions of the DDMI support offered on some Small Form Factor Pluggable (SFP) Transceiver Modules.
  • Page 11: Sfp Information And Sfp Detail Info

    Lantronix TN-SFP-xx25G-xR-S Series User Guide SFP Information and SFP Detail Info Note: This feature is not available on all devices and may vary between products. See the related manual for more information. SFP Information This page displays general SFP information and monitoring information as shown and described below.
  • Page 12: Sfp Detail Info

    Lantronix TN-SFP-xx25G-xR-S Series User Guide voltage. Data is assumed to be based on measurement of a laser monitor photodiode current. Data is not valid when the transmitter is disabled. Displays the measured received optical power in mW. Absolute accuracy is dependent upon the exact optical wavelength.
  • Page 13: For More Information

    Lantronix TN-SFP-xx25G-xR-S Series User Guide Vendor Name Displays the vendor name. Vendor P/N Displays the vendor part number or product name (e.g., TN-SFP-25G-ER). Vendor Revision Displays the vendor product revision. Vendor Serial Displays the vendor serial number for the transceiver.
  • Page 14: Compliance Information

    In accordance with European Union Directive 2002/96/EC of the European Parliament and of the Council of 27 January 2003, Lantronix will accept post usage returns of this product for proper disposal. The contact information for this activity can be found in the 'Contact Us' portion of this document.
  • Page 15 Lantronix TN-SFP-xx25G-xR-S Series User Guide Der Anschluss dieses Gerätes an ein öffentlickes Telekommunikationsnetz in den EGMitgliedstaaten verstösst gegen die jeweligen einzelstaatlichen Gesetze zur Anwendung der Richtlinie 91/263/EWG zur Angleichung der Rechtsvorschriften der Mitgliedstaaten über Telekommunikationsendeinrichtungen einschliesslich der gegenseitigen Anerkennung ihrer Konformität.
  • Page 16 Toll Free: 800-526-8766 Phone: 949-453-3990 Fax: 949-453-3995 Technical Support Online: http://www.transition.com/support. Sales Offices For a current list of our domestic and international sales offices, go to the Lantronix web site at www.lantronix.com/about/contact. 33815 Rev. C https://www.lantronix.com/ Page 16 of 16...
