Lantronix PremierWave EN Integration Manual page 10

Pin# Pin Name
46 WKUP
47
GND
48
S3V3
49
DDP
50
S3V3
51
DDM
52
S3V3
53
GND
54
GND
55
HDPA
56
ICE_NTRST
57
HDMA
58
TDI
59
GND
60
GND
61
GND
62
TMS
63
ERX-
64
TCK
65
ERX+
66
GND
67
GND
68
ICE_RTCK
69
RXCT
70
TDO
71
TXCT
72
GND
73
GND
74 ICE_NRST
75
ETX-
76
GND
77
ETX+
78
S3V3
79
GND
80
S3V3
PremierWave® Embedded System on Module Integration Guide
Dir Function Name
I CPU Wakeup
Drive low with Open Drain, Signal pulled up internally, Do not
Drive high
3.3V Power Input
I/O USB Device Port +
3.3V Power Input
I/O USB Device Port -
3.3V Power Input
I/O USB Host Port A +
O JTAG/Debug Signal Pins
I/O USB Host Port A -
I JTAG/Debug Signal Pins
I JTAG/Debug Signal Pins
I Ethernet Receive Data -
I JTAG/Debug Signal Pins
I Ethernet Receive Data +
I JTAG/Debug Signal Pins
I Ethernet Receive Data Center Tap
O JTAG/Debug Signal Pins
I Ethernet Transmit Data Center Tap
O JTAG/Debug Signal Pins
Use a buffer on this signal to disable external logic inputs when
the module is in initial power up or Shut Down mode. See
Module Initial Power Up Sequence
O Ethernet Transmit Data -
O Ethernet Transmit Data +
3.3V Power Input
3.3V Power Input
2: Description and Specifications
below.
10
