Technical Support Online: www.lantronix.com/support Sales Offices For a current list of our domestic and international sales offices go to the Lantronix web site at www.lantronix.com/about/contact. Disclaimer and Revisions All information contained herein is provided “AS IS.” Lantronix undertakes no obligation to update the information in this publication.
Changes or modifications to this device not explicitly approved by Lantronix will void the user's authority to operate this device. The information in this guide may change without notice. The manufacturer assumes no responsibility for any errors that may appear in this guide. Refer to the module datasheet for full compliance information.
List of Figures Figure 2-1 PremierWave 2050 Evaluation Board PWGG2052000K Connectors and Jumpers 8 Figure 2-2 Evaluation Board Schematic for Part 1 of 4 ____________________________ 16 Figure 2-3 Evaluation Board Schematic Part 2 of 4 _______________________________ 17 Figure 2-4 Evaluation Board Schematic Part 3 of 4 _______________________________ 18 Figure 2-5 Evaluation Board Schematic Part 4 of 4________________________________ 19 List of Tables Table 2-1 Evaluation Board Connectors, Header and Switches ______________________ 8...
Introduction About this Guide This user guide provides the information needed to use the Lantronix® PremierWave® 2250 enterprise Wi-Fi® IoT module with the evaluation kit. The intended audiences are the engineers responsible for integrating the PremierWave 2050 module into their product.
PremierWave 2050 Evaluation Kit Contents Two versions of the Lantronix PremierWave 2050 evaluation kit are available: The kit identified by part number PWGG2051000K includes an evaluation board with installed PW20501 module which has two U.FL connectors and two RP-SMA connectors.
2: Evaluati ion Kit he figure belo ow shows the PremierWav e 2050 evalu ation board a and highlights all of the onnectors and d configuratio on jumpers. T The following t table lists eac ch of the conn nectors and umper header rs along with t their function.
Page 9
2: Evaluation Kit Ref Des. Connector/Header Function Serial Port 2 Standard DB9 port for connection to RS232, RS485, and RS422 networks Dual Type A USB Host Port Port A of jack is a USB2.0 full speed port Port B of jack is a USB2.0 high speed port Mini USB Connector Standard USB device port that can be used to power the evaluation board and/or drive the PremierWave 2050 module USB 2.0 High Speed device port.
2: Evaluation Kit Ref Des. Connector/Header Function JP13 Serial Port 2 RS232/RS422/RS485 Mode Jumper Leave open for RS232 mode. Install for RS422/RS485 JP14 Serial Port 2 RS422/RS485 Mode Jumper Leave open for RS232 or 4-wire mode. Install for 2-wire mode. JP15, JP16 USB Host Power Enable Headers Leave open to enable USB host port power.
2: Evaluation Kit Table 2-6 JP9 Serial Port 1 Flow Control Break Out Header PremierWave 2050 PremierWave 2050 Module PIN J6 Evaluation Board Module Pin FUNCTION Function Pin # Pin # Serial Port TX (output) RS232, RS485 TX Serial port RX (input) RS232, RS485 RX Serial port RTS1 or TX enable or RS232 RTS, RS485 TX...
2: Evaluation Kit Antenna Port The PremierWave 2050 evaluation board includes two brackets for mounting the U.FL to reverse polarity SMA RF cables included with the kit. Follow the procedure below when installing the antenna cable. The same procedure applies when using the PCB strip antenna, with the exception that the swivel antenna does not need to be connected to the RF cable.
2: Evaluation Kit LEDs The PremierWave 2050 evaluation board includes several LEDs for signal and unit status. The table below lists all of the LEDs and their functions. Table 2-10 LEDs Signals Module LED Ref Color LED Function Design Orange PremierWave 2050 Status LED 1 Power is ON/No Error –...
