Protekt P-50N ISOL Instruction Manual

· a full body harness (conforming to EN 361) is the only acceptable body holding device that can be used, in a fall arrest system.
· in full body harness use only attaching points marked with big letter "A" to attach a fall arrest system.
· the anchor device or anchor point for the fall arrest system should always be positioned, and the work carried out in such a way, as
to minimise both the potential for falls and potential fall distance. The anchor device/point should be placed above the position of the
user . The shape and construction of the anchor device/point shall not allowed to self-acting disconnection of the equipment.
Minimal static strength of the anchor device/point is 12 kN. It is recommended to use certified and marked structural anchor point
complied with EN795
· it is obligatory to verify the free space required beneath the user at the workplace before each occasion of use the fall arrest system,
so that, in the case of a fall, there will be no collision with the ground or other obstacle in the fall path. The required value of the free
space should be taken from instruction manual of used equipment.
· there are many hazards that may affect the performance of the equipment and corresponding safety precautions that have to be
observed during equipment utilization, especially: - trailing or looping of lanyards or lifelines over sharp edges, - any defects like
cutting, abrasion, corrosion, - climatic exposure, - pendulum falls, - extremes of temperature, - chemical reagents, - electrical
conductivity.
· personal protective equipment must be transported in the package (e.g.: bag made of moisture-proof textile or foil bag or cases
made of steel or plastic) to protect it against damage or moisture.
· the equipment can be cleaned without causing adverse effect on the materials in the manufacture of the equipment. For textile
products use mild detergents for delicate fabrics, wash by hand or in a machine and rinse in water. Plastic parts can be cleaned only
with water. When the equipment becomes wet, either from being in use or when due cleaning, it shall be allowed to dry naturally,
and shall be kept away from direct heat. In metallic products some mechanic parts (spring, pin, hinge, etc.) can be regularly slightly
lubricated to ensure better operation. Other maintenance and cleaning procedures should be adhered to detailed instructions
stated in the manual of the equipment.
· personal protective equipment should be stored loosely packed, in a well-ventilated place, protected from direct light, ultraviolet
degradation, damp environment, sharp edges, extreme temperatures and corrosive or aggressive substances.
IT IS THE RESPONSIBILITY OF THE USER ORGANISATION TO PROVIDE THE IDENTITY CARD AND TO FILL IN THE DETAILS
REQUIRED. THE IDENTITY CARD SHOULD BE FILLED IN BEFORE THE FIRST USE BY A COMPETENT PERSON,
RESPONSIBLE INTHE USER ORGANIZATION FOR PROTECTIVE EQUIPMENT. ANY INFORMATION ABOUT THE EQUIPMENT
LIKE PERIODIC INSPECTIONS, REPAIRS, REASONS OF EQUIPMENT'S WITHDRAWN FROM USE SHALL BE NOTED INTO THE
IDENTITY CARD BY A COMPETENT PERSON. THE IDENTITY CARD SHOULD BE STORAGED DURING A WHOLE PERIOD OF
EQUIPMENT UTILIZATION. DO NOT USE THE EQUIPMENT WITHOUT THE IDENTITY CARD. ALL RECORDS IN THE IDENTITY
CARD CAN BE FILLED IN ONLY BY A COMPETENT PERSON.

IDENTITY CARD

MODEL AND TYPE OF EQUIPMENT
SERIAL NUMBER
USER NAME
DATE OF PURCHASE
PERIODIC EXAMINATION AND REPAIR HISTORY
REASON FOR
DATE
ENTRY PERIODIC EXAMINATION
OR REPAIR AND OTHER REVELANT INFORMATIONS
1
2
3
4
PROTEKT, 93-403 LODZ,
ul. Starorudzka 9, POLAND,
TEL: (48 42) 680 20 83, FAX: (48 42) 680 20 93
www.protekt.com.pl
REF. NUMBER
DATE OF MANUF.
DATE OF PUTTING
INTO OPERATION
DEFECTS NOTED, NAME AND SIGNATURE
REPAIRS CARRIED OUT OF COMPETENT PERSON
European certification was executed in the
CENTRAL INSTITUTE OF LABOUR PROTECTION
ul. Czerniakowska 16, 00-701 Warszawa, Polska
Instruction Manual
Carefully read the instruction
manual before using
the equipment.
1437
Product resistant to flame and molten metal splashes according to
section 4.1.5 of the EN 358 standard.
The safety harness is an element of personal fall arrest equipment and complies with
the EN 361 and EN 358 standards.

CONSTRUCTION

The safety harness is made of aramid belt sections properly sewn together and
connected by metal buckles. The resulting system provides full comfort and safety at
work.

EQUIPMENT

- back anchorage buckle with extension belt – designed to attach the connecting and
energy-absorbing component
- chest attachment loops – designed to attach the connecting and energy-absorbing
component
- work positioning belt
- adjustment and fastening buckles – for quick and easy putting on the harness and
for adjusting the length of all belts to the user's body shape.

PERIOD OF USE

The safety harness can be used for 5 years, counting from the date of putting the
device into operation. After 5 years of use the safety harness must be withdrawn
from use for a detailed manufacturer's inspection.
Such inspection can be conducted by:
- harness manufacturer;
- person authorized by the manufacturer;
- a company authorized by the manufacturer.
During the inspection a period of use for the safety harness until the next inspection
will be determined.
The safety harness must be withdrawn from use immediately and destroyed when it
has been used to arrest a fall.

SIZES

The safety harness is manufactured in two sizes:
- Medium – M-XL
- Large - XXL
Description of device marking
device model
type of the device
reference number
PERIODIC
size
EXAMINATION
NEXT DUE DATE
Month/year of manufacture
Serial number
number and year of the European
standard, the requirements of which
the equipment meets
The CE marking with the identity
number of the notified body controlling
the manufacturing process of the
equipment (Article 11)
Name of the manufacturer
or distributor:
No. 1437
SAFETY HARNESS
EN 361:2002
EN 358:1999
Ref.: AB 151 01
Front view
shoulder strap
adjusting
buckle
of the shoulder
strap
thigh strap
connecting
and adjusting
buckle
of the thigh strap
P-50N ISOL
back attaching
buckle for attaching
fall arrest system
SAFETY HARNESS
Ref.: AB 151 01
Size: MEDIUM
LARGE
Date of identity label
manufacture: 11.2012
work
Serial number: 00012
positioning
EN 361:2002
belt
EN 358:1999
1437
Carefully read the instruction
manual before using
the equipment.
P-50N ISOL
connecting
and adjusting
buckle
of the chest
strap
front attaching loops
for attaching
fall arrest
system
side buckles
for attaching
work
positioning
system
connecting
and adjusting
buckle
of the work
positioning belt
back view
lenghtening element
of the back attaching buckle
for attaching
fall arrest system
saddle
strap
